SDO HMI 2011-12-14 22:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.81 | 77.48 | 2.04 | 56.60 | 21.66 | 299.73 | -42.55 | 58.90 | 0.7343 | -135.3 | -117.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-14 22:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.62 | 0.00 | 1.05 | 19.50 | 306.51 | -35.77 | 57.96 | 0.6524 | -726.0 | -681.6 | |
| 0.00 | 1.11 | 0.00 | 0.75 | 21.80 | 304.84 | -37.44 | 55.91 | 0.6839 | -502.0 | -428.8 | |
| 0.00 | 1.53 | 0.00 | 1.01 | 18.91 | 305.45 | -36.82 | 59.42 | 0.6610 | -915.0 | -737.3 | |
| 0.00 | 1.53 | 0.00 | 1.01 | 19.13 | 305.28 | -37.00 | 59.22 | 0.6641 | -597.0 | -518.5 | |
| 0.00 | 1.62 | 0.00 | 1.06 | 18.60 | 305.38 | -36.90 | 59.90 | 0.6601 | -691.0 | -625.5 | |
| 0.00 | 1.02 | 0.00 | 0.68 | 18.98 | 305.04 | -37.23 | 59.57 | 0.6659 | -532.0 | -405.8 | |
| 0.00 | 1.19 | 0.00 | 0.79 | 18.29 | 304.83 | -37.45 | 60.64 | 0.6647 | -778.0 | -719.6 | |
| 0.00 | 0.85 | 0.00 | 0.57 | 18.92 | 304.39 | -37.89 | 60.03 | 0.6730 | -664.0 | -627.5 | |
| 0.00 | 0.85 | 0.00 | 0.63 | 26.82 | 301.56 | -40.72 | 51.63 | 0.7449 | -509.0 | -449.6 | |
| 0.00 | 1.02 | 0.00 | 0.68 | 18.07 | 304.49 | -37.79 | 61.13 | 0.6675 | -723.0 | -564.9 | |
| 0.00 | 1.02 | 0.00 | 0.68 | 18.05 | 304.30 | -37.98 | 61.28 | 0.6695 | -659.0 | -495.8 | |
| 0.00 | 1.96 | 0.00 | 1.33 | 20.00 | 303.73 | -38.55 | 58.95 | 0.6859 | -734.0 | -543.4 | |
| 0.00 | 1.02 | 0.00 | 0.75 | 25.66 | 301.75 | -40.53 | 52.91 | 0.7367 | -540.0 | -389.5 | |
| 1.36 | 4.60 | 0.92 | 3.10 | 19.02 | 303.68 | -38.59 | 60.28 | 0.6814 | -803.4 | -719.6 | |
| 0.00 | 1.87 | 0.00 | 1.27 | 19.31 | 303.44 | -38.83 | 60.03 | 0.6855 | -548.0 | -472.5 | |
| 0.00 | 0.94 | 0.00 | 0.66 | 21.45 | 301.67 | -40.61 | 58.18 | 0.7153 | -557.0 | -420.2 | |
| 0.00 | 1.79 | 0.00 | 1.23 | 18.85 | 302.36 | -39.92 | 61.22 | 0.6952 | -772.0 | -585.0 | |
| 0.00 | 1.02 | 0.00 | 0.70 | 18.97 | 302.32 | -39.95 | 61.07 | 0.6962 | -540.0 | -561.4 | |
| 0.00 | 1.19 | 0.00 | 0.83 | 19.95 | 301.86 | -40.41 | 60.02 | 0.7059 | -657.0 | -595.4 | |
| 0.00 | 0.85 | 0.00 | 0.60 | 20.27 | 301.68 | -40.60 | 59.70 | 0.7094 | -656.0 | -524.7 | |
| 0.00 | 0.94 | 0.00 | 0.65 | 18.82 | 302.08 | -40.20 | 61.40 | 0.6982 | -474.0 | -425.5 | |
| 0.00 | 0.94 | 0.00 | 0.70 | 25.38 | 299.63 | -42.65 | 54.40 | 0.7552 | -497.0 | -439.6 | |
| 0.00 | 3.06 | 0.00 | 2.07 | 16.36 | 302.62 | -39.66 | 64.48 | 0.6809 | -660.0 | -537.1 | |
| 0.00 | 1.87 | 0.00 | 1.31 | 19.70 | 301.69 | -40.58 | 60.43 | 0.7065 | -771.0 | -645.8 | |
| 0.00 | 1.45 | 0.00 | 1.01 | 19.86 | 301.52 | -40.76 | 60.31 | 0.7092 | -447.0 | -392.2 | |
| 0.00 | 2.55 | 0.00 | 1.94 | 25.78 | 299.18 | -43.10 | 54.15 | 0.7613 | -547.0 | -475.5 | |
| 0.00 | 1.45 | 0.00 | 1.00 | 18.70 | 301.75 | -40.53 | 61.73 | 0.7013 | -531.0 | -403.8 | |
| 0.00 | 1.53 | 0.00 | 1.08 | 19.96 | 300.86 | -41.42 | 60.51 | 0.7167 | -611.0 | -439.4 | |
| 0.00 | 1.87 | 0.00 | 1.37 | 21.98 | 299.69 | -42.59 | 58.53 | 0.7381 | -686.0 | -494.8 | |
| 0.00 | 1.19 | 0.00 | 0.85 | 20.10 | 300.23 | -42.05 | 60.65 | 0.7240 | -440.0 | -341.1 | |
| 0.00 | 0.85 | 0.00 | 0.69 | 26.88 | 296.37 | -45.90 | 54.26 | 0.7916 | 726.0 | 597.4 | |
| 0.00 | 0.85 | 0.00 | 0.64 | 22.44 | 298.28 | -44.00 | 58.63 | 0.7542 | -667.0 | -539.0 | |
| 0.00 | 1.36 | 0.00 | 1.03 | 23.03 | 297.95 | -44.32 | 58.07 | 0.7600 | -328.0 | -261.5 | |
| 0.00 | 1.11 | 0.00 | 0.84 | 22.64 | 298.02 | -44.25 | 58.51 | 0.7576 | -401.0 | -290.8 | |
| 0.00 | 1.28 | 0.00 | 0.97 | 23.09 | 297.74 | -44.53 | 58.09 | 0.7623 | -180.0 | -127.3 | |
| 0.00 | 2.55 | 0.00 | 1.93 | 22.29 | 297.81 | -44.47 | 59.04 | 0.7582 | 819.0 | 620.7 | |
| 0.00 | 0.94 | 0.00 | 0.77 | 26.92 | 295.63 | -46.65 | 54.55 | 0.7982 | 656.0 | 548.2 | |
| 0.00 | 0.94 | 0.00 | 0.72 | 23.26 | 296.94 | -45.33 | 58.25 | 0.7707 | 652.0 | 533.2 | |
| 0.00 | 1.45 | 0.00 | 1.17 | 25.89 | 295.55 | -46.73 | 55.77 | 0.7945 | 594.0 | 491.7 | |
| 0.00 | 1.19 | 0.00 | 0.94 | 24.37 | 296.30 | -45.98 | 57.22 | 0.7814 | 765.0 | 599.1 | |
| 0.00 | 1.45 | 0.00 | 1.12 | 22.94 | 296.71 | -45.56 | 58.74 | 0.7715 | 771.0 | 609.2 | |
| 1.45 | 4.51 | 1.12 | 3.48 | 22.59 | 296.82 | -45.46 | 59.12 | 0.7690 | 702.6 | 695.7 | |
| 0.00 | 0.94 | 0.00 | 0.74 | 24.44 | 295.94 | -46.34 | 57.29 | 0.7850 | 676.0 | 602.0 | |
| 0.00 | 0.94 | 0.00 | 0.72 | 22.33 | 296.65 | -45.62 | 59.50 | 0.7696 | 456.0 | 415.6 | |
| 0.00 | 0.85 | 0.00 | 0.67 | 23.54 | 295.70 | -46.57 | 58.47 | 0.7834 | 613.0 | 512.8 | |
| 0.00 | 2.38 | 0.00 | 1.91 | 24.00 | 295.35 | -46.93 | 58.08 | 0.7886 | 561.0 | 412.8 | |
| 0.00 | 0.85 | 0.00 | 0.68 | 22.89 | 295.39 | -46.89 | 59.37 | 0.7839 | 743.0 | 686.8 | |
| 0.00 | 0.60 | 0.00 | 0.47 | 22.60 | 295.47 | -46.81 | 59.69 | 0.7819 | 644.0 | 638.7 | |
| 0.00 | 1.11 | 0.00 | 0.89 | 23.74 | 294.90 | -47.38 | 58.57 | 0.7917 | 462.0 | 381.4 | |
| 0.00 | 1.02 | 0.00 | 0.81 | 22.45 | 295.17 | -47.11 | 60.00 | 0.7842 | 527.0 | 411.1 | |
| 0.00 | 1.28 | 0.00 | 1.09 | 26.12 | 292.85 | -49.42 | 56.65 | 0.8186 | 489.0 | 423.7 | |
| 0.00 | 0.94 | 0.00 | 0.76 | 23.10 | 294.34 | -47.94 | 59.56 | 0.7943 | 472.0 | 364.2 | |
| 0.00 | 1.36 | 0.00 | 1.10 | 22.59 | 294.39 | -47.89 | 60.15 | 0.7920 | 595.0 | 472.9 | |
| 0.00 | 0.68 | 0.00 | 0.58 | 24.94 | 292.96 | -49.31 | 57.97 | 0.8133 | 478.0 | 383.1 | |
| 0.00 | 0.60 | 0.00 | 0.52 | 25.18 | 291.65 | -50.62 | 58.19 | 0.8253 | 347.0 | 310.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
