SDO HMI 2011-12-16 16:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 53.15 | 305.46 | 32.84 | 188.48 | -18.34 | 352.15 | 32.91 | 239.81 | 0.5989 | 951.1 | 356.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-16 16:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.02 | 0.00 | 0.64 | -18.90 | 353.51 | 34.27 | 239.85 | 0.6184 | -629.0 | -524.5 | |
| 6.29 | 32.92 | 3.92 | 20.56 | -19.15 | 352.52 | 33.28 | 238.83 | 0.6080 | 765.4 | 69.9 | |
| 46.86 | 252.19 | 28.92 | 155.51 | -18.16 | 352.22 | 32.98 | 240.13 | 0.5987 | 1228.7 | 388.0 | |
| 0.00 | 2.30 | 0.00 | 1.41 | -19.95 | 351.03 | 31.78 | 236.61 | 0.5953 | 809.0 | 530.0 | |
| 0.00 | 2.13 | 0.00 | 1.31 | -19.79 | 350.99 | 31.75 | 236.82 | 0.5938 | 817.0 | 557.2 | |
| 0.00 | 0.85 | 0.00 | 0.51 | -16.73 | 350.33 | 31.09 | 241.12 | 0.5670 | -555.0 | -477.9 | |
| 0.00 | 2.38 | 0.00 | 1.46 | -19.48 | 350.81 | 31.57 | 237.15 | 0.5897 | 907.0 | 712.4 | |
| 0.00 | 1.11 | 0.00 | 0.66 | -14.78 | 349.93 | 30.69 | 244.08 | 0.5509 | -476.0 | -389.8 | |
| 0.00 | 1.19 | 0.00 | 0.73 | -20.26 | 350.76 | 31.52 | 235.94 | 0.5943 | 672.0 | 510.4 | |
| 0.00 | 1.79 | 0.00 | 1.09 | -20.01 | 350.67 | 31.43 | 236.25 | 0.5915 | 807.0 | 704.2 | |
| 0.00 | 0.77 | 0.00 | 0.47 | -19.70 | 350.60 | 31.36 | 236.67 | 0.5887 | 904.0 | 777.3 | |
| 0.00 | 3.32 | 0.00 | 2.02 | -19.42 | 350.32 | 31.08 | 236.88 | 0.5835 | 695.0 | 642.4 | |
| 0.00 | 2.38 | 0.00 | 1.45 | -19.49 | 350.08 | 30.84 | 236.60 | 0.5811 | 821.0 | 666.8 | |
| 0.00 | 1.11 | 0.00 | 0.66 | -18.50 | 349.26 | 30.02 | 237.51 | 0.5647 | -658.0 | -390.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
