SDO HMI 2011-12-16 17:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47.88 | 302.20 | 29.76 | 187.71 | -18.38 | 352.14 | 33.45 | 240.11 | 0.6057 | 1049.7 | 373.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-16 17:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.29 | 30.45 | 3.94 | 19.14 | -19.18 | 352.50 | 33.81 | 239.14 | 0.6145 | 776.8 | 60.2 | |
| 41.59 | 253.62 | 25.82 | 157.42 | -18.19 | 352.20 | 33.51 | 240.44 | 0.6053 | 1255.3 | 390.4 | |
| 0.00 | 1.02 | 0.00 | 0.63 | -19.57 | 351.31 | 32.62 | 237.78 | 0.6027 | 319.0 | 352.2 | |
| 0.00 | 1.02 | 0.00 | 0.62 | -18.17 | 350.90 | 32.21 | 239.61 | 0.5893 | 509.0 | 418.2 | |
| 0.00 | 3.57 | 0.00 | 2.21 | -19.91 | 351.02 | 32.33 | 237.06 | 0.6014 | 558.0 | 563.1 | |
| 0.00 | 1.11 | 0.00 | 0.69 | -20.22 | 351.06 | 32.37 | 236.62 | 0.6038 | 536.0 | 375.5 | |
| 0.00 | 2.21 | 0.00 | 1.36 | -19.48 | 350.81 | 32.12 | 237.56 | 0.5962 | 963.0 | 722.0 | |
| 0.00 | 0.77 | 0.00 | 0.47 | -19.91 | 350.76 | 32.07 | 236.87 | 0.5984 | 644.0 | 555.0 | |
| 0.00 | 1.28 | 0.00 | 0.78 | -19.70 | 350.60 | 31.91 | 237.08 | 0.5951 | 797.0 | 700.3 | |
| 0.00 | 1.79 | 0.00 | 1.10 | -20.07 | 350.65 | 31.96 | 236.55 | 0.5981 | 779.0 | 657.4 | |
| 0.00 | 0.68 | 0.00 | 0.42 | -19.48 | 350.44 | 31.75 | 237.29 | 0.5919 | 895.0 | 733.1 | |
| 0.00 | 3.74 | 0.00 | 2.29 | -19.45 | 350.18 | 31.49 | 237.14 | 0.5886 | 817.0 | 686.4 | |
| 0.00 | 0.94 | 0.00 | 0.58 | -21.89 | 350.68 | 31.99 | 233.91 | 0.6105 | 498.0 | 497.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
