SDO HMI 2011-12-16 19:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.53 | 84.47 | 8.97 | 55.76 | 8.37 | 357.92 | 40.34 | 284.02 | 0.6622 | -292.4 | -278.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-16 19:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.13 | 0.00 | 1.41 | 7.76 | 358.56 | 40.98 | 282.90 | 0.6690 | -42.0 | -52.1 | |
| 9.87 | 73.82 | 6.55 | 49.05 | 8.26 | 358.43 | 40.85 | 283.69 | 0.6685 | -930.9 | -398.1 | |
| 3.66 | -2.00 | 2.42 | -2.00 | 8.50 | 358.22 | 40.64 | 284.10 | 0.6665 | -1166.3 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.65 | 9.24 | 354.96 | 37.38 | 286.29 | 0.6266 | 696.0 | 537.8 | |
| 0.00 | 1.62 | 0.00 | 1.01 | 9.32 | 354.00 | 36.42 | 286.78 | 0.6142 | 743.0 | 574.5 | |
| 0.00 | 1.11 | 0.00 | 0.69 | 9.40 | 353.82 | 36.24 | 286.99 | 0.6121 | 661.0 | 533.7 | |
| 0.00 | 2.13 | 0.00 | 1.32 | 8.65 | 353.26 | 35.67 | 286.00 | 0.6020 | 742.0 | 611.4 | |
| 0.00 | 1.19 | 0.00 | 0.74 | 8.38 | 353.15 | 35.57 | 285.60 | 0.5998 | 735.0 | 528.4 | |
| 0.00 | 1.45 | 0.00 | 0.89 | 8.82 | 352.69 | 35.10 | 286.51 | 0.5950 | 715.0 | 594.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
