SDO HMI 2011-12-17 01:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.85 | 271.51 | 32.08 | 178.11 | -18.42 | 352.15 | 37.87 | 242.64 | 0.6581 | 812.4 | 377.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-17 01:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.93 | -19.16 | 354.49 | 40.21 | 242.74 | 0.6884 | -633.0 | -507.4 | |
| 0.00 | 1.02 | 0.00 | 0.69 | -19.04 | 354.17 | 39.89 | 242.76 | 0.6842 | -771.0 | -649.1 | |
| 0.77 | 229.82 | 0.51 | 150.67 | -18.47 | 352.68 | 38.40 | 242.84 | 0.6645 | 365.1 | 411.7 | |
| 6.47 | 22.46 | 4.29 | 14.93 | -19.25 | 352.57 | 38.29 | 241.69 | 0.6669 | 536.1 | 128.3 | |
| 37.18 | -3.00 | 24.39 | -3.00 | -18.26 | 352.19 | 37.91 | 242.89 | 0.6578 | 1154.9 | 999999 | |
| 0.00 | 0.60 | 0.00 | 0.39 | -19.73 | 351.08 | 36.80 | 240.20 | 0.6521 | 317.0 | 326.3 | |
| 2.81 | 3.74 | 1.83 | 2.45 | -20.04 | 351.12 | 36.85 | 239.79 | 0.6543 | 665.7 | 602.5 | |
| 0.00 | 0.68 | 0.00 | 0.44 | -17.94 | 350.55 | 36.27 | 242.50 | 0.6368 | 678.0 | 535.5 | |
| 0.00 | 1.62 | 0.00 | 1.04 | -18.37 | 350.50 | 36.22 | 241.84 | 0.6384 | 674.0 | 568.7 | |
| 0.00 | 1.02 | 0.00 | 0.66 | -19.61 | 350.77 | 36.50 | 240.20 | 0.6480 | 800.0 | 709.7 | |
| 1.62 | 2.04 | 1.06 | 1.33 | -20.51 | 350.90 | 36.63 | 239.00 | 0.6542 | 572.9 | 549.2 | |
| 0.00 | 1.87 | 0.00 | 1.21 | -19.83 | 350.64 | 36.36 | 239.81 | 0.6475 | 654.0 | 536.8 | |
| 0.00 | 2.30 | 0.00 | 1.48 | -19.64 | 350.28 | 36.00 | 239.87 | 0.6424 | 765.0 | 614.0 | |
| 0.00 | 1.96 | 0.00 | 1.24 | -17.67 | 349.72 | 35.44 | 242.44 | 0.6255 | -203.0 | -199.6 | |
| 0.00 | 1.02 | 0.00 | 0.65 | -18.38 | 349.61 | 35.34 | 241.33 | 0.6279 | -574.0 | -451.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
