SDO HMI 2011-12-17 01:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.55 | 32.78 | 5.49 | 17.09 | -17.00 | 323.57 | 9.29 | 209.37 | 0.3169 | -189.4 | -26.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-17 01:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.53 | 0.00 | 0.81 | -17.06 | 326.80 | 12.52 | 216.97 | 0.3461 | 778.0 | 616.7 | |
| 0.00 | 0.43 | 0.00 | 0.22 | -17.04 | 325.91 | 11.63 | 215.06 | 0.3371 | 497.0 | 585.8 | |
| 0.00 | 1.70 | 0.00 | 0.88 | -14.42 | 325.67 | 11.39 | 219.69 | 0.3008 | 788.0 | 552.2 | |
| 1.19 | 2.38 | 0.63 | 1.25 | -17.53 | 325.12 | 10.85 | 212.38 | 0.3366 | 942.6 | 829.8 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -17.78 | 324.92 | 10.64 | 211.49 | 0.3382 | 866.0 | 788.7 | |
| 0.00 | 1.62 | 0.00 | 0.85 | -17.62 | 324.62 | 10.35 | 211.04 | 0.3335 | 900.0 | 681.4 | |
| 0.00 | 2.55 | 0.00 | 1.34 | -18.12 | 324.59 | 10.31 | 210.17 | 0.3401 | 990.0 | 725.4 | |
| 0.00 | 1.19 | 0.00 | 0.63 | -18.49 | 324.17 | 9.89 | 208.60 | 0.3420 | 806.0 | 647.2 | |
| 5.36 | 5.62 | 2.78 | 2.91 | -15.49 | 323.67 | 9.39 | 212.33 | 0.2954 | -993.3 | -923.7 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -16.00 | 323.32 | 9.04 | 210.43 | 0.2997 | -802.0 | -617.9 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -16.49 | 322.81 | 8.54 | 208.20 | 0.3026 | -915.0 | -678.5 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -17.11 | 322.38 | 8.10 | 206.02 | 0.3082 | -959.0 | -800.9 | |
| 0.00 | 3.66 | 0.00 | 1.91 | -17.69 | 322.21 | 7.94 | 204.74 | 0.3158 | -834.0 | -721.6 | |
| 4.00 | 5.11 | 2.08 | 2.66 | -17.26 | 322.07 | 7.79 | 204.95 | 0.3084 | -1058.8 | -836.9 | |
| 0.00 | 2.30 | 0.00 | 1.20 | -18.31 | 321.40 | 7.12 | 201.69 | 0.3198 | -1058.0 | -796.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
