SDO HMI 2011-12-19 03:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.17 | 93.71 | 6.88 | 52.23 | 21.06 | 301.39 | 14.55 | 328.40 | 0.4589 | -189.7 | -129.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-19 03:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.11 | 0.00 | 0.63 | 16.61 | 310.51 | 23.68 | 308.57 | 0.4943 | 663.0 | 531.7 | |
| 0.00 | 1.96 | 0.00 | 1.13 | 19.38 | 309.86 | 23.02 | 313.72 | 0.5125 | -739.0 | -505.9 | |
| 0.00 | 1.02 | 0.00 | 0.59 | 19.41 | 309.25 | 22.41 | 314.49 | 0.5062 | -719.0 | -545.2 | |
| 0.00 | 2.13 | 0.00 | 1.21 | 18.28 | 309.02 | 22.19 | 313.03 | 0.4926 | -622.0 | -528.4 | |
| 0.00 | 1.53 | 0.00 | 0.87 | 18.46 | 308.71 | 21.88 | 313.71 | 0.4909 | -834.0 | -644.6 | |
| 0.00 | 1.36 | 0.00 | 0.77 | 18.14 | 308.33 | 21.50 | 313.69 | 0.4836 | -941.0 | -778.4 | |
| 0.00 | 1.87 | 0.00 | 1.03 | 14.51 | 307.33 | 20.50 | 308.78 | 0.4367 | -805.0 | -628.5 | |
| 0.00 | 1.96 | 0.00 | 1.07 | 14.29 | 306.89 | 20.05 | 308.97 | 0.4292 | -765.0 | -598.4 | |
| 0.00 | 1.28 | 0.00 | 0.70 | 14.54 | 306.72 | 19.88 | 309.66 | 0.4294 | -818.0 | -645.3 | |
| 12.17 | 14.97 | 6.88 | 8.47 | 19.77 | 306.94 | 20.11 | 318.01 | 0.4856 | -885.4 | -590.4 | |
| 0.00 | 1.96 | 0.00 | 1.10 | 19.86 | 306.36 | 19.52 | 318.95 | 0.4806 | -821.0 | -693.1 | |
| 0.00 | 0.85 | 0.00 | 0.47 | 16.77 | 304.40 | 17.57 | 317.05 | 0.4260 | -414.0 | -410.4 | |
| 0.00 | 1.45 | 0.00 | 0.80 | 18.86 | 304.46 | 17.62 | 320.29 | 0.4503 | -516.0 | -447.2 | |
| 0.00 | 1.45 | 0.00 | 0.80 | 18.67 | 304.04 | 17.21 | 320.65 | 0.4440 | -894.0 | -719.0 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 18.91 | 302.51 | 15.67 | 323.55 | 0.4320 | -868.0 | -768.9 | |
| 0.00 | 2.30 | 0.00 | 1.27 | 20.17 | 302.24 | 15.41 | 325.77 | 0.4453 | -773.0 | -607.1 | |
| 0.00 | 1.02 | 0.00 | 0.56 | 19.13 | 302.14 | 15.31 | 324.50 | 0.4313 | -626.0 | -573.9 | |
| 0.00 | 2.13 | 0.00 | 1.16 | 19.28 | 301.61 | 14.77 | 325.65 | 0.4284 | -880.0 | -759.0 | |
| 0.00 | 4.68 | 0.00 | 2.56 | 19.44 | 301.49 | 14.66 | 326.08 | 0.4294 | -531.0 | -645.3 | |
| 0.00 | 1.11 | 0.00 | 0.60 | 18.97 | 301.45 | 14.61 | 325.49 | 0.4230 | -972.0 | -779.0 | |
| 0.00 | 1.53 | 0.00 | 0.89 | 26.08 | 302.21 | 15.37 | 332.65 | 0.5204 | -684.0 | -532.3 | |
| 0.00 | 1.36 | 0.00 | 0.74 | 18.87 | 300.99 | 14.15 | 326.19 | 0.4176 | -949.0 | -759.3 | |
| 0.00 | 1.36 | 0.00 | 0.79 | 27.54 | 301.00 | 14.17 | 335.81 | 0.5317 | -559.0 | -473.6 | |
| 0.00 | 3.23 | 0.00 | 1.80 | 22.43 | 299.98 | 13.15 | 332.45 | 0.4566 | -504.0 | -515.0 | |
| 0.00 | 1.62 | 0.00 | 0.94 | 27.07 | 300.36 | 13.53 | 336.36 | 0.5215 | -650.0 | -537.7 | |
| 0.00 | 1.70 | 0.00 | 0.92 | 18.36 | 299.38 | 12.55 | 328.56 | 0.3970 | -890.0 | -719.2 | |
| 0.00 | 1.45 | 0.00 | 0.78 | 18.83 | 298.74 | 11.91 | 330.48 | 0.3982 | -696.0 | -476.2 | |
| 0.00 | 1.53 | 0.00 | 0.84 | 21.91 | 298.50 | 11.67 | 334.59 | 0.4391 | -638.0 | -464.4 | |
| 0.00 | 3.06 | 0.00 | 1.66 | 19.64 | 297.91 | 11.08 | 333.21 | 0.4032 | -738.0 | -580.6 | |
| 0.00 | 0.77 | 0.00 | 0.42 | 21.71 | 297.87 | 11.04 | 335.59 | 0.4321 | 879.0 | 715.4 | |
| 0.00 | 3.06 | 0.00 | 1.69 | 22.38 | 297.24 | 10.41 | 337.47 | 0.4378 | 733.0 | 607.9 | |
| 0.00 | 1.19 | 0.00 | 0.65 | 22.41 | 296.92 | 10.09 | 338.12 | 0.4363 | 614.0 | 447.2 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 22.83 | 296.72 | 9.89 | 338.88 | 0.4412 | 541.0 | 481.0 | |
| 0.00 | 1.87 | 0.00 | 1.03 | 22.41 | 296.63 | 9.79 | 338.69 | 0.4346 | 926.0 | 774.3 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 22.77 | 296.56 | 9.72 | 339.15 | 0.4393 | 669.0 | 577.4 | |
| 0.00 | 1.36 | 0.00 | 0.75 | 22.25 | 296.42 | 9.59 | 338.95 | 0.4311 | 846.0 | 716.2 | |
| 0.00 | 1.36 | 0.00 | 0.75 | 22.25 | 296.20 | 9.36 | 339.40 | 0.4298 | 915.0 | 730.8 | |
| 0.00 | 2.38 | 0.00 | 1.32 | 23.87 | 296.18 | 9.35 | 340.79 | 0.4534 | 824.0 | 675.6 | |
| 0.00 | 1.70 | 0.00 | 0.96 | 26.31 | 296.27 | 9.44 | 342.44 | 0.4892 | 823.0 | 531.8 | |
| 0.00 | 0.94 | 0.00 | 0.52 | 23.96 | 295.27 | 8.44 | 342.60 | 0.4503 | 793.0 | 674.3 | |
| 0.00 | 2.47 | 0.00 | 1.34 | 21.70 | 295.00 | 8.17 | 341.38 | 0.4152 | 904.0 | 720.1 | |
| 0.00 | 1.87 | 0.00 | 1.02 | 21.54 | 294.83 | 8.00 | 341.60 | 0.4120 | 963.0 | 829.9 | |
| 0.00 | 0.77 | 0.00 | 0.42 | 21.83 | 294.82 | 7.98 | 341.87 | 0.4162 | 815.0 | 641.4 | |
| 0.00 | 1.87 | 0.00 | 1.08 | 29.01 | 294.09 | 7.26 | 347.68 | 0.5197 | 784.0 | 594.6 | |
| 0.00 | 2.81 | 0.00 | 1.55 | 24.05 | 292.84 | 6.00 | 347.46 | 0.4418 | 764.0 | 717.8 | |
| 0.00 | 0.51 | 0.00 | 0.28 | 25.01 | 292.72 | 5.89 | 348.19 | 0.4559 | 681.0 | 560.2 | |
| 0.00 | 1.45 | 0.00 | 0.85 | 30.59 | 291.79 | 4.96 | 352.00 | 0.5368 | 874.0 | 737.1 | |
| 0.00 | 1.02 | 0.00 | 0.62 | 33.56 | 288.41 | 1.58 | 357.71 | 0.5754 | 707.0 | 542.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
