SDO HMI 2012-05-08 13:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.90 | 14.03 | 0.47 | 7.38 | 14.65 | 228.84 | 6.13 | 341.60 | 0.3319 | -445.5 | -282.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2012-05-08 13:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.25 | 0.00 | 0.67 | 13.88 | 235.66 | 12.95 | 323.54 | 0.3678 | -654.0 | -487.4 | |
| 0.00 | 0.98 | 0.00 | 0.52 | 12.96 | 235.58 | 12.87 | 322.14 | 0.3552 | -721.0 | -633.4 | |
| 0.90 | 2.95 | 0.47 | 1.54 | 13.69 | 229.67 | 6.96 | 338.06 | 0.3166 | -1092.5 | -896.7 | |
| 0.00 | 1.97 | 0.00 | 1.03 | 13.62 | 229.36 | 6.65 | 338.88 | 0.3137 | -791.0 | -703.9 | |
| 0.00 | 1.16 | 0.00 | 0.61 | 15.33 | 227.64 | 4.93 | 345.46 | 0.3319 | -840.0 | -679.8 | |
| 0.00 | 1.61 | 0.00 | 0.84 | 14.98 | 227.23 | 4.52 | 346.38 | 0.3246 | -934.0 | -794.3 | |
| 0.00 | 2.77 | 0.00 | 1.46 | 15.86 | 225.67 | 2.96 | 351.41 | 0.3340 | 1042.0 | 731.8 | |
| 0.00 | 1.34 | 0.00 | 0.71 | 16.70 | 224.36 | 1.65 | 355.41 | 0.3452 | 731.0 | 575.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
