SDO HMI 2012-05-08 14:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.06 | 8.94 | 1.08 | 4.69 | 14.67 | 227.84 | 5.68 | 342.63 | 0.3264 | -397.3 | -101.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2012-05-08 14:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.06 | 2.77 | 1.08 | 1.45 | 13.72 | 229.69 | 7.53 | 336.51 | 0.3208 | -893.4 | -984.2 | |
| 0.00 | 1.52 | 0.00 | 0.79 | 13.63 | 229.40 | 7.25 | 337.18 | 0.3175 | -821.0 | -535.5 | |
| 0.00 | 1.79 | 0.00 | 0.94 | 15.01 | 227.21 | 5.05 | 344.86 | 0.3273 | -872.0 | -756.0 | |
| 0.00 | 2.86 | 0.00 | 1.51 | 15.90 | 225.63 | 3.47 | 349.98 | 0.3359 | 1037.0 | 755.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
