SDO HMI 2012-10-16 09:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 103.02 | 535.37 | 57.34 | 298.14 | 7.23 | 229.25 | -27.23 | 85.31 | 0.4572 | -676.2 | -334.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2012-10-16 09:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.87 | 0.00 | 0.47 | 4.97 | 234.34 | -22.14 | 90.91 | 0.3771 | -616.0 | -421.5 | |
| 69.15 | 394.83 | 38.18 | 218.12 | 7.40 | 230.13 | -26.35 | 84.88 | 0.4437 | -1254.5 | -375.7 | |
| 0.00 | 1.48 | 0.00 | 0.82 | 5.40 | 230.21 | -26.27 | 89.41 | 0.4425 | 780.0 | 585.2 | |
| 1.31 | 4.19 | 0.73 | 2.35 | 5.80 | 228.40 | -28.08 | 88.42 | 0.4704 | 560.5 | 293.3 | |
| 0.00 | 0.87 | 0.00 | 0.49 | 3.94 | 228.31 | -28.17 | 92.36 | 0.4733 | 675.0 | 515.6 | |
| 10.83 | 20.34 | 6.09 | 11.44 | 5.07 | 228.16 | -28.32 | 89.95 | 0.4745 | -969.4 | -653.6 | |
| 3.06 | 49.51 | 1.73 | 28.01 | 6.66 | 227.53 | -28.95 | 86.60 | 0.4837 | -941.0 | -492.0 | |
| 1.48 | 3.67 | 0.84 | 2.07 | 4.99 | 227.62 | -28.86 | 90.08 | 0.4829 | -645.4 | -609.8 | |
| 0.00 | 0.96 | 0.00 | 0.54 | 9.43 | 227.28 | -29.20 | 80.90 | 0.4894 | -582.0 | -520.8 | |
| 0.00 | 1.05 | 0.00 | 0.59 | 7.58 | 227.43 | -29.05 | 84.69 | 0.4854 | -692.0 | -587.2 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 8.03 | 227.36 | -29.12 | 83.77 | 0.4867 | -670.0 | -569.4 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 9.25 | 227.26 | -29.22 | 81.27 | 0.4895 | -517.0 | -474.4 | |
| 4.19 | -7.00 | 2.37 | -7.00 | 6.32 | 227.41 | -29.07 | 87.29 | 0.4855 | -938.4 | 999999 | |
| 1.48 | -7.00 | 0.84 | -7.00 | 6.08 | 227.35 | -29.13 | 87.79 | 0.4863 | -763.6 | 999999 | |
| 6.11 | -7.00 | 3.46 | -7.00 | 6.92 | 227.27 | -29.21 | 86.07 | 0.4876 | -885.4 | 999999 | |
| 0.00 | 3.75 | 0.00 | 2.13 | 8.35 | 227.09 | -29.39 | 83.15 | 0.4910 | 112.0 | -11.3 | |
| 0.00 | 2.01 | 0.00 | 1.14 | 4.60 | 227.09 | -29.39 | 90.81 | 0.4913 | -748.0 | -581.9 | |
| 1.66 | 7.86 | 0.94 | 4.47 | 7.23 | 226.87 | -29.61 | 85.45 | 0.4938 | -749.3 | -631.7 | |
| 0.00 | 1.31 | 0.00 | 0.75 | 8.45 | 226.77 | -29.71 | 82.98 | 0.4959 | 526.0 | 496.2 | |
| 0.00 | 1.48 | 0.00 | 0.85 | 8.60 | 226.69 | -29.79 | 82.69 | 0.4973 | 613.0 | 478.5 | |
| 0.00 | 1.22 | 0.00 | 0.70 | 6.22 | 226.45 | -30.03 | 87.49 | 0.5001 | -621.0 | -491.1 | |
| 0.00 | 1.05 | 0.00 | 0.60 | 6.63 | 226.35 | -30.13 | 86.66 | 0.5015 | -647.0 | -465.9 | |
| 0.00 | 3.41 | 0.00 | 1.95 | 7.14 | 226.28 | -30.20 | 85.65 | 0.5026 | -804.0 | -589.4 | |
| 0.00 | 2.44 | 0.00 | 1.40 | 8.54 | 226.13 | -30.35 | 82.87 | 0.5055 | 832.0 | 623.0 | |
| 0.00 | 1.31 | 0.00 | 0.75 | 8.98 | 226.02 | -30.45 | 82.00 | 0.5076 | 863.0 | 722.7 | |
| 0.00 | 1.31 | 0.00 | 0.75 | 8.83 | 225.97 | -30.51 | 82.31 | 0.5083 | 904.0 | 776.9 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 9.27 | 225.86 | -30.62 | 81.45 | 0.5104 | 598.0 | 546.6 | |
| 1.83 | 4.45 | 1.05 | 2.56 | 7.12 | 226.00 | -30.48 | 85.68 | 0.5068 | -635.4 | -481.3 | |
| 0.00 | 2.44 | 0.00 | 1.41 | 8.56 | 225.89 | -30.59 | 82.86 | 0.5092 | 947.0 | 750.1 | |
| 0.00 | 1.66 | 0.00 | 0.96 | 10.20 | 225.13 | -31.35 | 79.79 | 0.5224 | 621.0 | 502.2 | |
| 1.92 | 9.43 | 1.11 | 5.45 | 7.39 | 225.31 | -31.17 | 85.19 | 0.5171 | -573.5 | -152.2 | |
| 0.00 | 1.05 | 0.00 | 0.61 | 6.91 | 225.35 | -31.13 | 86.11 | 0.5165 | -415.0 | -300.0 | |
| 0.00 | 1.22 | 0.00 | 0.72 | 8.29 | 223.67 | -32.81 | 83.57 | 0.5417 | 715.0 | 573.2 | |
| 0.00 | 1.05 | 0.00 | 0.62 | 8.43 | 223.44 | -33.04 | 83.33 | 0.5451 | 694.0 | 549.0 | |
| 0.00 | 1.57 | 0.00 | 0.93 | 6.26 | 223.22 | -33.26 | 87.32 | 0.5478 | 744.0 | 651.7 | |
| 0.00 | 1.57 | 0.00 | 0.94 | 6.62 | 222.11 | -34.37 | 86.65 | 0.5639 | 675.0 | 560.8 | |
| 0.00 | 1.22 | 0.00 | 0.74 | 9.73 | 220.88 | -35.60 | 81.26 | 0.5827 | 577.0 | 502.1 | |
| 0.00 | 0.96 | 0.00 | 0.58 | 7.21 | 220.81 | -35.67 | 85.62 | 0.5824 | 593.0 | 448.2 | |
| 0.00 | 0.87 | 0.00 | 0.54 | 8.56 | 219.32 | -37.16 | 83.37 | 0.6036 | 633.0 | 510.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
