SDO HMI 2013-01-06 09:58:54 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.42 | 307.82 | 23.05 | 163.77 | -24.26 | 250.47 | -5.27 | 166.72 | 0.3646 | 610.6 | 344.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-01-06 09:58:54 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.42 | 288.81 | 23.05 | 153.46 | -24.27 | 250.93 | -4.81 | 167.75 | 0.3621 | 1496.7 | 425.4 | |
| 0.00 | 0.93 | 0.00 | 0.50 | -23.07 | 246.07 | -9.68 | 155.10 | 0.3689 | -798.0 | -675.5 | |
| 0.00 | 0.93 | 0.00 | 0.50 | -24.22 | 245.58 | -10.16 | 155.45 | 0.3889 | -614.0 | -484.3 | |
| 0.00 | 1.36 | 0.00 | 0.73 | -24.03 | 245.43 | -10.31 | 154.91 | 0.3871 | -859.0 | -721.6 | |
| 0.00 | 1.02 | 0.00 | 0.55 | -23.69 | 245.40 | -10.35 | 154.41 | 0.3824 | -961.0 | -698.1 | |
| 0.00 | 1.78 | 0.00 | 0.95 | -23.30 | 244.94 | -10.80 | 152.95 | 0.3803 | -1008.0 | -830.8 | |
| 0.00 | 0.85 | 0.00 | 0.46 | -23.68 | 244.81 | -10.93 | 153.17 | 0.3865 | -950.0 | -775.6 | |
| 0.00 | 1.36 | 0.00 | 0.73 | -23.24 | 244.75 | -11.00 | 152.47 | 0.3808 | -1000.0 | -825.4 | |
| 0.00 | 0.93 | 0.00 | 0.50 | -22.61 | 244.57 | -11.17 | 151.24 | 0.3734 | -920.0 | -726.3 | |
| 0.00 | 1.87 | 0.00 | 1.00 | -23.30 | 244.51 | -11.23 | 152.06 | 0.3834 | -853.0 | -778.0 | |
| 0.00 | 1.19 | 0.00 | 0.64 | -23.27 | 244.32 | -11.42 | 151.62 | 0.3844 | -836.0 | -690.5 | |
| 0.00 | 1.19 | 0.00 | 0.64 | -23.61 | 243.96 | -11.78 | 151.34 | 0.3919 | -817.0 | -629.4 | |
| 0.00 | 1.27 | 0.00 | 0.68 | -21.05 | 241.49 | -14.25 | 142.61 | 0.3800 | -814.0 | -670.7 | |
| 0.00 | 1.44 | 0.00 | 0.78 | -21.79 | 241.25 | -14.49 | 143.41 | 0.3915 | -635.0 | -548.6 | |
| 0.00 | 2.89 | 0.00 | 1.65 | -29.38 | 239.99 | -15.76 | 151.51 | 0.4982 | -813.0 | -584.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
