SDO HMI 2013-01-09 13:58:54 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.02 | 220.61 | 23.39 | 142.82 | -24.61 | 249.71 | 35.66 | 235.49 | 0.6453 | 622.9 | 241.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-01-09 13:58:54 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.10 | 0.00 | 0.73 | -18.20 | 253.82 | 39.78 | 246.78 | 0.6637 | -640.0 | -478.5 | |
| 0.00 | 1.44 | 0.00 | 0.96 | -22.10 | 252.96 | 38.91 | 240.82 | 0.6690 | -667.0 | -604.1 | |
| 36.02 | 206.45 | 23.39 | 134.14 | -24.70 | 250.01 | 35.96 | 235.58 | 0.6491 | 1191.4 | 302.4 | |
| 0.00 | 0.93 | 0.00 | 0.58 | -25.54 | 246.06 | 32.02 | 231.77 | 0.6112 | -716.0 | -591.5 | |
| 0.00 | 1.02 | 0.00 | 0.63 | -23.91 | 245.41 | 31.36 | 233.66 | 0.5929 | -339.0 | -456.4 | |
| 0.00 | 0.59 | 0.00 | 0.37 | -25.68 | 245.60 | 31.56 | 231.23 | 0.6073 | -584.0 | -504.3 | |
| 0.00 | 0.85 | 0.00 | 0.51 | -22.49 | 243.89 | 29.85 | 234.68 | 0.5657 | -438.0 | -477.6 | |
| 0.00 | 1.53 | 0.00 | 0.91 | -22.29 | 243.29 | 29.25 | 234.53 | 0.5573 | -805.0 | -690.3 | |
| 0.00 | 1.70 | 0.00 | 1.00 | -21.49 | 242.93 | 28.89 | 235.51 | 0.5475 | -236.0 | -272.8 | |
| 0.00 | 2.63 | 0.00 | 1.57 | -22.55 | 243.10 | 29.05 | 233.96 | 0.5568 | -762.0 | -659.6 | |
| 0.00 | 1.10 | 0.00 | 0.66 | -25.58 | 241.73 | 27.69 | 228.17 | 0.5647 | -672.0 | -492.9 | |
| 0.00 | 1.27 | 0.00 | 0.76 | -28.99 | 238.56 | 24.51 | 220.29 | 0.5634 | -588.0 | -529.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
