SDO HMI 2013-02-21 02:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 153.16 | 778.30 | 144.11 | 740.69 | 10.14 | 70.16 | 56.30 | 286.52 | 0.8546 | 13.7 | -26.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-02-21 02:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.55 | 379.70 | 4.86 | 395.51 | 10.14 | 74.06 | 60.20 | 285.38 | 0.8878 | 159.5 | -218.8 | |
| 60.16 | -1.00 | 62.75 | -1.00 | 10.03 | 73.30 | 59.44 | 285.46 | 0.8817 | -717.4 | 999999 | |
| 0.00 | 1.03 | 0.00 | 1.03 | 11.28 | 71.42 | 57.56 | 287.37 | 0.8692 | 298.0 | 248.0 | |
| 2.15 | 13.24 | 2.06 | 12.58 | 10.81 | 70.22 | 56.35 | 287.20 | 0.8580 | -543.5 | -460.0 | |
| 0.00 | 1.72 | 0.00 | 1.63 | 10.47 | 69.90 | 56.04 | 286.91 | 0.8545 | -266.0 | -244.1 | |
| 1.98 | 3.18 | 1.83 | 2.95 | 9.55 | 69.34 | 55.47 | 286.03 | 0.8474 | 214.0 | 151.9 | |
| 0.00 | 1.20 | 0.00 | 1.13 | 10.15 | 69.49 | 55.63 | 286.67 | 0.8502 | -360.0 | -255.1 | |
| 0.00 | 1.38 | 0.00 | 1.29 | 10.61 | 69.45 | 55.59 | 287.20 | 0.8510 | -338.0 | -291.2 | |
| 0.00 | 1.29 | 0.00 | 1.20 | 10.73 | 69.11 | 55.25 | 287.44 | 0.8483 | -377.0 | -339.2 | |
| 0.00 | 1.20 | 0.00 | 1.12 | 10.88 | 69.10 | 55.24 | 287.62 | 0.8486 | -294.0 | -281.4 | |
| 0.00 | 2.23 | 0.00 | 2.04 | 9.83 | 68.77 | 54.90 | 286.52 | 0.8430 | -413.0 | -359.8 | |
| 0.43 | 8.59 | 0.40 | 7.92 | 11.21 | 68.67 | 54.80 | 288.13 | 0.8456 | -597.0 | -454.0 | |
| 1.38 | 344.20 | 1.22 | 295.62 | 9.80 | 67.62 | 53.75 | 286.85 | 0.8325 | -404.0 | 272.9 | |
| 14.35 | -13.00 | 12.74 | -13.00 | 10.03 | 67.47 | 53.61 | 287.16 | 0.8318 | 377.8 | 999999 | |
| 0.00 | 1.72 | 0.00 | 1.54 | 11.92 | 67.41 | 53.55 | 289.35 | 0.8363 | 371.0 | 262.7 | |
| 0.00 | 1.03 | 0.00 | 0.88 | 8.44 | 66.27 | 52.40 | 285.67 | 0.8162 | 405.0 | 360.5 | |
| 18.48 | -13.00 | 16.07 | -13.00 | 10.22 | 66.61 | 52.74 | 287.67 | 0.8242 | 495.1 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.91 | 11.05 | 66.82 | 52.95 | 288.56 | 0.8285 | 255.0 | 210.9 | |
| 2.58 | -13.00 | 2.22 | -13.00 | 9.71 | 66.39 | 52.52 | 287.14 | 0.8208 | 525.2 | 999999 | |
| 0.69 | 2.06 | 0.61 | 1.82 | 11.54 | 66.80 | 52.93 | 289.13 | 0.8297 | 188.1 | 151.3 | |
| 0.69 | -13.00 | 0.59 | -13.00 | 10.02 | 66.36 | 52.49 | 287.50 | 0.8213 | -251.5 | 999999 | |
| 1.29 | -13.00 | 1.10 | -13.00 | 8.94 | 66.02 | 52.16 | 286.34 | 0.8152 | 454.5 | 999999 | |
| 0.00 | 3.01 | 0.00 | 2.64 | 11.27 | 66.57 | 52.71 | 288.90 | 0.8269 | 369.0 | 289.5 | |
| 7.31 | -13.00 | 6.24 | -13.00 | 9.46 | 66.09 | 52.22 | 286.95 | 0.8172 | 787.2 | 999999 | |
| 0.34 | 1.63 | 0.30 | 1.42 | 11.31 | 66.28 | 52.42 | 289.04 | 0.8242 | 423.8 | 311.0 | |
| 0.00 | 1.20 | 0.00 | 1.03 | 9.78 | 65.86 | 51.99 | 287.39 | 0.8159 | 443.0 | 497.0 | |
| 0.00 | 0.86 | 0.00 | 0.75 | 12.44 | 66.10 | 52.23 | 290.42 | 0.8259 | 257.0 | 225.9 | |
| 0.60 | 2.58 | 0.50 | 2.15 | 9.13 | 65.13 | 51.27 | 286.86 | 0.8070 | 700.7 | 674.8 | |
| 0.00 | 0.26 | 0.00 | 0.22 | 11.62 | 65.72 | 51.86 | 289.60 | 0.8199 | 220.0 | 181.0 | |
| 0.00 | 2.15 | 0.00 | 1.84 | 11.40 | 65.66 | 51.80 | 289.36 | 0.8187 | 401.0 | 326.3 | |
| 36.18 | -13.00 | 30.62 | -13.00 | 10.44 | 65.38 | 51.51 | 288.34 | 0.8132 | 859.4 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.91 | 9.48 | 63.68 | 49.82 | 287.78 | 0.7937 | 468.0 | 379.8 | |
| 0.00 | 0.69 | 0.00 | 0.56 | 11.24 | 63.09 | 49.22 | 290.13 | 0.7933 | 562.0 | 458.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
