SDO HMI 2013-06-22 14:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.51 | 60.26 | 12.68 | 43.62 | -14.80 | 253.38 | 44.21 | 247.56 | 0.7317 | 858.5 | 473.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-06-22 14:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.26 | 59.17 | 3.82 | 42.85 | -15.05 | 253.49 | 44.32 | 247.28 | 0.7338 | 762.4 | 470.4 | |
| 10.71 | -1.00 | 7.75 | -1.00 | -14.66 | 253.39 | 44.22 | 247.74 | 0.7314 | 931.8 | 999999 | |
| 1.54 | -1.00 | 1.11 | -1.00 | -15.04 | 253.14 | 43.97 | 247.15 | 0.7299 | 832.5 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.77 | -14.19 | 252.23 | 43.06 | 247.91 | 0.7167 | 687.0 | 586.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
