SDO HMI 2013-08-17 21:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.72 | 220.94 | 26.67 | 160.76 | -7.07 | 139.38 | -45.06 | 106.27 | 0.7341 | 865.3 | 290.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-17 21:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.26 | 0.00 | 0.89 | -8.63 | 141.48 | -42.96 | 109.18 | 0.7157 | 689.0 | 591.2 | |
| 0.00 | 1.53 | 0.00 | 1.11 | -9.95 | 140.38 | -44.06 | 110.43 | 0.7333 | -479.0 | -409.6 | |
| 0.00 | 0.54 | 0.00 | 0.39 | -9.08 | 140.22 | -44.22 | 109.23 | 0.7317 | 379.0 | 400.8 | |
| 36.72 | 215.63 | 26.67 | 156.79 | -6.99 | 139.39 | -45.05 | 106.17 | 0.7337 | 1047.9 | 303.4 | |
| 0.00 | 1.26 | 0.00 | 1.02 | -14.06 | 135.93 | -48.52 | 113.58 | 0.7951 | -555.0 | -435.7 | |
| 0.00 | 0.72 | 0.00 | 0.56 | -6.98 | 135.57 | -48.87 | 104.82 | 0.7756 | -578.0 | -496.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
