SDO HMI 2013-08-18 02:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.61 | 232.22 | 28.15 | 161.30 | -7.06 | 139.36 | -42.33 | 107.36 | 0.7025 | 874.8 | 314.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-18 02:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.54 | 2.61 | 0.36 | 1.76 | -8.83 | 141.69 | -40.00 | 110.85 | 0.6820 | 722.8 | 522.1 | |
| 0.00 | 1.08 | 0.00 | 0.75 | -9.69 | 139.93 | -41.76 | 111.16 | 0.7063 | 487.0 | 334.2 | |
| 0.00 | 0.99 | 0.00 | 0.69 | -9.35 | 139.86 | -41.83 | 110.67 | 0.7057 | 602.0 | 498.4 | |
| 0.81 | 225.02 | 0.56 | 156.17 | -7.54 | 139.40 | -42.29 | 108.02 | 0.7038 | 769.9 | 322.1 | |
| 38.09 | -4.00 | 26.41 | -4.00 | -6.94 | 139.39 | -42.30 | 107.21 | 0.7017 | 1084.2 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.71 | -9.82 | 138.70 | -42.99 | 110.76 | 0.7209 | -510.0 | -440.1 | |
| 1.17 | -4.00 | 0.82 | -4.00 | -7.23 | 138.90 | -42.79 | 107.40 | 0.7086 | 281.5 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.62 | -14.17 | 135.95 | -45.74 | 114.95 | 0.7682 | -574.0 | -469.0 | |
| 0.00 | 0.72 | 0.00 | 0.60 | -12.37 | 131.70 | -49.99 | 110.99 | 0.8035 | -410.0 | -348.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
