SDO HMI 2013-08-18 10:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.16 | 250.67 | 26.09 | 163.06 | -7.04 | 139.34 | -37.96 | 109.34 | 0.6494 | 708.2 | 291.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-18 10:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.44 | 0.00 | 0.91 | -8.89 | 142.00 | -35.31 | 113.55 | 0.6251 | 788.0 | 579.2 | |
| 0.45 | 1.62 | 0.29 | 1.04 | -9.23 | 140.82 | -36.49 | 113.32 | 0.6415 | -743.2 | -685.8 | |
| 0.36 | 1.89 | 0.24 | 1.23 | -9.66 | 140.03 | -37.28 | 113.49 | 0.6533 | 725.2 | 620.9 | |
| 0.00 | 0.72 | 0.00 | 0.47 | -10.08 | 139.93 | -37.37 | 114.02 | 0.6566 | 454.0 | 311.4 | |
| 38.72 | 237.17 | 25.14 | 154.12 | -6.92 | 139.37 | -37.93 | 109.18 | 0.6484 | 1031.5 | 311.9 | |
| 0.63 | 1.71 | 0.42 | 1.14 | -9.52 | 138.52 | -38.79 | 112.45 | 0.6707 | -758.9 | -633.2 | |
| 0.00 | 0.72 | 0.00 | 0.53 | -18.84 | 136.48 | -40.82 | 123.23 | 0.7419 | 455.0 | 402.8 | |
| 0.00 | 1.62 | 0.00 | 1.08 | -9.57 | 138.27 | -39.03 | 112.38 | 0.6739 | -651.0 | -480.0 | |
| 0.00 | 0.81 | 0.00 | 0.54 | -6.15 | 137.60 | -39.71 | 107.22 | 0.6673 | 380.0 | 306.3 | |
| 0.00 | 1.53 | 0.00 | 1.03 | -6.88 | 137.01 | -40.30 | 107.99 | 0.6774 | -186.0 | -107.5 | |
| 0.00 | 1.44 | 0.00 | 0.97 | -6.51 | 136.56 | -40.75 | 107.27 | 0.6814 | -475.0 | -423.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
