SDO HMI 2013-08-19 00:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 49.85 | 303.53 | 29.60 | 180.30 | -6.99 | 139.04 | -30.53 | 113.81 | 0.5533 | 761.4 | 302.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-19 00:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.54 | 1.62 | 0.32 | 0.96 | -9.93 | 140.51 | -29.06 | 119.77 | 0.5534 | 837.7 | 649.8 | |
| 43.37 | 273.29 | 25.66 | 161.70 | -6.86 | 139.36 | -30.21 | 113.83 | 0.5483 | 1238.4 | 376.9 | |
| 0.00 | 1.80 | 0.00 | 1.09 | -10.33 | 138.58 | -31.00 | 118.79 | 0.5803 | -939.0 | -741.3 | |
| 0.81 | -2.00 | 0.48 | -2.00 | -6.71 | 138.77 | -30.81 | 113.15 | 0.5553 | 611.8 | 999999 | |
| 0.99 | 2.25 | 0.59 | 1.35 | -6.86 | 137.86 | -31.71 | 112.77 | 0.5682 | 711.7 | 537.5 | |
| 0.00 | 0.72 | 0.00 | 0.46 | -13.98 | 136.61 | -32.96 | 122.53 | 0.6285 | -695.0 | -575.8 | |
| 0.00 | 0.63 | 0.00 | 0.40 | -14.18 | 136.46 | -33.11 | 122.70 | 0.6316 | -633.0 | -546.1 | |
| 0.00 | 1.62 | 0.00 | 0.98 | -6.46 | 136.80 | -32.77 | 111.44 | 0.5799 | 715.0 | 537.3 | |
| 0.00 | 1.35 | 0.00 | 0.87 | -14.24 | 135.66 | -33.91 | 122.16 | 0.6410 | -608.0 | -475.5 | |
| 0.00 | 0.90 | 0.00 | 0.55 | -6.86 | 136.48 | -33.09 | 111.86 | 0.5863 | 313.0 | 234.3 | |
| 4.14 | 18.27 | 2.55 | 11.24 | -7.05 | 135.84 | -33.73 | 111.78 | 0.5956 | -933.5 | -575.7 | |
| 0.00 | 1.08 | 0.00 | 0.70 | -11.18 | 134.03 | -35.55 | 116.75 | 0.6409 | -594.0 | -512.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
