SDO HMI 2013-08-19 11:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 46.80 | 336.86 | 26.25 | 189.39 | -7.24 | 139.11 | -24.43 | 119.51 | 0.4738 | 461.1 | 291.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-19 11:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.62 | 3.51 | 0.91 | 1.96 | -9.62 | 141.13 | -22.40 | 126.13 | 0.4672 | 817.3 | 654.3 | |
| 0.00 | 3.78 | 0.00 | 2.12 | -9.98 | 140.91 | -22.63 | 126.48 | 0.4732 | 660.0 | 546.5 | |
| 0.00 | 3.87 | 0.00 | 2.17 | -9.48 | 140.74 | -22.79 | 125.41 | 0.4708 | 573.0 | 481.9 | |
| 42.03 | 286.73 | 23.53 | 160.57 | -6.85 | 139.34 | -24.20 | 119.06 | 0.4675 | 1173.5 | 368.8 | |
| 0.00 | 1.17 | 0.00 | 0.67 | -10.58 | 138.97 | -24.57 | 125.23 | 0.5023 | -567.0 | -419.4 | |
| 0.99 | 6.48 | 0.57 | 3.70 | -10.26 | 138.97 | -24.57 | 124.70 | 0.4997 | -925.8 | -712.1 | |
| 0.00 | 1.44 | 0.00 | 0.82 | -10.14 | 138.77 | -24.77 | 124.29 | 0.5011 | -403.0 | -557.8 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -4.97 | 138.93 | -24.61 | 115.04 | 0.4598 | -718.0 | -561.5 | |
| 0.00 | 1.71 | 0.00 | 1.01 | -13.22 | 137.33 | -26.21 | 127.59 | 0.5447 | -865.0 | -688.7 | |
| 0.00 | 0.45 | 0.00 | 0.28 | -18.10 | 136.31 | -27.23 | 133.24 | 0.5992 | 611.0 | 550.4 | |
| 0.00 | 0.27 | 0.00 | 0.16 | -14.74 | 136.79 | -26.75 | 129.23 | 0.5641 | -512.0 | -597.3 | |
| 0.00 | 1.35 | 0.00 | 0.80 | -13.41 | 136.82 | -26.72 | 127.34 | 0.5523 | -857.0 | -704.3 | |
| 0.00 | 2.70 | 0.00 | 1.54 | -6.52 | 137.16 | -26.38 | 116.36 | 0.4946 | 768.0 | 670.4 | |
| 0.00 | 1.80 | 0.00 | 1.08 | -14.51 | 136.29 | -27.25 | 128.39 | 0.5677 | -711.0 | -626.1 | |
| 0.00 | 0.81 | 0.00 | 0.46 | -7.78 | 136.94 | -26.60 | 118.40 | 0.5063 | 679.0 | 558.4 | |
| 0.00 | 1.53 | 0.00 | 0.88 | -8.11 | 136.78 | -26.76 | 118.81 | 0.5107 | -836.0 | -650.8 | |
| 0.00 | 0.90 | 0.00 | 0.54 | -14.40 | 135.95 | -27.59 | 127.89 | 0.5705 | -613.0 | -501.0 | |
| 2.16 | 6.66 | 1.24 | 3.82 | -7.03 | 136.48 | -27.06 | 116.65 | 0.5072 | 469.9 | 264.6 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -6.62 | 136.50 | -27.03 | 115.95 | 0.5041 | 639.0 | 489.8 | |
| 0.00 | 0.99 | 0.00 | 0.57 | -6.35 | 136.38 | -27.16 | 115.36 | 0.5040 | 685.0 | 549.2 | |
| 0.00 | 1.26 | 0.00 | 0.80 | -19.34 | 134.44 | -29.10 | 132.94 | 0.6290 | 351.0 | 358.4 | |
| 0.00 | 0.81 | 0.00 | 0.47 | -6.49 | 136.03 | -27.51 | 115.32 | 0.5097 | -725.0 | -672.4 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -7.53 | 135.93 | -27.61 | 117.05 | 0.5179 | -908.0 | -710.5 | |
| 0.00 | 1.80 | 0.00 | 1.04 | -8.09 | 135.89 | -27.65 | 117.98 | 0.5224 | -762.0 | -613.4 | |
| 0.00 | 1.80 | 0.00 | 1.04 | -6.91 | 135.87 | -27.67 | 115.91 | 0.5146 | -915.0 | -750.0 | |
| 0.00 | 1.26 | 0.00 | 0.73 | -7.85 | 135.17 | -28.36 | 116.96 | 0.5300 | -628.0 | -499.8 | |
| 0.00 | 0.99 | 0.00 | 0.57 | -3.50 | 134.10 | -29.44 | 108.49 | 0.5194 | -647.0 | -505.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
