SDO HMI 2013-08-20 01:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.34 | 355.10 | 33.78 | 189.48 | -7.17 | 139.19 | -16.62 | 129.89 | 0.3720 | 674.1 | 355.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-20 01:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.93 | 11.52 | 3.69 | 6.14 | -9.67 | 141.84 | -13.97 | 139.77 | 0.3700 | 979.1 | 250.7 | |
| 0.00 | 1.80 | 0.00 | 0.96 | -9.42 | 141.69 | -14.12 | 139.03 | 0.3685 | 979.0 | 647.8 | |
| 0.00 | 1.17 | 0.00 | 0.62 | -4.88 | 139.89 | -15.92 | 126.09 | 0.3397 | -699.0 | -600.8 | |
| 2.70 | 4.23 | 1.46 | 2.29 | -10.89 | 139.44 | -16.36 | 137.35 | 0.4101 | -1011.2 | -808.1 | |
| 49.12 | 305.33 | 26.14 | 162.50 | -6.80 | 139.32 | -16.49 | 129.40 | 0.3663 | 1375.2 | 414.0 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -12.68 | 138.55 | -17.26 | 138.70 | 0.4403 | -644.0 | -518.7 | |
| 0.00 | 1.35 | 0.00 | 0.72 | -4.78 | 138.36 | -17.44 | 123.34 | 0.3591 | -747.0 | -557.1 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -13.53 | 137.41 | -18.40 | 138.15 | 0.4619 | -818.0 | -656.2 | |
| 0.00 | 1.44 | 0.00 | 0.78 | -8.05 | 137.44 | -18.37 | 128.88 | 0.4025 | 800.0 | 550.7 | |
| 0.00 | 2.79 | 0.00 | 1.51 | -7.90 | 137.31 | -18.49 | 128.39 | 0.4025 | 793.0 | 640.2 | |
| 2.34 | 5.49 | 1.27 | 2.98 | -8.88 | 137.23 | -18.57 | 130.14 | 0.4134 | -1052.4 | -730.9 | |
| 0.00 | 0.27 | 0.00 | 0.15 | -13.42 | 136.92 | -18.89 | 137.25 | 0.4657 | -654.0 | -571.3 | |
| 0.00 | 1.17 | 0.00 | 0.66 | -14.24 | 136.72 | -19.09 | 138.14 | 0.4770 | -774.0 | -589.1 | |
| 0.00 | 1.80 | 0.00 | 1.01 | -13.85 | 136.72 | -19.09 | 137.58 | 0.4726 | -885.0 | -769.0 | |
| 0.00 | 1.35 | 0.00 | 0.73 | -5.83 | 136.76 | -19.05 | 123.32 | 0.3902 | -819.0 | -639.0 | |
| 0.00 | 0.99 | 0.00 | 0.53 | -6.80 | 136.62 | -19.19 | 125.16 | 0.4008 | 729.0 | 656.7 | |
| 0.00 | 1.71 | 0.00 | 0.92 | -7.11 | 136.61 | -19.20 | 125.78 | 0.4039 | 699.0 | 510.5 | |
| 0.00 | 1.53 | 0.00 | 0.90 | -18.81 | 135.59 | -20.22 | 142.50 | 0.5396 | 655.0 | 616.2 | |
| 2.25 | 5.40 | 1.22 | 2.92 | -6.90 | 136.42 | -19.38 | 125.09 | 0.4044 | 741.2 | 550.5 | |
| 0.00 | 1.26 | 0.00 | 0.68 | -7.30 | 135.98 | -19.82 | 125.26 | 0.4137 | -785.0 | -596.6 | |
| 0.00 | 1.26 | 0.00 | 0.68 | -5.93 | 135.94 | -19.86 | 122.41 | 0.4020 | -579.0 | -382.0 | |
| 0.00 | 1.26 | 0.00 | 0.70 | -11.25 | 135.05 | -20.76 | 131.12 | 0.4633 | -671.0 | -531.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
