SDO HMI 2013-08-23 17:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.47 | 252.56 | 25.73 | 152.94 | -7.05 | 139.65 | 32.28 | 247.10 | 0.5777 | 1024.7 | 361.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-08-23 17:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.47 | 247.88 | 25.73 | 150.18 | -7.03 | 139.71 | 32.34 | 247.17 | 0.5783 | 1245.0 | 376.4 | |
| 0.00 | 1.17 | 0.00 | 0.69 | -7.19 | 137.43 | 30.07 | 245.29 | 0.5493 | 652.0 | 632.5 | |
| 0.00 | 1.17 | 0.00 | 0.72 | -13.32 | 137.79 | 30.42 | 236.12 | 0.5957 | -802.0 | -680.7 | |
| 0.00 | 1.53 | 0.00 | 0.88 | -5.44 | 135.85 | 28.49 | 247.10 | 0.5175 | -757.0 | -607.6 | |
| 0.00 | 0.81 | 0.00 | 0.47 | -7.46 | 135.21 | 27.85 | 243.05 | 0.5216 | -663.0 | -494.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
