SDO HMI 2013-09-19 22:59:04 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 59.72 | 328.65 | 51.39 | 282.89 | -17.64 | 58.61 | -49.42 | 117.57 | 0.8184 | 718.5 | 200.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-09-19 22:59:04 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.89 | 0.00 | 0.73 | -17.32 | 60.58 | -47.45 | 118.10 | 0.7994 | 526.0 | 575.7 | |
| 55.91 | 307.54 | 47.64 | 262.83 | -17.65 | 58.94 | -49.09 | 117.71 | 0.8156 | 1010.0 | 240.2 | |
| 0.00 | 0.80 | 0.00 | 0.72 | -19.01 | 57.15 | -50.87 | 118.44 | 0.8362 | 85.0 | 100.0 | |
| 0.00 | 2.84 | 0.00 | 2.54 | -18.68 | 57.09 | -50.93 | 118.05 | 0.8355 | 45.0 | -28.6 | |
| 0.00 | 3.90 | 0.00 | 3.54 | -18.61 | 56.51 | -51.52 | 117.72 | 0.8401 | -508.0 | -513.3 | |
| 0.00 | 0.89 | 0.00 | 0.88 | -18.03 | 52.59 | -55.44 | 115.53 | 0.8698 | -627.0 | -541.6 | |
| 0.80 | 1.86 | 0.78 | 1.82 | -16.96 | 52.86 | -55.16 | 114.46 | 0.8646 | -667.4 | -554.6 | |
| 0.00 | 0.89 | 0.00 | 0.93 | -19.71 | 51.38 | -56.64 | 116.89 | 0.8836 | -464.0 | -409.8 | |
| 0.00 | 1.33 | 0.00 | 1.32 | -17.22 | 52.51 | -55.51 | 114.63 | 0.8680 | -525.0 | -425.7 | |
| 0.00 | 1.42 | 0.00 | 1.38 | -16.57 | 52.80 | -55.22 | 114.02 | 0.8639 | -712.0 | -567.4 | |
| 0.00 | 1.59 | 0.00 | 1.58 | -16.65 | 52.38 | -55.64 | 113.96 | 0.8675 | -374.0 | -260.4 | |
| 3.01 | 4.70 | 2.97 | 4.62 | -16.35 | 52.46 | -55.57 | 113.65 | 0.8660 | -554.9 | -404.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
