SDO HMI 2013-10-17 09:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.38 | 120.87 | 26.97 | 102.15 | -22.06 | 153.05 | 47.32 | 237.24 | 0.8095 | 313.9 | 145.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-10-17 09:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.13 | 0.00 | 1.05 | -22.88 | 156.96 | 51.23 | 238.28 | 0.8465 | -305.0 | -291.7 | |
| 14.66 | 60.92 | 13.37 | 55.58 | -22.41 | 156.56 | 50.83 | 238.62 | 0.8416 | 767.9 | 223.0 | |
| 0.79 | -2.00 | 0.71 | -2.00 | -22.53 | 155.95 | 50.22 | 238.22 | 0.8372 | 767.3 | 999999 | |
| 0.00 | 5.67 | 0.00 | 5.15 | -22.95 | 156.11 | 50.38 | 237.84 | 0.8401 | 130.0 | 151.2 | |
| 0.00 | 0.70 | 0.00 | 0.60 | -23.80 | 152.91 | 47.18 | 235.39 | 0.8176 | 483.0 | 456.0 | |
| 10.12 | 23.74 | 7.80 | 18.27 | -21.34 | 148.66 | 42.93 | 235.90 | 0.7685 | 697.3 | 401.0 | |
| 0.61 | 1.75 | 0.46 | 1.32 | -20.85 | 147.92 | 42.19 | 236.04 | 0.7590 | -568.9 | -444.9 | |
| 0.00 | 1.40 | 0.00 | 1.09 | -22.46 | 148.51 | 42.78 | 234.52 | 0.7730 | 475.0 | 375.0 | |
| 0.00 | 2.36 | 0.00 | 1.82 | -22.28 | 148.26 | 42.53 | 234.59 | 0.7698 | 606.0 | 467.7 | |
| 4.45 | 11.78 | 3.33 | 8.81 | -20.71 | 147.22 | 41.50 | 235.80 | 0.7516 | -820.5 | -571.2 | |
| 0.00 | 1.83 | 0.00 | 1.40 | -22.34 | 147.71 | 41.98 | 234.20 | 0.7651 | 571.0 | 433.9 | |
| 0.79 | -10.00 | 0.59 | -10.00 | -20.90 | 147.12 | 41.39 | 235.52 | 0.7517 | -805.0 | 999999 | |
| 0.00 | 3.40 | 0.00 | 2.55 | -21.16 | 147.08 | 41.35 | 235.19 | 0.7527 | -350.0 | -192.1 | |
| 0.96 | 1.92 | 0.71 | 1.43 | -22.28 | 145.97 | 40.24 | 233.20 | 0.7489 | -609.7 | -462.0 | |
| 0.00 | 1.92 | 0.00 | 1.42 | -22.30 | 145.77 | 40.04 | 233.05 | 0.7471 | -644.0 | -423.6 | |
| 0.00 | 2.09 | 0.00 | 1.47 | -22.01 | 142.29 | 36.56 | 231.04 | 0.7125 | -281.0 | -320.8 | |
| 0.00 | 0.26 | 0.00 | 0.19 | -24.53 | 142.45 | 36.72 | 228.27 | 0.7312 | -544.0 | -467.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
