SDO HMI 2013-10-17 20:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.29 | 68.09 | 12.72 | 67.84 | -22.18 | 154.08 | 54.41 | 240.23 | 0.8669 | 240.6 | 182.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2013-10-17 20:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.55 | 46.48 | 11.23 | 49.53 | -22.42 | 156.54 | 56.87 | 240.99 | 0.8872 | 634.5 | 210.4 | |
| 0.87 | 9.94 | 0.76 | 8.63 | -21.36 | 148.66 | 48.99 | 238.97 | 0.8223 | 779.3 | 532.0 | |
| 0.00 | 1.48 | 0.00 | 1.26 | -20.95 | 147.99 | 48.32 | 239.13 | 0.8149 | -629.0 | -470.6 | |
| 0.00 | 2.44 | 0.00 | 2.12 | -22.34 | 148.38 | 48.70 | 237.75 | 0.8239 | 749.0 | 527.0 | |
| 0.87 | 2.62 | 0.73 | 2.18 | -20.65 | 147.20 | 47.53 | 239.08 | 0.8067 | -631.1 | -501.0 | |
| 0.00 | 1.48 | 0.00 | 1.24 | -20.88 | 147.15 | 47.48 | 238.80 | 0.8073 | -641.0 | -553.0 | |
| 0.00 | 1.13 | 0.00 | 0.94 | -22.33 | 146.11 | 46.44 | 236.66 | 0.8046 | -559.0 | -494.5 | |
| 0.00 | 0.78 | 0.00 | 0.61 | -22.28 | 142.23 | 42.55 | 234.61 | 0.7699 | -496.0 | -359.9 | |
| 0.00 | 0.87 | 0.00 | 0.67 | -21.95 | 141.93 | 42.26 | 234.81 | 0.7655 | -446.0 | -454.6 | |
| 0.00 | 0.87 | 0.00 | 0.66 | -23.73 | 140.34 | 40.66 | 231.83 | 0.7611 | -491.0 | -458.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
