SDO HMI 2014-01-01 19:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 91.38 | 527.84 | 235.78 | 1568.46 | -8.44 | 98.89 | -80.17 | 98.03 | 0.9835 | 158.5 | -59.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-01 19:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.33 | 390.60 | 105.46 | 980.78 | -7.36 | 101.89 | -77.17 | 96.85 | 0.9750 | 438.6 | 22.1 | |
| 6.71 | 91.22 | 18.66 | 291.57 | -10.05 | 99.00 | -80.06 | 99.66 | 0.9846 | 398.4 | -86.2 | |
| 0.00 | 12.74 | 0.00 | 103.30 | -13.62 | 92.14 | -86.92 | 103.47 | 0.9982 | -322.0 | -217.5 | |
| 14.52 | -2.00 | 45.51 | -2.00 | -10.98 | 97.72 | -81.33 | 100.63 | 0.9882 | -83.5 | 999999 | |
| 0.00 | 0.76 | 0.00 | 2.45 | -9.20 | 97.62 | -81.44 | 98.84 | 0.9886 | 147.0 | 94.9 | |
| 0.00 | 2.63 | 0.00 | 14.12 | -11.20 | 93.87 | -85.19 | 100.97 | 0.9961 | -389.0 | -336.9 | |
| 0.59 | 11.47 | 5.00 | 76.73 | -11.59 | 92.16 | -86.90 | 101.43 | 0.9983 | -292.1 | -210.4 | |
| 12.99 | -1.00 | 35.79 | -1.00 | -6.38 | 99.11 | -79.95 | 95.93 | 0.9846 | 83.4 | 999999 | |
| 1.27 | -1.00 | 3.42 | -1.00 | -5.84 | 99.45 | -79.61 | 95.36 | 0.9837 | 14.6 | 999999 | |
| 5.95 | -1.00 | 16.53 | -1.00 | -5.49 | 99.13 | -79.93 | 95.03 | 0.9847 | -509.2 | 999999 | |
| 1.02 | 4.93 | 5.41 | 24.66 | -9.49 | 94.01 | -85.05 | 99.25 | 0.9960 | -481.9 | -416.5 | |
| 0.00 | 2.12 | 0.00 | 7.84 | -7.59 | 96.49 | -82.56 | 97.24 | 0.9914 | -250.0 | -333.9 | |
| 0.00 | 0.93 | 0.00 | 4.87 | -9.08 | 94.11 | -84.95 | 98.83 | 0.9959 | -316.0 | -369.7 | |
| 0.00 | 0.76 | 0.00 | 3.46 | -7.87 | 95.09 | -83.97 | 97.58 | 0.9943 | -405.0 | -384.0 | |
| 0.00 | 9.68 | 0.00 | 58.68 | -8.20 | 93.51 | -85.55 | 97.98 | 0.9968 | -424.0 | -366.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
