SDO HMI 2014-01-02 03:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.88 | 35.85 | 14.31 | 32.27 | -11.77 | 118.11 | -56.55 | 102.04 | 0.8367 | 525.7 | 384.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-02 03:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.02 | 0.00 | 0.88 | -14.39 | 120.28 | -54.38 | 105.42 | 0.8190 | 235.0 | 293.2 | |
| 10.79 | 24.30 | 9.46 | 21.24 | -11.39 | 119.15 | -55.51 | 101.66 | 0.8272 | 824.3 | 493.0 | |
| 0.00 | 1.61 | 0.00 | 1.42 | -11.80 | 118.97 | -55.69 | 102.14 | 0.8292 | 297.0 | 264.9 | |
| 4.67 | 7.14 | 4.39 | 6.71 | -12.38 | 116.61 | -58.05 | 102.63 | 0.8514 | 530.3 | 384.5 | |
| 0.42 | 0.85 | 0.46 | 0.92 | -12.70 | 111.78 | -62.87 | 102.66 | 0.8918 | -583.8 | -530.1 | |
| 0.00 | 0.93 | 0.00 | 1.10 | -12.46 | 109.52 | -65.13 | 102.29 | 0.9085 | -181.0 | -168.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
