SDO HMI 2014-01-02 16:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 265.63 | 1278.69 | 363.79 | 1788.87 | -8.47 | 98.16 | -69.38 | 97.84 | 0.9337 | 123.1 | -26.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-02 16:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.10 | 0.00 | 1.23 | -9.31 | 103.82 | -63.73 | 98.82 | 0.8974 | 599.0 | 556.7 | |
| 0.00 | 0.59 | 0.00 | 0.65 | -4.82 | 104.35 | -63.20 | 93.79 | 0.8933 | -360.0 | -389.0 | |
| 101.08 | 754.81 | 119.05 | 920.47 | -7.42 | 102.24 | -65.30 | 96.70 | 0.9089 | 567.3 | 113.9 | |
| 0.00 | 1.95 | 0.00 | 2.25 | -4.80 | 102.79 | -64.76 | 93.81 | 0.9052 | 203.0 | 196.4 | |
| 3.40 | -3.00 | 4.08 | -3.00 | -8.58 | 101.73 | -65.82 | 97.98 | 0.9126 | 466.2 | 999999 | |
| 0.68 | -3.00 | 0.82 | -3.00 | -7.98 | 101.56 | -65.99 | 97.32 | 0.9138 | -130.8 | 999999 | |
| 2.29 | -3.00 | 2.82 | -3.00 | -6.68 | 101.13 | -66.42 | 95.89 | 0.9169 | 187.1 | 999999 | |
| 0.00 | 2.55 | 0.00 | 3.10 | -4.67 | 101.44 | -66.10 | 93.70 | 0.9149 | -133.0 | -145.3 | |
| 3.65 | -3.00 | 4.56 | -3.00 | -6.18 | 100.73 | -66.82 | 95.36 | 0.9196 | 372.3 | 999999 | |
| 6.71 | 226.63 | 9.01 | 314.86 | -10.18 | 98.99 | -68.56 | 99.69 | 0.9310 | 752.1 | 64.9 | |
| 16.05 | -3.00 | 20.38 | -3.00 | -5.63 | 100.33 | -67.22 | 94.76 | 0.9224 | -571.3 | 999999 | |
| 33.38 | -10.00 | 46.26 | -10.00 | -10.92 | 98.28 | -69.27 | 100.48 | 0.9354 | 327.4 | 999999 | |
| 21.24 | -3.00 | 27.42 | -3.00 | -6.79 | 99.94 | -67.61 | 96.04 | 0.9249 | 264.6 | 999999 | |
| 3.57 | -3.00 | 4.58 | -3.00 | -6.15 | 100.04 | -67.50 | 95.33 | 0.9243 | 349.0 | 999999 | |
| 0.00 | 0.93 | 0.00 | 1.25 | -8.72 | 99.12 | -68.43 | 98.12 | 0.9302 | 561.0 | 521.2 | |
| 9.85 | -10.00 | 13.54 | -10.00 | -9.73 | 98.44 | -69.11 | 99.20 | 0.9344 | 420.4 | 999999 | |
| 3.91 | -3.00 | 5.08 | -3.00 | -5.89 | 99.79 | -67.75 | 95.06 | 0.9259 | 43.8 | 999999 | |
| 0.00 | 0.76 | 0.00 | 1.04 | -8.63 | 98.65 | -68.89 | 98.03 | 0.9331 | 428.0 | 394.6 | |
| 2.38 | -3.00 | 3.15 | -3.00 | -5.72 | 99.36 | -68.19 | 94.89 | 0.9288 | -349.2 | 999999 | |
| 0.00 | 6.12 | 0.00 | 8.66 | -9.25 | 97.79 | -69.76 | 98.68 | 0.9383 | -319.0 | -276.4 | |
| 1.70 | -3.00 | 2.30 | -3.00 | -5.75 | 98.78 | -68.77 | 94.93 | 0.9325 | -55.2 | 999999 | |
| 0.00 | 1.10 | 0.00 | 1.53 | -7.06 | 98.22 | -69.33 | 96.35 | 0.9358 | -310.0 | -234.4 | |
| 5.10 | -3.00 | 7.02 | -3.00 | -5.47 | 98.43 | -69.11 | 94.64 | 0.9347 | -368.4 | 999999 | |
| 0.42 | 1.53 | 0.64 | 2.30 | -9.78 | 96.54 | -71.01 | 99.25 | 0.9456 | 56.6 | -32.2 | |
| 0.00 | 4.16 | 0.00 | 5.93 | -5.52 | 97.65 | -69.90 | 94.71 | 0.9394 | -353.0 | -289.7 | |
| 0.00 | 2.04 | 0.00 | 3.10 | -6.96 | 96.38 | -71.17 | 96.27 | 0.9466 | -433.0 | -489.3 | |
| 0.00 | 0.93 | 0.00 | 1.78 | -13.41 | 92.23 | -75.32 | 103.03 | 0.9670 | -484.0 | -506.6 | |
| 0.00 | 2.80 | 0.00 | 4.24 | -5.75 | 96.50 | -71.05 | 94.99 | 0.9461 | -382.0 | -481.0 | |
| 0.00 | 2.46 | 0.00 | 4.04 | -9.15 | 94.82 | -72.73 | 98.59 | 0.9548 | -427.0 | -374.6 | |
| 0.00 | 1.53 | 0.00 | 2.41 | -7.52 | 95.59 | -71.96 | 96.87 | 0.9509 | -471.0 | -437.1 | |
| 0.00 | 0.93 | 0.00 | 1.46 | -6.88 | 95.84 | -71.71 | 96.19 | 0.9496 | -596.0 | -528.9 | |
| 3.14 | 21.75 | 5.37 | 37.66 | -9.95 | 94.05 | -73.49 | 99.43 | 0.9586 | -492.8 | -397.1 | |
| 4.76 | 50.37 | 9.63 | 102.89 | -13.30 | 91.33 | -76.22 | 102.92 | 0.9708 | -590.1 | -329.8 | |
| 7.48 | -32.00 | 13.16 | -32.00 | -10.40 | 93.55 | -74.00 | 99.91 | 0.9610 | -557.1 | 999999 | |
| 0.00 | 0.93 | 0.00 | 1.75 | -11.68 | 92.63 | -74.91 | 101.24 | 0.9652 | -351.0 | -363.8 | |
| 2.29 | -33.00 | 4.82 | -33.00 | -13.57 | 90.78 | -76.77 | 103.20 | 0.9730 | -125.1 | 999999 | |
| 0.00 | 4.50 | 0.00 | 8.32 | -11.32 | 92.79 | -74.76 | 100.87 | 0.9646 | -599.0 | -534.5 | |
| 7.48 | 65.07 | 12.06 | 104.57 | -6.87 | 95.16 | -72.39 | 96.20 | 0.9532 | -517.6 | -263.7 | |
| 0.68 | 1.70 | 1.12 | 2.80 | -7.89 | 94.72 | -72.82 | 97.27 | 0.9554 | -114.0 | -62.3 | |
| 0.00 | 0.42 | 0.00 | 0.72 | -8.20 | 94.37 | -73.18 | 97.60 | 0.9571 | -493.0 | -491.8 | |
| 0.00 | 2.55 | 0.00 | 4.66 | -10.25 | 92.97 | -74.57 | 99.76 | 0.9637 | -262.0 | -237.6 | |
| 3.23 | -38.00 | 5.36 | -38.00 | -6.73 | 94.71 | -72.84 | 96.06 | 0.9556 | -17.1 | 999999 | |
| 2.55 | 3.99 | 4.86 | 7.63 | -11.03 | 92.30 | -75.25 | 100.57 | 0.9667 | -474.3 | -464.1 | |
| 0.00 | 1.36 | 0.00 | 2.48 | -10.01 | 93.02 | -74.53 | 99.51 | 0.9636 | -113.0 | -212.4 | |
| 0.00 | 2.12 | 0.00 | 4.44 | -12.22 | 90.92 | -76.63 | 101.81 | 0.9725 | -432.0 | -400.7 | |
| 1.70 | 40.01 | 3.48 | 86.35 | -11.78 | 91.18 | -76.36 | 101.35 | 0.9714 | -529.6 | -400.8 | |
| 2.04 | 42.56 | 3.65 | 79.49 | -8.48 | 93.37 | -74.18 | 97.91 | 0.9620 | -505.7 | -377.1 | |
| 0.34 | 0.68 | 0.62 | 1.24 | -9.00 | 93.07 | -74.47 | 98.45 | 0.9633 | -304.8 | -349.2 | |
| 0.00 | 0.76 | 0.00 | 1.42 | -9.46 | 92.79 | -74.75 | 98.94 | 0.9646 | -457.0 | -473.4 | |
| 1.02 | 2.04 | 1.73 | 3.46 | -6.32 | 94.24 | -73.30 | 95.64 | 0.9580 | -160.3 | -166.8 | |
| 5.61 | -47.00 | 10.14 | -47.00 | -8.11 | 93.22 | -74.32 | 97.53 | 0.9627 | -594.5 | 999999 | |
| 0.00 | 0.51 | 0.00 | 0.87 | -6.01 | 94.14 | -73.40 | 95.32 | 0.9585 | -219.0 | -262.5 | |
| 0.68 | 1.61 | 1.22 | 2.88 | -7.49 | 93.31 | -74.24 | 96.88 | 0.9624 | -81.8 | -34.6 | |
| 0.00 | 0.59 | 0.00 | 1.16 | -9.27 | 91.96 | -75.58 | 98.75 | 0.9683 | -432.0 | -372.0 | |
| 3.06 | 5.27 | 6.01 | 10.35 | -9.02 | 91.87 | -75.67 | 98.50 | 0.9687 | -329.1 | -273.2 | |
| 1.19 | -46.00 | 2.65 | -46.00 | -10.96 | 90.00 | -77.54 | 100.53 | 0.9761 | -462.1 | 999999 | |
| 0.00 | 1.19 | 0.00 | 2.74 | -11.42 | 89.57 | -77.97 | 101.00 | 0.9776 | -130.0 | -144.1 | |
| 0.00 | 0.76 | 0.00 | 1.99 | -10.56 | 88.07 | -79.47 | 100.15 | 0.9827 | 222.0 | 185.3 | |
| 0.00 | 1.02 | 0.00 | 2.63 | -10.32 | 88.15 | -79.40 | 99.90 | 0.9825 | 123.0 | 108.2 | |
| 2.97 | 6.03 | 7.20 | 14.59 | -8.78 | 89.04 | -78.51 | 98.31 | 0.9797 | -114.3 | -83.8 | |
| 0.00 | 7.98 | 0.00 | 21.48 | -10.15 | 87.81 | -79.74 | 99.74 | 0.9836 | 348.0 | 277.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
