SDO HMI 2014-01-05 18:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.33 | 61.30 | 6.72 | 31.42 | -12.82 | 116.61 | -10.32 | 135.40 | 0.2431 | 224.9 | 188.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-05 18:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.78 | 0.00 | 0.89 | -11.32 | 127.66 | 0.72 | 185.21 | 0.1367 | 1045.0 | 858.9 | |
| 0.00 | 3.23 | 0.00 | 1.63 | -13.08 | 120.78 | -6.15 | 147.86 | 0.1972 | 904.0 | 805.2 | |
| 0.00 | 3.82 | 0.00 | 1.93 | -12.75 | 120.03 | -6.90 | 143.85 | 0.1997 | 583.0 | 689.2 | |
| 12.99 | 19.62 | 6.54 | 9.88 | -10.93 | 119.50 | -7.43 | 135.48 | 0.1819 | 1229.1 | 741.3 | |
| 0.00 | 3.06 | 0.00 | 1.55 | -12.32 | 119.22 | -7.71 | 139.46 | 0.2026 | 1126.0 | 888.4 | |
| 0.00 | 3.06 | 0.00 | 1.55 | -12.05 | 119.08 | -7.86 | 138.04 | 0.2008 | 1250.0 | 1012.0 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -18.71 | 118.50 | -8.44 | 152.09 | 0.2982 | 678.0 | 755.8 | |
| 0.00 | 1.44 | 0.00 | 0.73 | -13.27 | 118.55 | -8.39 | 140.10 | 0.2223 | 951.0 | 784.5 | |
| 0.00 | 1.02 | 0.00 | 0.52 | -11.75 | 118.60 | -8.33 | 135.32 | 0.2028 | 989.0 | 748.0 | |
| 0.00 | 1.70 | 0.00 | 0.88 | -18.40 | 118.20 | -8.74 | 150.73 | 0.2961 | 935.0 | 768.9 | |
| 0.00 | 1.02 | 0.00 | 0.52 | -12.29 | 116.20 | -10.74 | 130.09 | 0.2390 | -1070.0 | -842.9 | |
| 0.00 | 2.12 | 0.00 | 1.08 | -12.50 | 116.10 | -10.84 | 130.51 | 0.2425 | -917.0 | -759.5 | |
| 0.00 | 1.44 | 0.00 | 0.74 | -11.86 | 115.29 | -11.64 | 126.48 | 0.2467 | 1075.0 | 809.2 | |
| 0.00 | 1.02 | 0.00 | 0.53 | -13.41 | 113.20 | -13.73 | 126.88 | 0.2900 | -889.0 | -704.3 | |
| 0.00 | 1.02 | 0.00 | 0.53 | -11.62 | 112.96 | -13.97 | 121.05 | 0.2773 | -873.0 | -650.4 | |
| 0.00 | 1.19 | 0.00 | 0.61 | -11.86 | 112.79 | -14.14 | 121.49 | 0.2817 | -966.0 | -733.6 | |
| 0.00 | 1.61 | 0.00 | 0.84 | -11.99 | 111.91 | -15.02 | 120.45 | 0.2954 | -999.0 | -782.2 | |
| 0.00 | 1.44 | 0.00 | 0.75 | -12.55 | 111.75 | -15.18 | 121.86 | 0.3023 | -968.0 | -717.0 | |
| 0.00 | 1.78 | 0.00 | 0.93 | -14.26 | 111.55 | -15.39 | 126.19 | 0.3201 | -1046.0 | -805.5 | |
| 0.00 | 1.10 | 0.00 | 0.59 | -16.21 | 108.31 | -18.62 | 125.97 | 0.3805 | -973.0 | -757.6 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -15.55 | 106.95 | -19.98 | 122.74 | 0.3931 | -748.0 | -659.9 | |
| 0.34 | 4.25 | 0.18 | 2.30 | -16.36 | 106.73 | -20.20 | 124.25 | 0.4026 | -856.8 | -551.1 | |
| 0.00 | 1.95 | 0.00 | 1.05 | -15.36 | 106.68 | -20.26 | 122.00 | 0.3954 | -654.0 | -473.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
