SDO HMI 2014-01-07 11:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 194.33 | 937.15 | 99.04 | 477.80 | 9.00 | 100.21 | -4.24 | 17.64 | 0.2366 | 147.2 | 115.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-07 11:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.56 | 90.85 | 3.83 | 46.03 | 8.45 | 105.45 | 1.00 | 355.32 | 0.2128 | -1226.0 | -512.0 | |
| 9.69 | -1.00 | 4.91 | -1.00 | 8.30 | 105.18 | 0.73 | 356.53 | 0.2099 | -1298.7 | 999999 | |
| 0.00 | 1.10 | 0.00 | 0.56 | 7.82 | 104.76 | 0.31 | 358.45 | 0.2014 | -825.0 | -680.2 | |
| 3.65 | -1.00 | 1.85 | -1.00 | 8.36 | 104.73 | 0.29 | 358.65 | 0.2107 | -1095.1 | 999999 | |
| 0.00 | 3.06 | 0.00 | 1.54 | 6.91 | 104.49 | 0.04 | 359.76 | 0.1858 | -1076.0 | -829.1 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 7.61 | 104.40 | -0.04 | 0.22 | 0.1977 | -942.0 | -842.9 | |
| 5.44 | 164.37 | 2.76 | 83.45 | 8.84 | 103.87 | -0.58 | 2.62 | 0.2191 | -1040.9 | -629.4 | |
| 0.00 | 1.10 | 0.00 | 0.56 | 9.45 | 103.87 | -0.58 | 2.50 | 0.2294 | -893.0 | -722.6 | |
| 5.69 | -7.00 | 2.89 | -7.00 | 8.81 | 103.63 | -0.82 | 3.71 | 0.2188 | -1148.8 | 999999 | |
| 11.22 | -7.00 | 5.70 | -7.00 | 8.90 | 103.39 | -1.06 | 4.76 | 0.2207 | -1050.8 | 999999 | |
| 7.90 | -7.00 | 4.01 | -7.00 | 8.60 | 103.18 | -1.26 | 5.83 | 0.2159 | -1278.1 | 999999 | |
| 0.00 | 4.76 | 0.00 | 2.41 | 7.61 | 103.04 | -1.41 | 7.07 | 0.1992 | -988.0 | -892.7 | |
| 1.36 | -7.00 | 0.69 | -7.00 | 8.75 | 102.91 | -1.53 | 6.97 | 0.2190 | -1362.9 | 999999 | |
| 8.50 | -7.00 | 4.32 | -7.00 | 9.03 | 102.88 | -1.56 | 6.95 | 0.2236 | -1088.9 | 999999 | |
| 3.23 | -7.00 | 1.64 | -7.00 | 8.87 | 102.74 | -1.71 | 7.70 | 0.2214 | -1127.8 | 999999 | |
| 1.10 | 5.44 | 0.56 | 2.75 | 7.88 | 102.56 | -1.89 | 9.20 | 0.2050 | -1224.9 | -940.6 | |
| 0.85 | -7.00 | 0.43 | -7.00 | 8.94 | 102.53 | -1.92 | 8.58 | 0.2230 | -978.0 | 999999 | |
| 0.00 | 1.44 | 0.00 | 0.74 | 9.42 | 102.43 | -2.01 | 8.66 | 0.2314 | -605.0 | -414.9 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 8.51 | 102.35 | -2.10 | 9.68 | 0.2163 | -1004.0 | -842.9 | |
| 0.00 | 2.80 | 0.00 | 1.42 | 8.24 | 102.26 | -2.19 | 10.31 | 0.2120 | -1075.0 | -921.2 | |
| 0.00 | 1.10 | 0.00 | 0.56 | 7.97 | 102.23 | -2.22 | 10.68 | 0.2075 | -661.0 | -595.8 | |
| 10.54 | -7.00 | 5.34 | -7.00 | 8.37 | 101.78 | -2.66 | 12.37 | 0.2157 | -1176.0 | 999999 | |
| 0.00 | 2.04 | 0.00 | 1.04 | 9.30 | 101.78 | -2.67 | 11.52 | 0.2313 | -658.0 | -378.3 | |
| 0.00 | 4.93 | 0.00 | 2.49 | 7.79 | 101.58 | -2.87 | 13.94 | 0.2069 | -502.0 | -700.9 | |
| 0.68 | -7.00 | 0.35 | -7.00 | 8.55 | 101.39 | -3.05 | 13.91 | 0.2202 | -1013.8 | 999999 | |
| 2.46 | 9.86 | 1.26 | 5.02 | 9.33 | 101.36 | -3.09 | 13.23 | 0.2334 | -911.7 | -789.3 | |
| 0.00 | 0.85 | 0.00 | 0.43 | 6.77 | 101.32 | -3.13 | 16.56 | 0.1912 | -912.0 | -745.2 | |
| 0.00 | 1.87 | 0.00 | 0.95 | 7.89 | 100.92 | -3.53 | 16.82 | 0.2115 | 1032.0 | 767.3 | |
| 0.00 | 1.19 | 0.00 | 0.60 | 8.34 | 100.89 | -3.56 | 16.36 | 0.2190 | -597.0 | -507.9 | |
| 0.00 | 3.23 | 0.00 | 1.64 | 8.49 | 100.71 | -3.74 | 16.94 | 0.2224 | -65.0 | -193.2 | |
| 3.74 | 50.99 | 1.90 | 25.90 | 8.01 | 100.56 | -3.88 | 18.24 | 0.2153 | 779.8 | 185.6 | |
| 0.00 | 7.31 | 0.00 | 3.72 | 9.13 | 100.49 | -3.95 | 17.01 | 0.2338 | -78.0 | -119.0 | |
| 0.51 | 570.96 | 0.26 | 291.96 | 9.58 | 100.40 | -4.05 | 16.82 | 0.2417 | 802.5 | 451.0 | |
| 6.46 | -31.00 | 3.28 | -31.00 | 8.43 | 100.14 | -4.31 | 19.42 | 0.2245 | 175.7 | 999999 | |
| 0.59 | -31.00 | 0.30 | -31.00 | 8.23 | 99.84 | -4.60 | 20.98 | 0.2229 | 811.1 | 999999 | |
| 4.16 | -33.00 | 2.13 | -33.00 | 9.43 | 99.65 | -4.80 | 19.91 | 0.2433 | 910.5 | 999999 | |
| 1.53 | -33.00 | 0.78 | -33.00 | 9.22 | 99.53 | -4.91 | 20.67 | 0.2407 | 907.7 | 999999 | |
| 3.31 | -33.00 | 1.70 | -33.00 | 9.86 | 99.10 | -5.34 | 21.33 | 0.2534 | 948.1 | 999999 | |
| 17.00 | -33.00 | 8.68 | -33.00 | 9.35 | 99.08 | -5.37 | 22.19 | 0.2454 | 1228.3 | 999999 | |
| 0.68 | -33.00 | 0.35 | -33.00 | 9.08 | 99.00 | -5.45 | 22.95 | 0.2417 | 1145.0 | 999999 | |
| 0.00 | 3.06 | 0.00 | 1.58 | 11.14 | 98.96 | -5.48 | 20.08 | 0.2744 | 546.0 | 444.4 | |
| 1.19 | -33.00 | 0.61 | -33.00 | 9.62 | 98.87 | -5.58 | 22.55 | 0.2511 | 937.0 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.51 | 5.77 | 98.91 | -5.53 | 30.18 | 0.1918 | -797.0 | -549.8 | |
| 1.27 | -33.00 | 0.65 | -33.00 | 9.35 | 98.84 | -5.61 | 23.08 | 0.2470 | 1315.5 | 999999 | |
| 0.76 | -33.00 | 0.39 | -33.00 | 8.90 | 98.79 | -5.66 | 24.03 | 0.2403 | 1173.6 | 999999 | |
| 0.00 | 1.10 | 0.00 | 0.56 | 7.72 | 98.63 | -5.82 | 26.87 | 0.2235 | -711.0 | -381.5 | |
| 0.93 | -33.00 | 0.48 | -33.00 | 9.84 | 98.44 | -6.00 | 23.73 | 0.2573 | 788.5 | 999999 | |
| 72.33 | -33.00 | 36.99 | -33.00 | 9.23 | 98.15 | -6.29 | 25.77 | 0.2501 | 1437.7 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
