SDO HMI 2014-01-08 02:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 10.20 | 0.00 | 5.57 | -21.78 | 111.63 | 15.44 | 216.77 | 0.4222 | 241.9 | 387.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-08 02:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.53 | 0.00 | 0.84 | -18.92 | 118.01 | 21.82 | 232.99 | 0.4423 | 873.0 | 761.8 | |
| 0.00 | 1.19 | 0.00 | 0.66 | -19.54 | 117.66 | 21.47 | 231.40 | 0.4433 | 422.0 | 389.1 | |
| 0.00 | 0.68 | 0.00 | 0.37 | -20.86 | 116.43 | 20.24 | 227.44 | 0.4409 | 750.0 | 629.1 | |
| 0.00 | 3.74 | 0.00 | 2.06 | -21.69 | 115.27 | 19.08 | 224.39 | 0.4361 | 552.0 | 652.3 | |
| 0.00 | 1.02 | 0.00 | 0.55 | -23.23 | 111.06 | 14.87 | 215.20 | 0.4109 | 627.0 | 568.0 | |
| 0.00 | 0.68 | 0.00 | 0.35 | -19.59 | 98.90 | 2.71 | 189.30 | 0.2767 | -742.0 | -601.6 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -27.70 | 92.93 | -3.26 | 172.92 | 0.4099 | -789.0 | -569.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
