SDO HMI 2014-01-08 15:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 184.67 | 869.77 | 95.88 | 451.43 | 9.04 | 100.31 | 11.23 | 319.71 | 0.2979 | 209.0 | 122.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-08 15:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.35 | 54.03 | 2.84 | 28.65 | 8.58 | 106.22 | 17.14 | 306.08 | 0.3622 | -977.6 | -397.5 | |
| 6.29 | -1.00 | 3.33 | -1.00 | 8.30 | 105.84 | 16.76 | 306.06 | 0.3545 | -1068.7 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.63 | 8.78 | 105.67 | 16.59 | 307.43 | 0.3569 | -608.0 | -487.7 | |
| 0.00 | 0.85 | 0.00 | 0.45 | 7.38 | 105.24 | 16.16 | 304.87 | 0.3379 | -654.0 | -530.0 | |
| 35.26 | 109.00 | 18.55 | 57.36 | 8.01 | 104.86 | 15.78 | 307.03 | 0.3388 | -1212.8 | -416.3 | |
| 0.00 | 1.10 | 0.00 | 0.59 | 10.22 | 104.87 | 15.79 | 311.95 | 0.3617 | -813.0 | -684.4 | |
| 0.00 | 1.53 | 0.00 | 0.81 | 10.30 | 104.60 | 15.52 | 312.63 | 0.3593 | -773.0 | -616.9 | |
| 0.00 | 3.14 | 0.00 | 1.65 | 7.37 | 104.28 | 15.20 | 306.49 | 0.3249 | -1033.0 | -808.0 | |
| 0.00 | 2.04 | 0.00 | 1.07 | 8.45 | 104.23 | 15.15 | 309.20 | 0.3351 | -579.0 | -411.1 | |
| 0.00 | 0.76 | 0.00 | 0.41 | 10.39 | 104.32 | 15.24 | 313.32 | 0.3569 | -689.0 | -551.3 | |
| 0.00 | 1.70 | 0.00 | 0.89 | 7.27 | 104.06 | 14.98 | 306.65 | 0.3211 | -950.0 | -823.6 | |
| 0.59 | 3.57 | 0.31 | 1.87 | 8.30 | 104.01 | 14.93 | 309.25 | 0.3307 | -1007.3 | -708.1 | |
| 0.00 | 8.92 | 0.00 | 4.67 | 7.63 | 103.95 | 14.87 | 307.75 | 0.3232 | -472.0 | -951.1 | |
| 0.00 | 1.87 | 0.00 | 0.98 | 7.96 | 103.87 | 14.79 | 308.71 | 0.3255 | -939.0 | -797.0 | |
| 0.00 | 1.95 | 0.00 | 1.02 | 7.57 | 103.58 | 14.50 | 308.29 | 0.3177 | -874.0 | -720.3 | |
| 0.00 | 1.87 | 0.00 | 0.98 | 8.56 | 103.59 | 14.51 | 310.68 | 0.3281 | -887.0 | -733.9 | |
| 0.00 | 1.02 | 0.00 | 0.53 | 7.50 | 103.27 | 14.19 | 308.73 | 0.3130 | -879.0 | -718.9 | |
| 1.44 | 2.63 | 0.75 | 1.37 | 7.80 | 103.13 | 14.05 | 309.76 | 0.3142 | -1109.3 | -954.2 | |
| 0.00 | 1.36 | 0.00 | 0.71 | 6.78 | 103.04 | 13.95 | 307.33 | 0.3025 | -938.0 | -674.4 | |
| 0.00 | 3.91 | 0.00 | 2.04 | 8.28 | 103.03 | 13.94 | 311.14 | 0.3180 | -1123.0 | -993.5 | |
| 2.29 | 8.16 | 1.20 | 4.26 | 8.58 | 102.73 | 13.65 | 312.46 | 0.3177 | -931.4 | -813.4 | |
| 0.00 | 3.57 | 0.00 | 1.85 | 6.95 | 102.64 | 13.56 | 308.58 | 0.2991 | -896.0 | -674.4 | |
| 0.00 | 5.61 | 0.00 | 2.92 | 8.24 | 102.69 | 13.60 | 311.75 | 0.3135 | -1118.0 | -920.5 | |
| 0.00 | 1.02 | 0.00 | 0.53 | 7.94 | 102.58 | 13.50 | 311.23 | 0.3089 | -1007.0 | -829.4 | |
| 0.00 | 4.50 | 0.00 | 2.35 | 8.66 | 102.43 | 13.34 | 313.30 | 0.3149 | -930.0 | -732.5 | |
| 0.00 | 2.12 | 0.00 | 1.11 | 8.30 | 102.38 | 13.30 | 312.53 | 0.3103 | -791.0 | -769.1 | |
| 0.00 | 1.10 | 0.00 | 0.57 | 7.46 | 102.26 | 13.18 | 310.70 | 0.2995 | -1059.0 | -887.8 | |
| 0.00 | 1.19 | 0.00 | 0.62 | 7.64 | 102.27 | 13.19 | 311.14 | 0.3016 | -1011.0 | -802.7 | |
| 0.00 | 3.99 | 0.00 | 2.08 | 7.94 | 102.22 | 13.13 | 312.00 | 0.3042 | -1022.0 | -866.9 | |
| 0.93 | 3.14 | 0.49 | 1.63 | 8.18 | 102.19 | 13.11 | 312.64 | 0.3066 | -1073.1 | -790.9 | |
| 0.00 | 0.85 | 0.00 | 0.44 | 7.27 | 102.07 | 12.99 | 310.63 | 0.2952 | -962.0 | -700.5 | |
| 0.00 | 1.61 | 0.00 | 0.84 | 8.32 | 102.02 | 12.93 | 313.39 | 0.3061 | -644.0 | -543.7 | |
| 0.00 | 1.19 | 0.00 | 0.62 | 7.30 | 101.77 | 12.69 | 311.37 | 0.2916 | -988.0 | -779.6 | |
| 0.00 | 1.36 | 0.00 | 0.70 | 7.51 | 101.75 | 12.66 | 311.97 | 0.2936 | -952.0 | -789.4 | |
| 0.00 | 2.46 | 0.00 | 1.28 | 8.11 | 101.73 | 12.65 | 313.50 | 0.3003 | -782.0 | -732.8 | |
| 0.76 | 6.20 | 0.40 | 3.21 | 7.89 | 101.33 | 12.25 | 313.89 | 0.2929 | -1030.0 | -711.4 | |
| 0.68 | 1.70 | 0.35 | 0.87 | 6.33 | 101.10 | 12.02 | 310.28 | 0.2726 | -1101.4 | -924.3 | |
| 0.00 | 1.19 | 0.00 | 0.61 | 6.21 | 101.04 | 11.96 | 310.08 | 0.2705 | -590.0 | -582.0 | |
| 0.00 | 3.57 | 0.00 | 1.85 | 8.19 | 101.07 | 11.98 | 315.25 | 0.2932 | -766.0 | -611.5 | |
| 0.00 | 5.35 | 0.00 | 2.77 | 7.95 | 100.97 | 11.89 | 314.89 | 0.2892 | -114.0 | -316.9 | |
| 0.00 | 2.04 | 0.00 | 1.05 | 6.89 | 100.24 | 11.16 | 313.95 | 0.2681 | 825.0 | 611.9 | |
| 0.00 | 1.19 | 0.00 | 0.61 | 8.39 | 100.25 | 11.17 | 317.74 | 0.2863 | 265.0 | 11.9 | |
| 0.42 | 3.23 | 0.22 | 1.66 | 6.76 | 99.90 | 10.82 | 314.49 | 0.2626 | 924.0 | 741.5 | |
| 0.00 | 6.63 | 0.00 | 3.42 | 8.24 | 99.85 | 10.77 | 318.41 | 0.2799 | 859.0 | 820.1 | |
| 0.00 | 1.27 | 0.00 | 0.66 | 8.02 | 99.73 | 10.64 | 318.23 | 0.2758 | 714.0 | 570.2 | |
| 5.86 | 10.79 | 3.01 | 5.54 | 7.33 | 99.68 | 10.59 | 316.62 | 0.2667 | 1161.0 | 806.1 | |
| 1.19 | 573.55 | 0.62 | 296.21 | 10.02 | 99.67 | 10.58 | 322.85 | 0.3009 | 887.1 | 417.3 | |
| 0.68 | 2.04 | 0.35 | 1.04 | 5.44 | 99.33 | 10.25 | 312.18 | 0.2402 | -1081.4 | -940.2 | |
| 0.00 | 1.36 | 0.00 | 0.71 | 10.81 | 99.39 | 10.31 | 325.12 | 0.3087 | 674.0 | 523.6 | |
| 119.45 | -47.00 | 61.66 | -47.00 | 9.55 | 98.50 | 9.42 | 325.07 | 0.2831 | 1321.5 | 999999 | |
| 0.00 | 1.10 | 0.00 | 0.58 | 11.44 | 98.56 | 9.48 | 328.46 | 0.3099 | -776.0 | -648.2 | |
| 3.48 | -47.00 | 1.80 | -47.00 | 9.97 | 98.30 | 9.22 | 326.49 | 0.2870 | 890.5 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.52 | 7.52 | 97.54 | 8.46 | 323.43 | 0.2459 | 873.0 | 587.1 | |
| 0.00 | 1.87 | 0.00 | 0.95 | 6.95 | 97.41 | 8.33 | 322.42 | 0.2368 | 774.0 | 599.1 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 7.31 | 97.24 | 8.15 | 323.91 | 0.2399 | 1116.0 | 892.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
