SDO HMI 2014-01-08 17:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 173.53 | 885.09 | 90.53 | 461.15 | 9.06 | 100.27 | 12.29 | 317.15 | 0.3096 | 241.6 | 137.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-08 17:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.02 | 0.00 | 0.55 | 10.98 | 107.44 | 19.46 | 307.67 | 0.4149 | -632.0 | -469.9 | |
| 4.93 | 39.67 | 2.63 | 21.18 | 8.59 | 106.28 | 18.30 | 304.37 | 0.3778 | -1007.3 | -421.8 | |
| 8.75 | -2.00 | 4.66 | -2.00 | 8.37 | 105.89 | 17.91 | 304.45 | 0.3706 | -992.4 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.64 | 10.43 | 105.88 | 17.90 | 308.88 | 0.3900 | -732.0 | -553.2 | |
| 34.40 | 107.88 | 18.21 | 57.11 | 8.02 | 104.91 | 16.93 | 305.16 | 0.3542 | -1206.3 | -421.0 | |
| 0.00 | 1.27 | 0.00 | 0.68 | 10.31 | 104.62 | 16.64 | 310.69 | 0.3731 | -821.0 | -628.0 | |
| 0.00 | 23.44 | 0.00 | 12.34 | 7.52 | 104.11 | 16.13 | 305.28 | 0.3389 | -1183.0 | -858.3 | |
| 0.00 | 1.53 | 0.00 | 0.81 | 8.25 | 104.11 | 16.13 | 307.00 | 0.3458 | -1021.0 | -848.6 | |
| 0.00 | 1.27 | 0.00 | 0.67 | 8.94 | 104.08 | 16.10 | 308.64 | 0.3523 | -748.0 | -634.9 | |
| 0.00 | 2.38 | 0.00 | 1.25 | 8.51 | 103.75 | 15.77 | 308.24 | 0.3438 | -940.0 | -840.9 | |
| 0.00 | 0.51 | 0.00 | 0.27 | 8.12 | 103.67 | 15.69 | 307.46 | 0.3388 | -773.0 | -624.3 | |
| 1.70 | 6.37 | 0.89 | 3.34 | 7.78 | 103.19 | 15.22 | 307.50 | 0.3292 | -1179.6 | -861.9 | |
| 0.00 | 2.04 | 0.00 | 1.06 | 6.82 | 103.10 | 15.12 | 305.25 | 0.3186 | -809.0 | -621.8 | |
| 0.00 | 1.53 | 0.00 | 0.80 | 8.65 | 103.14 | 15.16 | 309.67 | 0.3374 | -564.0 | -448.4 | |
| 0.76 | 27.44 | 0.40 | 14.40 | 8.41 | 103.10 | 15.12 | 309.19 | 0.3343 | -957.8 | -670.6 | |
| 2.63 | -15.00 | 1.38 | -15.00 | 8.47 | 102.85 | 14.87 | 309.78 | 0.3318 | -950.8 | 999999 | |
| 0.93 | 4.59 | 0.49 | 2.40 | 8.22 | 102.72 | 14.74 | 309.45 | 0.3276 | -1142.7 | -916.6 | |
| 0.00 | 1.44 | 0.00 | 0.75 | 6.96 | 102.61 | 14.63 | 306.51 | 0.3134 | -851.0 | -679.5 | |
| 0.00 | 1.78 | 0.00 | 0.93 | 7.89 | 102.64 | 14.67 | 308.79 | 0.3232 | -838.0 | -659.6 | |
| 0.00 | 1.87 | 0.00 | 0.98 | 8.85 | 102.37 | 14.40 | 311.59 | 0.3299 | -739.0 | -491.4 | |
| 0.00 | 2.55 | 0.00 | 1.33 | 7.89 | 102.31 | 14.33 | 309.43 | 0.3188 | -1047.0 | -937.6 | |
| 0.00 | 2.04 | 0.00 | 1.07 | 8.16 | 102.29 | 14.31 | 310.13 | 0.3214 | -1106.0 | -994.2 | |
| 0.00 | 0.68 | 0.00 | 0.35 | 7.43 | 102.26 | 14.28 | 308.40 | 0.3135 | -865.0 | -644.1 | |
| 0.00 | 1.10 | 0.00 | 0.58 | 8.12 | 102.10 | 14.12 | 310.42 | 0.3187 | -858.0 | -745.5 | |
| 0.00 | 2.55 | 0.00 | 1.33 | 8.03 | 101.85 | 13.87 | 310.69 | 0.3145 | -742.0 | -693.5 | |
| 0.00 | 1.10 | 0.00 | 0.57 | 7.34 | 101.80 | 13.82 | 309.07 | 0.3065 | -952.0 | -775.7 | |
| 0.00 | 1.44 | 0.00 | 0.75 | 6.89 | 101.75 | 13.77 | 307.99 | 0.3013 | -704.0 | -520.0 | |
| 0.00 | 1.02 | 0.00 | 0.53 | 8.05 | 101.48 | 13.51 | 311.51 | 0.3102 | -610.0 | -544.1 | |
| 2.21 | 14.10 | 1.15 | 7.33 | 7.90 | 101.30 | 13.32 | 311.54 | 0.3062 | -879.2 | -615.0 | |
| 0.00 | 3.14 | 0.00 | 1.63 | 6.43 | 101.16 | 13.18 | 307.98 | 0.2888 | -1011.0 | -878.7 | |
| 0.00 | 4.76 | 0.00 | 2.46 | 8.21 | 100.02 | 12.05 | 315.17 | 0.2943 | 878.0 | 706.4 | |
| 0.00 | 1.44 | 0.00 | 0.75 | 8.54 | 99.97 | 12.00 | 316.08 | 0.2977 | -572.0 | -426.9 | |
| 0.00 | 2.04 | 0.00 | 1.05 | 6.80 | 99.83 | 11.85 | 312.00 | 0.2757 | 1013.0 | 829.1 | |
| 1.87 | 594.94 | 0.97 | 308.36 | 9.33 | 99.85 | 11.87 | 318.18 | 0.3058 | 691.0 | 420.5 | |
| 5.52 | 11.64 | 2.85 | 6.00 | 7.34 | 99.69 | 11.72 | 313.76 | 0.2801 | 1121.9 | 774.4 | |
| 1.19 | -34.00 | 0.62 | -34.00 | 9.96 | 99.69 | 11.71 | 319.93 | 0.3119 | 859.9 | 999999 | |
| 0.00 | 1.78 | 0.00 | 0.92 | 8.21 | 99.63 | 11.65 | 316.11 | 0.2896 | 935.0 | 851.5 | |
| 0.00 | 1.02 | 0.00 | 0.54 | 12.43 | 99.70 | 11.72 | 324.61 | 0.3441 | 833.0 | 616.2 | |
| 1.87 | -34.00 | 0.97 | -34.00 | 9.75 | 99.53 | 11.55 | 319.86 | 0.3075 | 746.4 | 999999 | |
| 0.00 | 3.57 | 0.00 | 1.85 | 8.63 | 99.49 | 11.51 | 317.46 | 0.2931 | 845.0 | 562.5 | |
| 0.00 | 2.29 | 0.00 | 1.17 | 5.42 | 99.34 | 11.37 | 309.19 | 0.2543 | -1200.0 | -974.9 | |
| 0.00 | 1.36 | 0.00 | 0.71 | 10.90 | 99.51 | 11.53 | 322.25 | 0.3221 | 726.0 | 554.4 | |
| 1.70 | -34.00 | 0.88 | -34.00 | 9.93 | 99.38 | 11.40 | 320.60 | 0.3082 | 798.0 | 999999 | |
| 0.00 | 1.61 | 0.00 | 0.84 | 10.84 | 99.17 | 11.19 | 322.95 | 0.3179 | 138.0 | 138.4 | |
| 1.78 | -34.00 | 0.93 | -34.00 | 10.25 | 98.63 | 10.65 | 323.16 | 0.3048 | 875.3 | 999999 | |
| 101.17 | -34.00 | 52.40 | -34.00 | 9.52 | 98.49 | 10.51 | 322.03 | 0.2936 | 1372.8 | 999999 | |
| 2.12 | -34.00 | 1.10 | -34.00 | 10.01 | 98.29 | 10.31 | 323.56 | 0.2980 | 879.3 | 999999 | |
| 0.00 | 1.70 | 0.00 | 0.87 | 7.28 | 97.21 | 9.24 | 320.39 | 0.2509 | 1150.0 | 828.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
