SDO HMI 2014-01-09 05:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.59 | 28.52 | 0.31 | 15.13 | -18.90 | 69.46 | -11.92 | 147.91 | 0.3355 | -7.5 | -15.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-09 05:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.10 | 0.00 | 0.56 | -17.74 | 81.96 | 0.58 | 182.31 | 0.2397 | 787.0 | 595.8 | |
| 0.00 | 1.87 | 0.00 | 0.94 | -13.76 | 80.04 | -1.34 | 172.42 | 0.1728 | -861.0 | -675.4 | |
| 0.00 | 1.02 | 0.00 | 0.52 | -16.96 | 76.96 | -4.42 | 161.90 | 0.2383 | 738.0 | 540.2 | |
| 0.00 | 1.61 | 0.00 | 0.83 | -18.53 | 74.99 | -6.40 | 157.27 | 0.2746 | 887.0 | 741.8 | |
| 0.00 | 0.93 | 0.00 | 0.48 | -18.74 | 74.88 | -6.50 | 157.27 | 0.2786 | 805.0 | 661.0 | |
| 0.00 | 1.78 | 0.00 | 0.93 | -19.80 | 74.34 | -7.05 | 157.14 | 0.2984 | 844.0 | 686.7 | |
| 0.00 | 1.53 | 0.00 | 0.79 | -19.95 | 74.17 | -7.21 | 156.88 | 0.3018 | 804.0 | 712.9 | |
| 0.00 | 2.46 | 0.00 | 1.27 | -18.18 | 74.13 | -7.26 | 154.04 | 0.2754 | 810.0 | 727.4 | |
| 0.00 | 1.53 | 0.00 | 0.79 | -17.70 | 74.15 | -7.24 | 153.27 | 0.2680 | 875.0 | 723.1 | |
| 0.59 | 3.99 | 0.31 | 2.06 | -18.08 | 73.03 | -8.35 | 150.60 | 0.2824 | -1092.9 | -828.2 | |
| 0.00 | 1.36 | 0.00 | 0.72 | -22.08 | 71.42 | -9.96 | 152.84 | 0.3526 | 705.0 | 655.0 | |
| 0.00 | 2.04 | 0.00 | 1.05 | -15.13 | 69.26 | -12.12 | 133.95 | 0.2829 | -859.0 | -784.1 | |
| 0.00 | 1.02 | 0.00 | 0.54 | -15.77 | 63.34 | -18.04 | 124.95 | 0.3651 | -827.0 | -658.8 | |
| 0.00 | 1.27 | 0.00 | 0.68 | -16.83 | 63.24 | -18.14 | 127.20 | 0.3758 | -149.0 | -329.9 | |
| 0.00 | 0.85 | 0.00 | 0.49 | -24.08 | 56.28 | -25.10 | 132.12 | 0.5243 | -674.0 | -466.7 | |
| 0.00 | 1.19 | 0.00 | 0.71 | -24.40 | 53.27 | -28.11 | 129.76 | 0.5603 | -786.0 | -650.3 | |
| 0.00 | 1.53 | 0.00 | 0.92 | -24.42 | 52.83 | -28.55 | 129.39 | 0.5654 | -510.0 | -363.4 | |
| 0.00 | 0.59 | 0.00 | 0.34 | -17.67 | 54.08 | -27.30 | 119.24 | 0.5029 | -622.0 | -464.0 | |
| 0.00 | 0.85 | 0.00 | 0.51 | -23.66 | 52.87 | -28.52 | 128.28 | 0.5592 | -680.0 | -521.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
