SDO HMI 2014-01-09 13:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 120.05 | 790.99 | 66.95 | 440.18 | 9.03 | 100.53 | 23.52 | 299.40 | 0.4535 | 105.8 | 150.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-09 13:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.31 | 8.07 | 1.94 | 4.73 | 8.43 | 106.89 | 29.88 | 292.64 | 0.5361 | -689.9 | -426.9 | |
| 0.42 | 2.55 | 0.25 | 1.49 | 8.18 | 106.67 | 29.65 | 292.36 | 0.5316 | -727.4 | -603.1 | |
| 0.00 | 1.53 | 0.00 | 0.89 | 8.72 | 106.65 | 29.63 | 293.32 | 0.5343 | -416.0 | -334.4 | |
| 2.72 | 13.51 | 1.59 | 7.87 | 8.39 | 106.48 | 29.46 | 292.85 | 0.5302 | -794.6 | -633.1 | |
| 0.51 | -4.00 | 0.30 | -4.00 | 8.20 | 106.33 | 29.31 | 292.62 | 0.5271 | -815.7 | 999999 | |
| 5.86 | 124.66 | 3.40 | 71.90 | 8.33 | 105.82 | 28.81 | 293.21 | 0.5209 | -864.1 | -462.3 | |
| 0.00 | 1.70 | 0.00 | 0.99 | 10.59 | 105.49 | 28.48 | 297.42 | 0.5301 | -690.0 | -526.5 | |
| 7.99 | -6.00 | 4.60 | -6.00 | 8.25 | 105.24 | 28.23 | 293.50 | 0.5125 | -1047.5 | 999999 | |
| 6.12 | -6.00 | 3.51 | -6.00 | 8.09 | 104.96 | 27.94 | 293.41 | 0.5076 | -1228.0 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.68 | 7.19 | 104.82 | 27.81 | 291.83 | 0.5007 | -845.0 | -734.0 | |
| 0.00 | 1.53 | 0.00 | 0.88 | 8.87 | 104.58 | 27.57 | 295.11 | 0.5071 | -764.0 | -637.3 | |
| 2.29 | 22.52 | 1.31 | 12.80 | 7.47 | 104.37 | 27.36 | 292.70 | 0.4960 | -857.4 | -780.7 | |
| 0.00 | 3.14 | 0.00 | 1.78 | 6.30 | 104.30 | 27.29 | 290.52 | 0.4885 | -692.0 | -618.3 | |
| 4.33 | 7.65 | 2.47 | 4.36 | 7.83 | 104.27 | 27.25 | 293.45 | 0.4965 | -1079.7 | -806.5 | |
| 0.00 | 3.06 | 0.00 | 1.74 | 8.22 | 104.19 | 27.18 | 294.23 | 0.4978 | -795.0 | -719.7 | |
| 1.19 | -12.00 | 0.68 | -12.00 | 7.53 | 104.11 | 27.10 | 293.00 | 0.4926 | -1058.4 | 999999 | |
| 1.36 | -12.00 | 0.77 | -12.00 | 7.38 | 104.10 | 27.09 | 292.72 | 0.4916 | -908.6 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.72 | 6.95 | 104.01 | 26.99 | 291.98 | 0.4879 | -513.0 | -432.9 | |
| 0.00 | 1.10 | 0.00 | 0.63 | 8.21 | 103.89 | 26.88 | 294.45 | 0.4936 | -643.0 | -571.8 | |
| 4.08 | -12.00 | 2.31 | -12.00 | 7.55 | 103.78 | 26.76 | 293.29 | 0.4880 | -1073.7 | 999999 | |
| 0.00 | 0.93 | 0.00 | 0.53 | 7.03 | 103.74 | 26.73 | 292.34 | 0.4846 | -759.0 | -648.8 | |
| 0.00 | 2.21 | 0.00 | 1.25 | 8.06 | 103.78 | 26.77 | 294.26 | 0.4911 | -701.0 | -586.6 | |
| 0.00 | 1.27 | 0.00 | 0.72 | 6.82 | 103.66 | 26.65 | 291.99 | 0.4823 | -825.0 | -620.4 | |
| 0.00 | 1.78 | 0.00 | 1.01 | 7.81 | 103.60 | 26.58 | 293.94 | 0.4871 | -1071.0 | -895.3 | |
| 0.00 | 1.02 | 0.00 | 0.58 | 7.99 | 103.61 | 26.60 | 294.27 | 0.4883 | -754.0 | -651.2 | |
| 0.00 | 1.78 | 0.00 | 1.01 | 8.08 | 103.45 | 26.44 | 294.56 | 0.4866 | -818.0 | -689.2 | |
| 0.00 | 1.61 | 0.00 | 0.91 | 7.62 | 103.38 | 26.37 | 293.75 | 0.4830 | -991.0 | -829.8 | |
| 0.00 | 0.76 | 0.00 | 0.43 | 7.92 | 103.24 | 26.22 | 294.44 | 0.4827 | -686.0 | -543.2 | |
| 0.00 | 3.57 | 0.00 | 2.00 | 7.10 | 102.85 | 25.84 | 293.16 | 0.4724 | -934.0 | -692.0 | |
| 0.00 | 1.78 | 0.00 | 1.00 | 7.58 | 102.82 | 25.80 | 294.12 | 0.4747 | -909.0 | -791.6 | |
| 0.00 | 2.38 | 0.00 | 1.34 | 8.27 | 102.73 | 25.72 | 295.52 | 0.4779 | -765.0 | -594.0 | |
| 0.00 | 0.59 | 0.00 | 0.33 | 7.84 | 102.50 | 25.49 | 294.89 | 0.4720 | -631.0 | -502.3 | |
| 0.68 | 7.56 | 0.38 | 4.23 | 7.68 | 102.33 | 25.32 | 294.74 | 0.4685 | -858.0 | -793.3 | |
| 0.00 | 1.44 | 0.00 | 0.80 | 7.30 | 101.45 | 24.44 | 294.74 | 0.4538 | -754.0 | -577.7 | |
| 0.00 | 1.53 | 0.00 | 0.85 | 7.77 | 101.29 | 24.27 | 295.85 | 0.4545 | -977.0 | -916.9 | |
| 1.44 | 560.69 | 0.81 | 308.10 | 9.34 | 101.23 | 24.22 | 298.97 | 0.4646 | -898.8 | 427.0 | |
| 0.42 | -36.00 | 0.24 | -36.00 | 9.36 | 100.84 | 23.83 | 299.40 | 0.4594 | 566.4 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.70 | 8.52 | 100.13 | 23.12 | 298.49 | 0.4436 | 519.0 | 383.0 | |
| 0.00 | 1.61 | 0.00 | 0.89 | 7.38 | 99.93 | 22.92 | 296.34 | 0.4327 | 890.0 | 736.9 | |
| 1.19 | -36.00 | 0.66 | -36.00 | 9.08 | 99.45 | 22.44 | 300.33 | 0.4386 | 844.4 | 999999 | |
| 9.86 | -36.00 | 5.45 | -36.00 | 10.02 | 99.42 | 22.41 | 302.21 | 0.4456 | 982.2 | 999999 | |
| 9.26 | -36.00 | 5.09 | -36.00 | 9.67 | 98.98 | 21.96 | 302.05 | 0.4369 | 1024.4 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.69 | 5.96 | 98.42 | 21.40 | 294.78 | 0.4015 | -747.0 | -605.9 | |
| 50.14 | -36.00 | 27.44 | -36.00 | 9.33 | 98.47 | 21.46 | 301.95 | 0.4273 | 1289.8 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.55 | 6.70 | 98.16 | 21.15 | 296.72 | 0.4029 | 789.0 | 630.7 | |
| 0.00 | 0.25 | 0.00 | 0.14 | 7.54 | 98.17 | 21.16 | 298.56 | 0.4092 | -631.0 | -494.3 | |
| 4.93 | -36.00 | 2.69 | -36.00 | 9.22 | 97.92 | 20.91 | 302.41 | 0.4190 | 1299.9 | 999999 | |
| 1.02 | -36.00 | 0.55 | -36.00 | 9.16 | 97.72 | 20.71 | 302.52 | 0.4159 | 1277.5 | 999999 | |
| 0.93 | -36.00 | 0.51 | -36.00 | 9.22 | 97.60 | 20.59 | 302.80 | 0.4147 | 1112.5 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.66 | 12.78 | 97.29 | 20.27 | 310.03 | 0.4432 | 840.0 | 683.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
