SDO HMI 2014-01-10 08:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.98 | 304.66 | 22.22 | 164.95 | 5.85 | 45.23 | -21.35 | 64.36 | 0.4041 | -926.6 | -431.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-10 08:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.40 | 0.00 | 1.73 | 9.06 | 66.27 | -0.31 | 1.33 | 0.2282 | -920.0 | -739.4 | |
| 0.00 | 1.53 | 0.00 | 0.78 | 9.85 | 65.38 | -1.20 | 4.91 | 0.2425 | -727.0 | -609.5 | |
| 0.00 | 1.53 | 0.00 | 0.80 | 12.34 | 59.10 | -7.48 | 24.28 | 0.3105 | -901.0 | -736.1 | |
| 0.00 | 2.55 | 0.00 | 1.32 | 10.26 | 59.09 | -7.49 | 27.45 | 0.2794 | -774.0 | -634.4 | |
| 0.00 | 1.79 | 0.00 | 0.93 | 10.94 | 58.11 | -8.47 | 29.26 | 0.2973 | -775.0 | -624.8 | |
| 0.00 | 1.28 | 0.00 | 0.65 | 6.55 | 56.85 | -9.73 | 42.52 | 0.2495 | -826.0 | -689.5 | |
| 0.00 | 0.94 | 0.00 | 0.48 | 5.51 | 55.60 | -10.97 | 48.94 | 0.2525 | -881.0 | -712.0 | |
| 0.00 | 1.70 | 0.00 | 0.89 | 9.50 | 52.94 | -13.64 | 45.01 | 0.3304 | -977.0 | -889.1 | |
| 0.00 | 1.28 | 0.00 | 0.67 | 9.75 | 52.74 | -13.84 | 44.89 | 0.3355 | -740.0 | -676.3 | |
| 0.00 | 0.85 | 0.00 | 0.46 | 11.29 | 48.83 | -17.75 | 48.83 | 0.3990 | -877.0 | -696.5 | |
| 0.00 | 1.28 | 0.00 | 0.69 | 11.63 | 48.74 | -17.84 | 48.32 | 0.4035 | -845.0 | -704.5 | |
| 0.00 | 1.79 | 0.00 | 0.97 | 11.82 | 48.32 | -18.26 | 48.62 | 0.4106 | -952.0 | -725.7 | |
| 0.00 | 1.62 | 0.00 | 0.88 | 12.25 | 48.29 | -18.29 | 47.87 | 0.4154 | -685.0 | -551.7 | |
| 0.00 | 0.94 | 0.00 | 0.49 | 4.44 | 48.12 | -18.45 | 65.45 | 0.3485 | -783.0 | -558.6 | |
| 0.00 | 1.79 | 0.00 | 1.00 | 15.09 | 46.24 | -20.34 | 46.02 | 0.4683 | -869.0 | -689.7 | |
| 40.98 | 273.31 | 22.22 | 148.24 | 5.49 | 44.49 | -22.09 | 66.76 | 0.4091 | -1455.4 | -434.0 | |
| 0.00 | 0.94 | 0.00 | 0.52 | 11.14 | 43.18 | -23.40 | 56.65 | 0.4684 | -815.0 | -657.4 | |
| 0.00 | 0.60 | 0.00 | 0.33 | 4.75 | 42.10 | -24.48 | 70.42 | 0.4401 | 726.0 | 527.1 | |
| 0.00 | 1.11 | 0.00 | 0.61 | -1.32 | 41.14 | -25.44 | 84.56 | 0.4333 | 731.0 | 586.3 | |
| 0.00 | 1.02 | 0.00 | 0.57 | 3.42 | 40.08 | -26.50 | 74.59 | 0.4639 | 878.0 | 694.8 | |
| 0.00 | 1.45 | 0.00 | 0.81 | 3.15 | 40.05 | -26.52 | 75.16 | 0.4632 | 782.0 | 649.6 | |
| 0.00 | 0.60 | 0.00 | 0.34 | 6.22 | 38.46 | -28.12 | 70.04 | 0.5005 | 778.0 | 510.9 | |
| 0.00 | 1.36 | 0.00 | 0.79 | 7.12 | 37.42 | -29.16 | 69.05 | 0.5198 | 817.0 | 680.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
