SDO HMI 2014-01-10 13:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 60.17 | 360.59 | 46.59 | 279.66 | -16.07 | 14.11 | -49.74 | 107.57 | 0.7714 | 882.7 | 239.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-10 13:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.71 | 358.38 | 28.22 | 277.67 | -16.16 | 14.56 | -49.29 | 107.76 | 0.7668 | 1079.1 | 244.8 | |
| 22.95 | -1.00 | 17.97 | -1.00 | -15.93 | 13.59 | -50.26 | 107.29 | 0.7767 | 779.1 | 999999 | |
| 0.51 | -1.00 | 0.40 | -1.00 | -15.86 | 12.98 | -50.87 | 107.10 | 0.7830 | 231.8 | 999999 | |
| 0.00 | 1.36 | 0.00 | 1.20 | -16.66 | 8.16 | -55.68 | 107.38 | 0.8313 | -510.0 | -446.1 | |
| 0.00 | 0.85 | 0.00 | 0.79 | -17.35 | 6.37 | -57.47 | 107.97 | 0.8482 | -492.0 | -344.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
