group	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
11944	477.28	2446.18	322.64	1642.18	-9.73	99.85	42.07	259.70	0.6712	440.8	178.1

previous   or   next   observation for the same group / back to the solar disc SDO HMI 2014-01-11 00:00:24 UT See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!)

spot	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
1	0.00	1.10	0.00	0.84	-8.37	107.21	49.43	262.50	0.7603	-307.0	-276.2
2	172.22	1182.67	125.39	851.10	-8.79	104.98	47.20	261.83	0.7349	1008.8	306.6
3	51.40	-2.00	36.42	-2.00	-8.27	103.51	45.73	262.47	0.7172	1111.0	999999
4	0.00	3.74	0.00	2.62	-6.01	103.05	45.27	265.62	0.7110	645.0	475.8
5	0.00	0.68	0.00	0.48	-10.37	103.69	45.91	259.55	0.7208	92.0	105.9
6	0.00	4.42	0.00	3.09	-6.76	102.92	45.15	264.57	0.7095	301.0	283.8
7	2.04	-2.00	1.43	-2.00	-8.85	103.13	45.35	261.62	0.7129	905.5	999999
8	0.00	1.44	0.00	1.01	-5.47	102.70	44.93	266.40	0.7067	-548.0	-429.6
9	0.00	2.04	0.00	1.42	-6.60	102.53	44.75	264.78	0.7046	527.0	265.0
10	28.63	-2.00	19.93	-2.00	-8.38	102.51	44.73	262.25	0.7050	1177.2	999999
11	1.53	-2.00	1.06	-2.00	-7.94	102.44	44.66	262.88	0.7040	1037.4	999999
12	0.00	0.85	0.00	0.59	-6.53	102.06	44.28	264.87	0.6988	626.0	479.0
13	1.95	-2.00	1.35	-2.00	-8.04	102.16	44.38	262.71	0.7006	1185.0	999999
14	0.00	2.80	0.00	1.95	-10.05	102.31	44.53	259.85	0.7038	439.0	421.2
15	0.00	0.68	0.00	0.47	-10.45	102.12	44.35	259.27	0.7020	-119.0	-139.1
16	2.97	22.01	2.03	15.04	-6.73	101.54	43.77	264.56	0.6924	898.0	486.3
17	0.00	0.93	0.00	0.66	-14.42	102.95	45.17	253.82	0.7175	402.0	334.9
18	0.00	1.61	0.00	1.11	-9.60	101.73	43.95	260.43	0.6963	214.0	229.8
19	0.00	0.85	0.00	0.58	-5.83	101.25	43.47	265.87	0.6885	455.0	404.7
20	0.00	0.68	0.00	0.48	-14.95	102.70	44.92	253.04	0.7156	516.0	395.5
21	3.14	67.20	2.14	45.27	-6.99	101.12	43.34	264.18	0.6872	802.8	537.8
22	6.63	-21.00	4.48	-21.00	-7.25	100.78	43.00	263.79	0.6830	796.1	999999
23	0.00	1.27	0.00	0.87	-10.35	101.11	43.33	259.29	0.6893	-362.0	-300.3
24	0.76	1.61	0.52	1.09	-10.05	100.40	42.62	259.63	0.6802	-378.7	-291.0
25	1.53	10.62	1.02	7.08	-9.54	99.99	42.22	260.35	0.6745	-359.8	-154.7
26	0.00	3.31	0.00	2.20	-8.66	99.59	41.81	261.61	0.6685	764.0	688.6
27	0.00	1.78	0.00	1.18	-7.43	99.39	41.61	263.45	0.6652	721.0	591.1
28	0.00	0.93	0.00	0.63	-13.68	100.15	42.37	254.28	0.6826	610.0	514.8
29	0.00	1.10	0.00	0.73	-9.45	99.22	41.44	260.38	0.6645	707.0	592.5
30	0.00	1.61	0.00	1.06	-9.58	99.00	41.22	260.16	0.6618	443.0	377.7
31	0.00	0.85	0.00	0.55	-8.25	98.30	40.52	262.12	0.6515	471.0	426.7
32	0.00	1.70	0.00	1.10	-8.29	97.95	40.18	262.02	0.6470	729.0	624.8
33	0.00	0.68	0.00	0.43	-5.46	97.13	39.35	266.41	0.6348	-546.0	-483.4
34	0.00	0.93	0.00	0.60	-7.41	97.27	39.49	263.35	0.6373	629.0	533.5
35	0.00	1.27	0.00	0.81	-5.50	96.87	39.09	266.35	0.6312	-636.0	-593.3
36	0.00	2.46	0.00	1.57	-7.08	96.62	38.84	263.83	0.6284	799.0	609.8
37	81.48	412.66	52.31	264.82	-10.86	97.06	39.29	257.91	0.6383	1198.3	353.0
38	0.00	0.76	0.00	0.48	-6.70	96.47	38.69	264.42	0.6261	-618.0	-526.1
39	0.00	1.27	0.00	0.81	-6.97	96.38	38.60	263.98	0.6251	-315.0	-261.9
40	0.00	0.85	0.00	0.54	-5.86	96.25	38.47	265.78	0.6228	-730.0	-641.9
41	0.59	1.61	0.38	1.03	-9.37	96.54	38.76	260.18	0.6292	838.7	769.6
42	0.00	1.78	0.00	1.13	-7.63	96.33	38.56	262.93	0.6248	518.0	479.8
43	0.00	1.78	0.00	1.13	-9.63	95.96	38.18	259.67	0.6218	693.0	627.5
44	0.00	0.85	0.00	0.54	-9.40	95.86	38.08	260.03	0.6201	757.0	607.5
45	0.00	8.16	0.00	5.13	-9.97	95.67	37.89	259.08	0.6183	295.0	260.2
46	4.84	34.92	3.02	21.80	-9.42	95.18	37.40	259.88	0.6109	-875.4	-413.4
47	4.33	11.21	2.70	6.98	-10.03	94.99	37.21	258.86	0.6093	373.7	303.6
48	0.59	4.67	0.37	2.91	-10.59	94.96	37.18	257.93	0.6097	725.6	472.6
49	0.00	3.40	0.00	2.11	-10.75	94.79	37.01	257.64	0.6077	350.0	309.3
50	0.00	1.44	0.00	0.90	-9.95	94.57	36.79	258.91	0.6034	97.0	-8.2
51	0.00	2.12	0.00	1.31	-9.53	94.18	36.40	259.55	0.5974	-659.0	-592.6
52	0.00	1.44	0.00	0.89	-8.65	93.85	36.08	260.97	0.5917	-532.0	-453.3
53	0.00	9.26	0.00	5.69	-9.95	93.86	36.08	258.77	0.5937	224.0	-99.0
54	0.00	1.02	0.00	0.62	-8.65	93.71	35.93	260.94	0.5897	-514.0	-482.2
55	0.00	2.04	0.00	1.25	-9.48	93.73	35.95	259.54	0.5911	-589.0	-462.2
56	0.51	3.14	0.31	1.92	-8.36	93.57	35.79	261.41	0.5874	-763.8	-564.1
57	0.00	3.65	0.00	2.23	-8.92	93.63	35.85	260.47	0.5889	-589.0	-581.1
58	0.00	0.76	0.00	0.47	-10.34	93.76	35.98	258.10	0.5930	120.0	95.1
59	3.48	426.51	2.14	259.49	-11.06	93.79	36.01	256.91	0.5946	-729.5	-139.0
60	0.00	0.76	0.00	0.47	-12.69	94.00	36.22	254.26	0.6012	860.0	689.7
61	0.00	1.10	0.00	0.68	-10.32	93.54	35.76	258.09	0.5898	-559.0	-410.0
62	0.00	9.60	0.00	5.85	-9.29	93.37	35.59	259.81	0.5859	-828.0	-754.2
63	1.44	-59.00	0.88	-59.00	-10.89	93.50	35.72	257.12	0.5904	-707.0	999999
64	0.00	1.27	0.00	0.77	-8.41	93.20	35.42	261.29	0.5823	-730.0	-598.5
65	0.34	-59.00	0.21	-59.00	-10.57	93.38	35.61	257.64	0.5882	-759.5	999999
66	0.00	2.21	0.00	1.35	-9.50	93.25	35.47	259.42	0.5845	-827.0	-706.2
67	4.16	-59.00	2.54	-59.00	-10.39	93.25	35.47	257.90	0.5860	-819.9	999999
68	0.00	1.95	0.00	1.18	-6.03	92.81	35.03	265.38	0.5749	-570.0	-520.5
69	0.00	1.44	0.00	0.89	-13.30	93.69	35.91	253.16	0.5986	723.0	584.4
70	8.24	-59.00	5.03	-59.00	-11.35	93.16	35.38	256.26	0.5866	-772.9	999999
71	2.46	-59.00	1.50	-59.00	-10.67	93.07	35.29	257.39	0.5840	-575.8	999999
72	0.00	2.63	0.00	1.60	-9.22	92.89	35.11	259.84	0.5790	-793.0	-736.7
73	0.00	1.53	0.00	0.92	-9.20	92.56	34.78	259.81	0.5743	-875.0	-614.2
74	0.00	1.19	0.00	0.72	-8.94	92.49	34.71	260.26	0.5730	-822.0	-735.2
75	17.25	-59.00	10.48	-59.00	-11.52	92.74	34.96	255.87	0.5812	-888.3	999999
76	0.00	1.10	0.00	0.67	-9.59	92.49	34.71	259.12	0.5740	-708.0	-529.9
77	1.10	-59.00	0.67	-59.00	-12.20	92.73	34.95	254.70	0.5828	-548.5	999999
78	4.42	-59.00	2.68	-59.00	-11.88	92.61	34.83	255.21	0.5803	-697.8	999999
79	5.44	-59.00	3.31	-59.00	-12.63	92.61	34.83	253.94	0.5822	-192.9	999999
80	5.61	-59.00	3.41	-59.00	-12.93	92.58	34.80	253.43	0.5827	914.4	999999
81	2.21	-59.00	1.34	-59.00	-11.56	92.38	34.60	255.69	0.5764	-918.1	999999
82	1.95	-59.00	1.18	-59.00	-11.35	92.35	34.57	256.04	0.5755	-999.1	999999
83	1.36	-59.00	0.82	-59.00	-11.66	92.21	34.43	255.48	0.5742	-892.9	999999
84	0.00	4.76	0.00	2.86	-10.18	92.02	34.24	258.00	0.5684	-951.0	-744.4
85	18.18	-59.00	11.00	-59.00	-12.28	92.26	34.48	254.42	0.5766	-701.4	999999
86	0.00	2.21	0.00	1.32	-9.44	91.86	34.08	259.26	0.5648	-850.0	-609.6
87	0.00	1.53	0.00	0.91	-5.16	91.50	33.72	266.87	0.5558	-592.0	-418.2
88	0.00	1.02	0.00	0.61	-9.23	91.84	34.06	259.63	0.5642	-768.0	-584.4
89	0.00	2.55	0.00	1.53	-9.98	91.81	34.03	258.31	0.5651	-806.0	-679.4
90	0.00	1.10	0.00	0.66	-8.79	91.68	33.90	260.38	0.5613	-769.0	-600.8
91	0.00	1.19	0.00	0.72	-11.43	91.89	34.11	255.78	0.5692	-897.0	-770.6
92	0.00	1.27	0.00	0.76	-9.33	91.63	33.85	259.41	0.5614	-731.0	-620.9
93	1.87	-59.00	1.13	-59.00	-12.00	91.89	34.11	254.80	0.5707	-913.5	999999
94	0.00	1.78	0.00	1.07	-10.46	91.69	33.91	257.43	0.5643	-736.0	-624.4
95	0.00	1.70	0.00	1.02	-11.70	91.78	34.00	255.27	0.5684	-625.0	-608.6
96	0.00	1.44	0.00	0.86	-10.70	91.65	33.87	257.00	0.5642	-754.0	-605.5
97	1.44	-59.00	0.87	-59.00	-11.86	91.69	33.91	254.98	0.5675	-939.5	999999
98	0.34	2.12	0.20	1.27	-11.59	91.51	33.73	255.38	0.5644	-806.8	-736.0
99	4.25	12.83	2.57	7.76	-14.36	91.90	34.12	250.76	0.5778	868.2	544.5
100	0.00	1.27	0.00	0.76	-12.08	91.36	33.58	254.49	0.5635	-792.0	-643.9
101	11.05	-59.00	6.62	-59.00	-12.61	91.40	33.62	253.57	0.5656	-799.5	999999
102	0.00	1.02	0.00	0.60	-9.71	90.92	33.14	258.57	0.5519	-702.0	-608.3
103	0.00	1.10	0.00	0.66	-11.82	91.03	33.26	254.84	0.5583	-719.0	-608.9
104	2.29	-59.00	1.37	-59.00	-13.05	91.03	33.25	252.68	0.5617	-664.6	999999
105	0.00	3.91	0.00	2.33	-12.27	90.88	33.10	253.99	0.5574	-746.0	-663.7
106	0.00	2.38	0.00	1.42	-12.78	90.95	33.17	253.12	0.5599	-828.0	-771.1
107	0.00	1.02	0.00	0.61	-12.01	90.77	32.99	254.42	0.5551	-756.0	-674.9
108	0.00	2.80	0.00	1.66	-12.19	90.62	32.84	254.04	0.5535	-769.0	-687.4
109	0.00	2.04	0.00	1.21	-12.49	90.62	32.84	253.51	0.5544	-882.0	-704.9
110	0.00	1.27	0.00	0.76	-13.68	90.77	32.99	251.47	0.5601	-605.0	-541.1
111	0.00	1.27	0.00	0.75	-11.78	90.49	32.71	254.73	0.5505	-884.0	-699.5
112	0.00	1.87	0.00	1.10	-10.13	90.18	32.40	257.64	0.5422	-690.0	-606.5
113	0.00	0.76	0.00	0.45	-11.82	90.31	32.54	254.61	0.5482	-798.0	-604.6
114	0.00	3.31	0.00	1.96	-12.26	90.34	32.56	253.82	0.5498	-921.0	-742.5
115	0.00	1.19	0.00	0.70	-10.75	90.07	32.30	256.46	0.5421	-607.0	-547.3
116	0.00	2.12	0.00	1.25	-10.58	90.02	32.24	256.77	0.5408	-762.0	-725.2
117	0.00	1.44	0.00	0.85	-10.97	89.99	32.21	256.05	0.5414	-865.0	-733.7
118	0.00	1.36	0.00	0.79	-5.36	89.50	31.72	266.48	0.5266	-586.0	-565.9
119	2.55	5.10	1.51	3.01	-12.81	90.09	32.31	252.75	0.5480	-914.0	-787.9
120	0.00	1.10	0.00	0.65	-13.47	90.19	32.41	251.62	0.5515	-713.0	-621.3
121	0.00	3.14	0.00	1.85	-12.46	90.01	32.23	253.35	0.5457	-787.0	-724.6
122	0.00	1.10	0.00	0.65	-11.74	89.91	32.13	254.61	0.5423	-907.0	-818.1
123	2.21	67.20	1.31	39.85	-13.83	90.14	32.36	250.96	0.5520	-680.3	-190.6
124	0.00	1.95	0.00	1.14	-10.89	89.63	31.85	256.08	0.5360	-854.0	-758.7
125	1.19	-123.00	0.70	-123.00	-13.71	89.98	32.20	251.09	0.5493	-956.9	999999
126	0.00	1.87	0.00	1.10	-13.00	89.80	32.02	252.29	0.5445	-762.0	-638.0
127	7.31	-123.00	4.31	-123.00	-13.90	89.68	31.90	250.63	0.5460	-928.6	999999
128	0.00	1.27	0.00	0.75	-12.48	89.41	31.63	253.09	0.5373	-809.0	-704.7
129	0.00	2.97	0.00	1.74	-12.27	89.31	31.53	253.42	0.5353	-881.0	-746.4
130	0.00	1.61	0.00	0.94	-12.58	89.17	31.39	252.82	0.5343	-726.0	-538.5
131	0.00	1.53	0.00	0.90	-13.08	89.20	31.43	251.90	0.5364	-580.0	-545.8
132	0.00	0.93	0.00	0.55	-12.76	89.02	31.24	252.41	0.5327	-812.0	-712.0
133	0.00	1.02	0.00	0.59	-12.41	88.76	30.98	252.96	0.5279	-856.0	-770.4
134	0.00	1.10	0.00	0.65	-15.51	88.40	30.62	247.12	0.5349	-724.0	-631.5
135	0.00	0.85	0.00	0.49	-13.56	87.47	29.70	250.23	0.5138	-750.0	-690.3
136	0.00	0.34	0.00	0.20	-15.11	86.93	29.15	247.02	0.5128	-655.0	-562.2
137	0.00	1.87	0.00	1.07	-15.04	86.32	28.54	246.80	0.5041	-739.0	-611.8
138	0.00	1.70	0.00	0.95	-12.12	84.79	27.01	251.70	0.4696	-819.0	-638.8

	Proj. U	-  Projected umbra area in millionths of solar disc, negative values indicate
	that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
	Proj. WS	-  Projected whole spot area in millionths of solar disc, negative values indicate
	that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7.
	Corr. U	-  Corrected umbra area in millionths of solar hemisphere, for negative values see above
	Corr. WS	-  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
	B	-  Heliographic latitude B; positive: North, negative: South
	L	-  Heliographic longitude L
	LCM	-  Longitudinal distance from the Sun's central meridian
	Pos. angle	-  Position angle
	r	-  Distance from the centre of Sun's disc in terms of Sun's radius
	MU	-  Mean magnetic field within the umbra contour averaged the pixel values with sign.
	MP	-  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
