SDO HMI 2014-01-11 07:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.73 | 51.11 | 8.01 | 25.97 | -13.06 | 44.27 | -9.68 | 133.67 | 0.2272 | -330.5 | -313.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-11 07:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.73 | -12.78 | 47.47 | -6.49 | 143.74 | 0.1872 | 1083.0 | 771.6 | |
| 0.00 | 1.19 | 0.00 | 0.60 | -13.22 | 46.60 | -7.36 | 141.73 | 0.2021 | 815.0 | 696.1 | |
| 0.00 | 2.98 | 0.00 | 1.50 | -12.95 | 46.18 | -7.77 | 139.31 | 0.2031 | 781.0 | 786.1 | |
| 0.00 | 1.53 | 0.00 | 0.77 | -12.53 | 46.04 | -7.91 | 137.39 | 0.1994 | 891.0 | 631.4 | |
| 0.00 | 1.45 | 0.00 | 0.73 | -12.50 | 45.86 | -8.09 | 136.64 | 0.2012 | 831.0 | 734.5 | |
| 0.00 | 1.62 | 0.00 | 0.82 | -12.84 | 44.32 | -9.64 | 132.92 | 0.2239 | -1155.0 | -875.7 | |
| 2.89 | 39.87 | 1.47 | 20.30 | -12.98 | 44.04 | -9.92 | 132.60 | 0.2291 | -1246.0 | -674.0 | |
| 0.00 | 1.02 | 0.00 | 0.52 | -13.81 | 43.82 | -10.14 | 134.62 | 0.2413 | 512.0 | 340.3 | |
| 12.84 | -7.00 | 6.54 | -7.00 | -13.13 | 43.78 | -10.17 | 132.37 | 0.2338 | -1053.1 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
