SDO HMI 2014-01-11 13:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 386.56 | 2215.01 | 298.66 | 1686.45 | -9.75 | 99.97 | 49.30 | 260.51 | 0.7571 | 514.9 | 180.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-11 13:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.59 | 0.00 | 0.54 | -13.87 | 107.72 | 57.04 | 256.16 | 0.8411 | -437.0 | -380.3 | |
| 0.00 | 3.91 | 0.00 | 3.40 | -10.72 | 106.15 | 55.47 | 259.84 | 0.8245 | -304.0 | -270.7 | |
| 187.32 | 1060.51 | 157.32 | 883.63 | -8.78 | 104.68 | 54.01 | 262.17 | 0.8094 | 1029.4 | 257.1 | |
| 1.53 | -3.00 | 1.26 | -3.00 | -7.93 | 103.96 | 53.28 | 263.22 | 0.8018 | 1003.7 | 999999 | |
| 2.04 | -3.00 | 1.68 | -3.00 | -8.82 | 103.88 | 53.21 | 262.09 | 0.8012 | 950.0 | 999999 | |
| 2.55 | -3.00 | 2.07 | -3.00 | -8.95 | 103.21 | 52.54 | 261.91 | 0.7942 | 948.8 | 999999 | |
| 1.70 | -3.00 | 1.38 | -3.00 | -10.12 | 103.12 | 52.45 | 260.43 | 0.7937 | 350.6 | 999999 | |
| 18.19 | -3.00 | 14.49 | -3.00 | -8.34 | 102.41 | 51.73 | 262.66 | 0.7856 | 1130.3 | 999999 | |
| 1.44 | -3.00 | 1.14 | -3.00 | -7.94 | 102.10 | 51.42 | 263.16 | 0.7821 | 1055.6 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.94 | -9.58 | 102.12 | 51.45 | 261.07 | 0.7829 | 544.0 | 501.9 | |
| 0.00 | 0.34 | 0.00 | 0.27 | -10.46 | 102.27 | 51.59 | 259.94 | 0.7849 | -234.0 | -207.0 | |
| 3.99 | 6.37 | 3.11 | 4.96 | -6.56 | 101.31 | 50.64 | 264.93 | 0.7734 | 741.9 | 571.5 | |
| 0.00 | 10.11 | 0.00 | 7.92 | -10.24 | 101.50 | 50.82 | 260.18 | 0.7765 | 482.0 | 370.9 | |
| 0.00 | 1.10 | 0.00 | 0.89 | -14.20 | 102.52 | 51.84 | 255.22 | 0.7907 | 464.0 | 370.2 | |
| 0.00 | 1.10 | 0.00 | 0.85 | -6.48 | 100.65 | 49.97 | 265.04 | 0.7660 | 664.0 | 563.9 | |
| 2.55 | 27.37 | 1.96 | 20.96 | -7.25 | 100.71 | 50.03 | 264.03 | 0.7668 | 799.4 | 532.7 | |
| 0.00 | 1.10 | 0.00 | 0.84 | -7.80 | 100.42 | 49.75 | 263.31 | 0.7637 | 677.0 | 605.6 | |
| 0.85 | 2.21 | 0.65 | 1.68 | -7.98 | 100.32 | 49.64 | 263.06 | 0.7625 | 676.7 | 564.4 | |
| 1.19 | 5.10 | 0.90 | 3.84 | -8.76 | 99.71 | 49.03 | 262.02 | 0.7560 | 653.4 | 444.3 | |
| 0.00 | 0.76 | 0.00 | 0.58 | -9.03 | 99.62 | 48.95 | 261.65 | 0.7551 | 560.0 | 502.4 | |
| 0.00 | 2.89 | 0.00 | 2.17 | -9.19 | 99.47 | 48.79 | 261.43 | 0.7534 | 620.0 | 528.0 | |
| 0.00 | 1.36 | 0.00 | 1.02 | -8.84 | 99.36 | 48.68 | 261.89 | 0.7520 | 655.0 | 575.6 | |
| 0.00 | 1.95 | 0.00 | 1.47 | -9.57 | 99.45 | 48.77 | 260.92 | 0.7534 | 533.0 | 519.0 | |
| 0.00 | 1.19 | 0.00 | 0.89 | -9.87 | 99.51 | 48.83 | 260.53 | 0.7542 | 404.0 | 315.0 | |
| 0.00 | 0.42 | 0.00 | 0.32 | -10.02 | 99.45 | 48.77 | 260.32 | 0.7536 | 425.0 | 427.6 | |
| 0.00 | 3.57 | 0.00 | 2.66 | -9.26 | 99.21 | 48.53 | 261.32 | 0.7505 | 718.0 | 655.2 | |
| 0.00 | 1.10 | 0.00 | 0.81 | -8.44 | 98.44 | 47.76 | 262.38 | 0.7412 | 608.0 | 546.4 | |
| 0.00 | 0.85 | 0.00 | 0.62 | -8.09 | 98.38 | 47.71 | 262.86 | 0.7404 | 600.0 | 475.7 | |
| 0.00 | 1.02 | 0.00 | 0.75 | -10.84 | 98.62 | 47.94 | 259.16 | 0.7448 | -178.0 | -174.8 | |
| 0.00 | 0.59 | 0.00 | 0.43 | -7.41 | 97.75 | 47.08 | 263.76 | 0.7328 | 605.0 | 562.1 | |
| 0.00 | 0.76 | 0.00 | 0.55 | -5.93 | 97.05 | 46.37 | 265.78 | 0.7243 | -580.0 | -507.8 | |
| 0.00 | 1.53 | 0.00 | 1.10 | -7.00 | 97.05 | 46.37 | 264.30 | 0.7243 | 559.0 | 490.2 | |
| 57.20 | 373.45 | 41.14 | 268.25 | -10.80 | 97.15 | 46.47 | 259.07 | 0.7277 | 1227.9 | 306.3 | |
| 0.00 | 1.02 | 0.00 | 0.72 | -7.65 | 96.57 | 45.90 | 263.39 | 0.7188 | 516.0 | 386.8 | |
| 0.00 | 2.46 | 0.00 | 1.74 | -9.14 | 96.32 | 45.65 | 261.29 | 0.7166 | 548.0 | 541.3 | |
| 0.00 | 1.70 | 0.00 | 1.20 | -8.32 | 96.15 | 45.48 | 262.43 | 0.7140 | -73.0 | -119.2 | |
| 0.93 | -33.00 | 0.67 | -33.00 | -11.42 | 96.66 | 45.98 | 258.15 | 0.7226 | 1019.0 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.72 | -8.59 | 96.15 | 45.47 | 262.05 | 0.7142 | -472.0 | -430.2 | |
| 0.00 | 1.61 | 0.00 | 1.14 | -8.80 | 96.10 | 45.42 | 261.75 | 0.7136 | -423.0 | -318.6 | |
| 0.00 | 0.85 | 0.00 | 0.60 | -7.62 | 95.80 | 45.13 | 263.39 | 0.7095 | 596.0 | 508.7 | |
| 4.93 | 71.99 | 3.45 | 50.16 | -9.89 | 95.72 | 45.05 | 260.19 | 0.7099 | 820.6 | 270.3 | |
| 5.27 | 42.07 | 3.66 | 29.17 | -7.85 | 95.37 | 44.69 | 263.04 | 0.7042 | 906.2 | 460.1 | |
| 6.46 | -41.00 | 4.51 | -41.00 | -9.30 | 95.58 | 44.91 | 261.01 | 0.7077 | -705.6 | 999999 | |
| 1.19 | -41.00 | 0.83 | -41.00 | -9.81 | 95.50 | 44.82 | 260.28 | 0.7071 | 828.0 | 999999 | |
| 0.76 | -41.00 | 0.53 | -41.00 | -10.31 | 94.99 | 44.32 | 259.51 | 0.7014 | 840.2 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.58 | -9.86 | 94.46 | 43.78 | 260.10 | 0.6944 | -371.0 | -324.0 | |
| 0.00 | 1.53 | 0.00 | 1.05 | -9.54 | 94.32 | 43.65 | 260.55 | 0.6924 | -635.0 | -665.1 | |
| 6.97 | 48.10 | 4.76 | 32.93 | -9.04 | 94.20 | 43.53 | 261.26 | 0.6905 | -495.4 | -114.3 | |
| 0.00 | 1.36 | 0.00 | 0.93 | -9.72 | 94.31 | 43.63 | 260.29 | 0.6924 | -586.0 | -551.7 | |
| 1.78 | 61.02 | 1.22 | 41.66 | -10.47 | 94.11 | 43.43 | 259.17 | 0.6906 | -445.7 | 14.5 | |
| 0.76 | -50.00 | 0.52 | -50.00 | -11.12 | 94.18 | 43.50 | 258.24 | 0.6923 | -597.6 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.94 | -12.37 | 94.43 | 43.75 | 256.49 | 0.6970 | 765.0 | 650.5 | |
| 0.00 | 0.93 | 0.00 | 0.63 | -8.36 | 93.61 | 42.94 | 262.21 | 0.6826 | -600.0 | -553.8 | |
| 2.29 | -50.00 | 1.56 | -50.00 | -10.48 | 93.86 | 43.18 | 259.13 | 0.6876 | -715.4 | 999999 | |
| 2.04 | 5.61 | 1.38 | 3.79 | -8.83 | 93.56 | 42.88 | 261.51 | 0.6822 | -760.5 | -610.5 | |
| 0.00 | 1.87 | 0.00 | 1.26 | -9.16 | 93.56 | 42.89 | 261.03 | 0.6826 | -581.0 | -525.2 | |
| 1.44 | 335.88 | 0.99 | 225.74 | -12.23 | 94.06 | 43.39 | 256.62 | 0.6924 | 434.6 | -90.9 | |
| 0.00 | 0.85 | 0.00 | 0.57 | -9.61 | 93.55 | 42.87 | 260.37 | 0.6828 | -585.0 | -534.7 | |
| 11.05 | -50.00 | 7.49 | -50.00 | -10.40 | 93.64 | 42.96 | 259.21 | 0.6847 | -815.9 | 999999 | |
| 0.00 | 1.95 | 0.00 | 1.34 | -13.01 | 94.06 | 43.39 | 255.50 | 0.6936 | 831.0 | 699.9 | |
| 0.00 | 1.19 | 0.00 | 0.82 | -13.29 | 94.04 | 43.36 | 255.11 | 0.6938 | 780.0 | 647.6 | |
| 0.00 | 0.85 | 0.00 | 0.57 | -9.20 | 93.28 | 42.61 | 260.94 | 0.6791 | -622.0 | -593.1 | |
| 0.00 | 1.19 | 0.00 | 0.81 | -13.50 | 93.84 | 43.16 | 254.76 | 0.6917 | 789.0 | 674.6 | |
| 5.35 | -57.00 | 3.62 | -57.00 | -11.34 | 93.35 | 42.68 | 257.80 | 0.6823 | -845.3 | 999999 | |
| 0.00 | 1.61 | 0.00 | 1.08 | -9.22 | 93.00 | 42.33 | 260.89 | 0.6755 | -749.0 | -621.3 | |
| 0.00 | 1.02 | 0.00 | 0.69 | -10.25 | 93.12 | 42.45 | 259.37 | 0.6781 | 231.0 | 336.7 | |
| 0.00 | 0.93 | 0.00 | 0.64 | -13.63 | 93.70 | 43.02 | 254.54 | 0.6903 | 763.0 | 659.8 | |
| 0.00 | 0.51 | 0.00 | 0.34 | -5.48 | 92.41 | 41.74 | 266.44 | 0.6663 | -733.0 | -598.8 | |
| 0.00 | 1.61 | 0.00 | 1.08 | -9.05 | 92.74 | 42.06 | 261.11 | 0.6720 | -678.0 | -602.7 | |
| 14.28 | -57.00 | 9.60 | -57.00 | -11.69 | 93.01 | 42.33 | 257.24 | 0.6785 | -868.0 | 999999 | |
| 2.89 | -57.00 | 1.93 | -57.00 | -11.65 | 92.63 | 41.96 | 257.24 | 0.6738 | -847.8 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.56 | -9.43 | 92.27 | 41.59 | 260.49 | 0.6663 | -552.0 | -552.3 | |
| 2.38 | -57.00 | 1.59 | -57.00 | -12.10 | 92.60 | 41.92 | 256.57 | 0.6740 | -573.8 | 999999 | |
| 0.00 | 2.12 | 0.00 | 1.40 | -9.35 | 92.06 | 41.38 | 260.59 | 0.6635 | -844.0 | -697.8 | |
| 7.05 | -57.00 | 4.74 | -57.00 | -13.20 | 92.70 | 42.02 | 254.96 | 0.6772 | 965.6 | 999999 | |
| 1.78 | -57.00 | 1.19 | -57.00 | -12.14 | 92.32 | 41.64 | 256.45 | 0.6706 | -802.3 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.84 | -10.13 | 91.97 | 41.30 | 259.41 | 0.6633 | -647.0 | -539.7 | |
| 1.61 | -57.00 | 1.08 | -57.00 | -12.64 | 92.38 | 41.70 | 255.72 | 0.6722 | -581.7 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.56 | -10.34 | 91.93 | 41.25 | 259.08 | 0.6629 | -684.0 | -488.9 | |
| 0.00 | 2.72 | 0.00 | 1.80 | -11.91 | 92.08 | 41.40 | 256.75 | 0.6671 | -842.0 | -643.6 | |
| 0.34 | 1.19 | 0.22 | 0.79 | -11.41 | 91.91 | 41.23 | 257.47 | 0.6642 | -702.5 | -618.0 | |
| 0.00 | 0.68 | 0.00 | 0.45 | -12.10 | 91.75 | 41.07 | 256.40 | 0.6633 | -765.0 | -725.0 | |
| 0.00 | 0.93 | 0.00 | 0.62 | -11.96 | 91.72 | 41.05 | 256.61 | 0.6627 | -709.0 | -611.2 | |
| 0.00 | 1.10 | 0.00 | 0.72 | -11.08 | 91.41 | 40.73 | 257.89 | 0.6573 | -731.0 | -636.9 | |
| 5.27 | 8.84 | 3.51 | 5.89 | -14.55 | 92.05 | 41.38 | 252.83 | 0.6720 | 790.7 | 572.9 | |
| 5.27 | -57.00 | 3.48 | -57.00 | -12.65 | 91.61 | 40.94 | 255.55 | 0.6625 | -807.7 | 999999 | |
| 0.00 | 1.10 | 0.00 | 0.72 | -10.52 | 91.08 | 40.40 | 258.67 | 0.6523 | -753.0 | -639.7 | |
| 0.00 | 0.76 | 0.00 | 0.50 | -9.61 | 90.87 | 40.19 | 260.04 | 0.6483 | -639.0 | -627.7 | |
| 2.63 | 7.65 | 1.72 | 5.00 | -12.13 | 91.12 | 40.44 | 256.23 | 0.6553 | -820.5 | -608.1 | |
| 0.93 | 2.63 | 0.61 | 1.72 | -11.85 | 90.87 | 40.19 | 256.61 | 0.6516 | -822.0 | -670.8 | |
| 0.00 | 2.12 | 0.00 | 1.37 | -9.54 | 90.50 | 39.83 | 260.11 | 0.6435 | -714.0 | -565.2 | |
| 0.00 | 4.25 | 0.00 | 2.78 | -12.98 | 90.88 | 40.20 | 254.89 | 0.6539 | -515.0 | -505.9 | |
| 0.00 | 1.70 | 0.00 | 1.10 | -10.70 | 90.40 | 39.72 | 258.29 | 0.6437 | -650.0 | -466.9 | |
| 0.00 | 1.78 | 0.00 | 1.15 | -10.94 | 90.40 | 39.72 | 257.92 | 0.6440 | -738.0 | -657.2 | |
| 0.00 | 1.19 | 0.00 | 0.76 | -9.50 | 90.15 | 39.47 | 260.13 | 0.6387 | -737.0 | -547.4 | |
| 0.00 | 0.68 | 0.00 | 0.45 | -14.45 | 91.02 | 40.34 | 252.71 | 0.6589 | -413.0 | -315.2 | |
| 0.68 | 2.21 | 0.45 | 1.45 | -14.12 | 90.91 | 40.23 | 253.17 | 0.6568 | -598.4 | -428.7 | |
| 0.00 | 2.21 | 0.00 | 1.44 | -12.99 | 90.68 | 40.01 | 254.83 | 0.6514 | -668.0 | -582.5 | |
| 0.00 | 0.85 | 0.00 | 0.55 | -12.81 | 90.65 | 39.97 | 255.09 | 0.6506 | -809.0 | -731.0 | |
| 0.00 | 1.02 | 0.00 | 0.66 | -13.62 | 90.65 | 39.97 | 253.86 | 0.6523 | -620.0 | -520.0 | |
| 0.00 | 1.10 | 0.00 | 0.71 | -11.75 | 90.30 | 39.62 | 256.64 | 0.6440 | -687.0 | -595.6 | |
| 0.68 | 2.29 | 0.44 | 1.48 | -11.11 | 90.07 | 39.40 | 257.60 | 0.6400 | -891.5 | -821.8 | |
| 0.00 | 0.76 | 0.00 | 0.49 | -12.47 | 90.31 | 39.63 | 255.54 | 0.6455 | -691.0 | -624.3 | |
| 0.00 | 0.76 | 0.00 | 0.49 | -11.76 | 90.10 | 39.43 | 256.59 | 0.6415 | -712.0 | -621.4 | |
| 1.19 | 2.97 | 0.77 | 1.92 | -12.83 | 90.26 | 39.58 | 254.97 | 0.6456 | -805.6 | -706.7 | |
| 0.00 | 2.12 | 0.00 | 1.37 | -12.21 | 90.14 | 39.47 | 255.91 | 0.6429 | -728.0 | -699.5 | |
| 0.00 | 1.10 | 0.00 | 0.71 | -11.58 | 90.04 | 39.36 | 256.85 | 0.6403 | -782.0 | -695.9 | |
| 0.00 | 0.93 | 0.00 | 0.61 | -13.48 | 90.38 | 39.71 | 254.00 | 0.6486 | -695.0 | -579.3 | |
| 0.00 | 0.68 | 0.00 | 0.43 | -8.79 | 89.40 | 38.72 | 261.15 | 0.6280 | -590.0 | -498.8 | |
| 2.46 | 25.16 | 1.60 | 16.31 | -13.83 | 90.14 | 39.46 | 253.42 | 0.6462 | -711.9 | 37.0 | |
| 0.00 | 1.27 | 0.00 | 0.80 | -8.30 | 89.00 | 38.32 | 261.89 | 0.6221 | -801.0 | -699.3 | |
| 0.00 | 1.02 | 0.00 | 0.64 | -8.54 | 89.02 | 38.35 | 261.51 | 0.6227 | -749.0 | -595.1 | |
| 0.00 | 2.04 | 0.00 | 1.31 | -12.98 | 89.58 | 38.90 | 254.58 | 0.6371 | -621.0 | -521.2 | |
| 5.35 | 8.75 | 3.44 | 5.63 | -13.88 | 89.63 | 38.96 | 253.20 | 0.6399 | -868.2 | -610.0 | |
| 0.00 | 1.19 | 0.00 | 0.76 | -12.54 | 89.38 | 38.71 | 255.22 | 0.6336 | -686.0 | -632.9 | |
| 0.00 | 1.36 | 0.00 | 0.87 | -12.79 | 89.19 | 38.52 | 254.78 | 0.6317 | -662.0 | -495.1 | |
| 0.00 | 0.85 | 0.00 | 0.54 | -12.58 | 89.16 | 38.48 | 255.10 | 0.6308 | -661.0 | -580.5 | |
| 0.00 | 1.27 | 0.00 | 0.81 | -12.40 | 89.05 | 38.37 | 255.35 | 0.6290 | -760.0 | -683.1 | |
| 0.00 | 2.12 | 0.00 | 1.33 | -14.35 | 87.75 | 37.08 | 251.90 | 0.6168 | -511.0 | -547.9 | |
| 0.00 | 1.19 | 0.00 | 0.72 | -10.90 | 84.96 | 34.29 | 256.82 | 0.5704 | -577.0 | -533.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
