SDO HMI 2014-01-11 20:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 67.19 | 474.58 | 40.43 | 286.43 | -16.33 | 13.57 | -33.24 | 112.87 | 0.5729 | 832.9 | 354.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-11 20:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.76 | 0.00 | 0.44 | -14.05 | 17.46 | -29.36 | 110.75 | 0.5106 | 731.0 | 621.3 | |
| 39.76 | 461.35 | 23.80 | 277.71 | -16.37 | 14.29 | -32.52 | 113.27 | 0.5637 | 1331.4 | 382.9 | |
| 3.14 | -2.00 | 1.89 | -2.00 | -16.81 | 13.95 | -32.86 | 113.84 | 0.5701 | 631.3 | 999999 | |
| 0.00 | 1.10 | 0.00 | 0.68 | -19.07 | 13.21 | -33.61 | 117.14 | 0.5901 | 707.0 | 494.8 | |
| 2.46 | -2.00 | 1.49 | -2.00 | -16.31 | 13.35 | -33.46 | 112.70 | 0.5759 | 1237.1 | 999999 | |
| 19.62 | -2.00 | 11.91 | -2.00 | -16.17 | 12.97 | -33.84 | 112.29 | 0.5803 | 1166.5 | 999999 | |
| 1.53 | -2.00 | 0.93 | -2.00 | -16.15 | 12.57 | -34.25 | 112.08 | 0.5856 | 578.2 | 999999 | |
| 0.68 | -2.00 | 0.41 | -2.00 | -15.91 | 12.54 | -34.27 | 111.67 | 0.5850 | 357.0 | 999999 | |
| 0.00 | 1.53 | 0.00 | 0.99 | -16.91 | 8.38 | -38.44 | 111.58 | 0.6419 | -708.0 | -590.5 | |
| 0.00 | 1.19 | 0.00 | 0.77 | -16.54 | 7.64 | -39.18 | 110.76 | 0.6500 | -575.0 | -424.8 | |
| 0.00 | 1.44 | 0.00 | 0.94 | -16.66 | 7.45 | -39.36 | 110.86 | 0.6526 | -637.0 | -466.2 | |
| 0.00 | 1.10 | 0.00 | 0.72 | -14.59 | 7.10 | -39.72 | 107.64 | 0.6512 | -700.0 | -619.5 | |
| 0.00 | 1.19 | 0.00 | 0.79 | -15.37 | 5.75 | -41.06 | 108.42 | 0.6700 | -836.0 | -659.3 | |
| 0.00 | 0.93 | 0.00 | 0.64 | -18.99 | 4.41 | -42.40 | 113.20 | 0.6961 | -678.0 | -601.5 | |
| 0.00 | 1.44 | 0.00 | 0.99 | -18.16 | 4.41 | -42.40 | 112.04 | 0.6936 | -683.0 | -567.8 | |
| 0.00 | 0.85 | 0.00 | 0.58 | -17.19 | 4.53 | -42.28 | 110.70 | 0.6895 | -528.0 | -508.0 | |
| 0.00 | 1.19 | 0.00 | 0.83 | -17.92 | 3.38 | -43.43 | 111.40 | 0.7049 | -713.0 | -541.3 | |
| 0.00 | 0.51 | 0.00 | 0.35 | -17.14 | 3.53 | -43.28 | 110.34 | 0.7011 | -534.0 | -476.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
