SDO HMI 2014-01-11 23:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 75.53 | 493.85 | 44.69 | 292.73 | -16.34 | 13.59 | -31.57 | 113.72 | 0.5506 | 1023.9 | 334.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-11 23:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 45.11 | 485.71 | 26.55 | 287.38 | -16.39 | 14.26 | -30.90 | 114.15 | 0.5420 | 1334.9 | 352.9 | |
| 30.08 | -1.00 | 17.92 | -1.00 | -16.25 | 12.99 | -32.17 | 113.22 | 0.5584 | 1151.5 | 999999 | |
| 0.00 | 0.93 | 0.00 | 0.59 | -16.39 | 7.59 | -37.57 | 111.08 | 0.6292 | -670.0 | -562.5 | |
| 0.00 | 2.04 | 0.00 | 1.30 | -14.53 | 7.10 | -38.06 | 108.01 | 0.6298 | -703.0 | -530.2 | |
| 0.34 | 1.19 | 0.22 | 0.77 | -15.28 | 5.72 | -39.44 | 108.74 | 0.6494 | -739.0 | -634.7 | |
| 0.00 | 1.10 | 0.00 | 0.74 | -19.05 | 4.37 | -40.79 | 113.83 | 0.6775 | -606.0 | -533.8 | |
| 0.00 | 1.10 | 0.00 | 0.74 | -17.28 | 3.89 | -41.27 | 111.13 | 0.6776 | -509.0 | -414.7 | |
| 0.00 | 1.78 | 0.00 | 1.21 | -17.99 | 3.44 | -41.72 | 112.00 | 0.6851 | -788.0 | -553.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
