SDO HMI 2014-01-12 11:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 236.05 | 1547.33 | 250.70 | 1614.98 | -9.87 | 100.50 | 61.89 | 260.98 | 0.8787 | 386.4 | 156.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-12 11:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.02 | 0.00 | 1.36 | -7.97 | 107.18 | 68.58 | 263.12 | 0.9302 | -191.0 | -185.2 | |
| 93.51 | 760.44 | 114.41 | 907.92 | -9.07 | 105.05 | 66.45 | 261.97 | 0.9160 | 633.3 | 178.7 | |
| 0.00 | 2.04 | 0.00 | 2.47 | -11.02 | 104.86 | 66.26 | 259.83 | 0.9146 | 12.0 | -18.5 | |
| 12.92 | -2.00 | 14.99 | -2.00 | -8.74 | 103.69 | 65.08 | 262.35 | 0.9063 | 984.4 | 999999 | |
| 1.19 | -2.00 | 1.37 | -2.00 | -9.08 | 103.52 | 64.91 | 261.97 | 0.9050 | 947.1 | 999999 | |
| 5.02 | -2.00 | 5.71 | -2.00 | -8.54 | 103.13 | 64.52 | 262.58 | 0.9022 | 868.4 | 999999 | |
| 1.79 | -2.00 | 2.00 | -2.00 | -8.57 | 102.72 | 64.11 | 262.55 | 0.8991 | 800.0 | 999999 | |
| 0.34 | 1.19 | 0.37 | 1.31 | -6.97 | 102.07 | 63.47 | 264.34 | 0.8943 | 520.5 | 484.9 | |
| 11.39 | -2.00 | 12.60 | -2.00 | -8.44 | 102.34 | 63.73 | 262.69 | 0.8962 | 1011.4 | 999999 | |
| 1.87 | 3.91 | 2.02 | 4.21 | -6.92 | 101.53 | 62.92 | 264.42 | 0.8901 | 511.0 | 358.2 | |
| 0.00 | 1.53 | 0.00 | 1.64 | -6.21 | 101.37 | 62.77 | 265.21 | 0.8890 | -227.0 | -138.5 | |
| 0.00 | 0.77 | 0.00 | 0.82 | -6.37 | 101.34 | 62.73 | 265.04 | 0.8887 | -251.0 | -162.7 | |
| 0.00 | 1.11 | 0.00 | 1.17 | -6.39 | 101.02 | 62.41 | 265.03 | 0.8861 | 373.0 | 288.4 | |
| 1.70 | 3.23 | 1.79 | 3.40 | -6.72 | 100.83 | 62.23 | 264.65 | 0.8845 | 590.8 | 476.2 | |
| 0.68 | 2.21 | 0.74 | 2.40 | -11.47 | 101.71 | 63.11 | 259.29 | 0.8914 | -366.8 | -302.7 | |
| 0.00 | 0.51 | 0.00 | 0.54 | -10.60 | 100.79 | 62.19 | 260.26 | 0.8840 | 334.0 | 255.3 | |
| 1.96 | 3.49 | 1.98 | 3.53 | -8.98 | 99.57 | 60.97 | 262.10 | 0.8739 | 622.0 | 462.8 | |
| 0.00 | 0.85 | 0.00 | 0.86 | -9.57 | 99.68 | 61.08 | 261.42 | 0.8749 | 392.0 | 390.7 | |
| 0.51 | 2.30 | 0.51 | 2.31 | -9.24 | 99.28 | 60.67 | 261.80 | 0.8714 | 648.2 | 547.7 | |
| 0.00 | 0.94 | 0.00 | 0.94 | -9.82 | 99.45 | 60.85 | 261.13 | 0.8730 | 452.0 | 404.6 | |
| 0.00 | 1.02 | 0.00 | 0.97 | -7.41 | 97.56 | 58.96 | 263.92 | 0.8565 | 561.0 | 398.1 | |
| 0.00 | 0.77 | 0.00 | 0.76 | -12.20 | 98.79 | 60.19 | 258.37 | 0.8679 | 403.0 | 342.0 | |
| 0.00 | 1.19 | 0.00 | 1.19 | -13.15 | 98.98 | 60.38 | 257.29 | 0.8698 | -443.0 | -425.8 | |
| 2.47 | 16.24 | 2.31 | 15.15 | -7.36 | 96.92 | 58.31 | 263.99 | 0.8507 | 703.1 | 541.1 | |
| 0.00 | 1.96 | 0.00 | 1.92 | -13.22 | 98.40 | 59.79 | 257.18 | 0.8649 | -343.0 | -259.8 | |
| 0.00 | 0.94 | 0.00 | 0.90 | -12.23 | 97.78 | 59.18 | 258.29 | 0.8592 | 296.0 | 224.6 | |
| 40.38 | 636.66 | 38.12 | 573.12 | -10.77 | 97.17 | 58.57 | 259.97 | 0.8533 | 942.5 | 190.8 | |
| 0.00 | 0.68 | 0.00 | 0.66 | -13.46 | 97.89 | 59.29 | 256.87 | 0.8607 | -461.0 | -432.5 | |
| 2.47 | 5.53 | 2.25 | 5.05 | -8.78 | 96.05 | 57.45 | 262.30 | 0.8428 | -520.1 | -326.8 | |
| 1.19 | -27.00 | 1.09 | -27.00 | -9.58 | 96.20 | 57.59 | 261.36 | 0.8442 | 715.2 | 999999 | |
| 1.02 | -27.00 | 0.95 | -27.00 | -11.50 | 96.59 | 57.99 | 259.10 | 0.8483 | 778.2 | 999999 | |
| 1.53 | -27.00 | 1.37 | -27.00 | -9.41 | 95.10 | 56.50 | 261.54 | 0.8339 | -398.1 | 999999 | |
| 1.02 | -27.00 | 0.90 | -27.00 | -9.53 | 94.59 | 55.99 | 261.38 | 0.8290 | -507.8 | 999999 | |
| 3.23 | -27.00 | 2.84 | -27.00 | -10.04 | 94.56 | 55.95 | 260.76 | 0.8288 | -426.9 | 999999 | |
| 0.00 | 0.68 | 0.00 | 0.58 | -5.51 | 93.30 | 54.70 | 266.28 | 0.8163 | -421.0 | -355.1 | |
| 0.00 | 1.96 | 0.00 | 1.67 | -5.95 | 93.31 | 54.71 | 265.74 | 0.8163 | -429.0 | -352.8 | |
| 0.00 | 1.19 | 0.00 | 1.05 | -11.53 | 94.55 | 55.94 | 258.96 | 0.8293 | -234.0 | -215.7 | |
| 1.70 | -27.00 | 1.49 | -27.00 | -10.80 | 94.28 | 55.68 | 259.83 | 0.8264 | -119.8 | 999999 | |
| 2.64 | -27.00 | 2.29 | -27.00 | -10.63 | 94.13 | 55.52 | 260.03 | 0.8248 | -409.2 | 999999 | |
| 0.00 | 5.78 | 0.00 | 4.98 | -9.25 | 93.73 | 55.12 | 261.69 | 0.8205 | -601.0 | -508.9 | |
| 0.60 | 10.20 | 0.51 | 8.82 | -8.90 | 93.59 | 54.99 | 262.12 | 0.8191 | -556.9 | -249.8 | |
| 5.36 | -27.00 | 4.63 | -27.00 | -10.95 | 93.79 | 55.19 | 259.62 | 0.8217 | -621.3 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.87 | -9.27 | 93.36 | 54.76 | 261.66 | 0.8169 | -560.0 | -447.4 | |
| 0.00 | 1.45 | 0.00 | 1.23 | -8.99 | 93.09 | 54.49 | 262.00 | 0.8142 | -645.0 | -581.9 | |
| 7.23 | -27.00 | 6.21 | -27.00 | -11.29 | 93.57 | 54.96 | 259.19 | 0.8197 | -766.6 | 999999 | |
| 7.57 | -27.00 | 6.46 | -27.00 | -11.64 | 93.25 | 54.64 | 258.75 | 0.8167 | -766.7 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.79 | -9.26 | 92.64 | 54.03 | 261.66 | 0.8096 | -660.0 | -629.3 | |
| 0.00 | 0.94 | 0.00 | 0.82 | -14.18 | 94.08 | 55.48 | 255.72 | 0.8265 | 556.0 | 405.0 | |
| 0.00 | 0.85 | 0.00 | 0.72 | -10.38 | 92.80 | 54.20 | 260.27 | 0.8117 | -390.0 | -342.9 | |
| 0.34 | 1.53 | 0.30 | 1.33 | -14.23 | 93.78 | 55.17 | 255.64 | 0.8236 | 606.5 | 552.6 | |
| 0.00 | 0.60 | 0.00 | 0.50 | -12.44 | 92.86 | 54.26 | 257.74 | 0.8133 | -174.0 | -155.1 | |
| 2.38 | 19.64 | 1.98 | 16.27 | -10.77 | 92.24 | 53.63 | 259.76 | 0.8061 | -559.9 | -537.8 | |
| 2.13 | -52.00 | 1.77 | -52.00 | -10.51 | 92.17 | 53.56 | 260.08 | 0.8053 | -563.8 | 999999 | |
| 0.00 | 3.57 | 0.00 | 3.00 | -12.31 | 92.61 | 54.01 | 257.88 | 0.8108 | -427.0 | -378.7 | |
| 5.27 | -27.00 | 4.48 | -27.00 | -13.82 | 92.94 | 54.34 | 256.05 | 0.8152 | 966.1 | 999999 | |
| 3.15 | -27.00 | 2.66 | -27.00 | -13.35 | 92.68 | 54.08 | 256.60 | 0.8122 | -217.2 | 999999 | |
| 1.87 | -52.00 | 1.55 | -52.00 | -10.70 | 91.91 | 53.31 | 259.83 | 0.8028 | -764.5 | 999999 | |
| 2.21 | -27.00 | 1.85 | -27.00 | -12.74 | 92.43 | 53.83 | 257.34 | 0.8093 | -542.2 | 999999 | |
| 0.00 | 1.53 | 0.00 | 1.28 | -12.12 | 92.25 | 53.64 | 258.09 | 0.8070 | -232.0 | -241.1 | |
| 1.19 | -27.00 | 1.01 | -27.00 | -13.78 | 92.67 | 54.06 | 256.08 | 0.8124 | 724.6 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.99 | -11.92 | 92.09 | 53.48 | 258.32 | 0.8052 | -416.0 | -338.4 | |
| 1.02 | -27.00 | 0.86 | -27.00 | -13.22 | 92.43 | 53.83 | 256.74 | 0.8096 | -481.2 | 999999 | |
| 1.11 | -27.00 | 0.93 | -27.00 | -13.10 | 92.39 | 53.79 | 256.88 | 0.8092 | -383.8 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.91 | -11.24 | 91.85 | 53.25 | 259.15 | 0.8024 | -434.0 | -370.2 | |
| 1.19 | 3.23 | 0.99 | 2.69 | -12.31 | 92.10 | 53.49 | 257.84 | 0.8056 | -587.6 | -441.4 | |
| 0.00 | 2.55 | 0.00 | 2.11 | -12.11 | 91.84 | 53.23 | 258.06 | 0.8028 | -625.0 | -554.7 | |
| 0.68 | -27.00 | 0.57 | -27.00 | -12.85 | 92.01 | 53.40 | 257.16 | 0.8051 | -699.5 | 999999 | |
| 0.00 | 1.79 | 0.00 | 1.47 | -12.24 | 91.67 | 53.07 | 257.89 | 0.8012 | -716.0 | -523.5 | |
| 1.79 | 2.89 | 1.50 | 2.43 | -14.97 | 92.36 | 53.76 | 254.57 | 0.8105 | 655.0 | 516.3 | |
| 0.00 | 0.85 | 0.00 | 0.70 | -12.40 | 91.52 | 52.91 | 257.68 | 0.7998 | -547.0 | -461.2 | |
| 0.00 | 9.61 | 0.00 | 7.94 | -13.47 | 91.74 | 53.14 | 256.36 | 0.8029 | 71.0 | 9.5 | |
| 0.00 | 0.68 | 0.00 | 0.54 | -8.43 | 90.47 | 51.87 | 262.63 | 0.7869 | -220.0 | -265.0 | |
| 0.00 | 1.19 | 0.00 | 0.97 | -11.94 | 91.09 | 52.48 | 258.21 | 0.7950 | -663.0 | -580.9 | |
| 0.00 | 0.68 | 0.00 | 0.55 | -11.77 | 90.94 | 52.34 | 258.42 | 0.7934 | -630.0 | -596.0 | |
| 0.00 | 1.62 | 0.00 | 1.32 | -12.78 | 91.18 | 52.57 | 257.17 | 0.7966 | -567.0 | -507.5 | |
| 0.00 | 2.04 | 0.00 | 1.65 | -12.29 | 90.89 | 52.28 | 257.76 | 0.7932 | -638.0 | -572.5 | |
| 0.00 | 0.85 | 0.00 | 0.69 | -12.05 | 90.77 | 52.17 | 258.05 | 0.7918 | -737.0 | -656.5 | |
| 0.00 | 1.19 | 0.00 | 0.94 | -8.26 | 89.82 | 51.21 | 262.83 | 0.7798 | -743.0 | -638.7 | |
| 0.00 | 1.36 | 0.00 | 1.08 | -10.03 | 90.12 | 51.52 | 260.58 | 0.7837 | -650.0 | -520.9 | |
| 0.00 | 0.85 | 0.00 | 0.69 | -14.26 | 91.14 | 52.54 | 255.31 | 0.7975 | -453.0 | -346.8 | |
| 0.00 | 1.02 | 0.00 | 0.80 | -8.60 | 89.59 | 50.99 | 262.39 | 0.7774 | -707.0 | -649.2 | |
| 0.00 | 1.02 | 0.00 | 0.82 | -13.50 | 90.70 | 52.09 | 256.22 | 0.7923 | -517.0 | -406.4 | |
| 0.00 | 1.45 | 0.00 | 1.15 | -12.14 | 90.30 | 51.70 | 257.90 | 0.7870 | -647.0 | -530.5 | |
| 0.43 | 1.28 | 0.34 | 1.03 | -13.81 | 90.45 | 51.84 | 255.79 | 0.7900 | -502.6 | -330.0 | |
| 0.00 | 1.70 | 0.00 | 1.35 | -12.70 | 90.02 | 51.41 | 257.16 | 0.7844 | -701.0 | -553.2 | |
| 0.00 | 2.47 | 0.00 | 1.94 | -13.69 | 89.43 | 50.83 | 255.82 | 0.7792 | -659.0 | -530.9 | |
| 0.00 | 0.85 | 0.00 | 0.66 | -12.97 | 88.89 | 50.29 | 256.69 | 0.7726 | -535.0 | -535.5 | |
| 0.00 | 0.26 | 0.00 | 0.19 | -13.80 | 86.83 | 48.23 | 255.32 | 0.7510 | -500.0 | -538.7 | |
| 0.00 | 1.19 | 0.00 | 0.86 | -12.82 | 85.01 | 46.40 | 256.38 | 0.7290 | -617.0 | -493.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
