SDO HMI 2014-01-12 15:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 75.29 | 140.46 | 38.64 | 72.07 | -17.88 | 29.79 | -6.61 | 155.24 | 0.2617 | 145.5 | 189.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-12 15:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 41.98 | 78.01 | 21.47 | 39.91 | -17.68 | 30.86 | -5.54 | 158.37 | 0.2508 | 1146.6 | 624.2 | |
| 0.00 | 0.93 | 0.00 | 0.48 | -16.17 | 30.60 | -5.80 | 154.79 | 0.2291 | 797.0 | 661.5 | |
| 0.00 | 6.80 | 0.00 | 3.49 | -18.26 | 30.32 | -6.09 | 157.38 | 0.2632 | 680.0 | 436.8 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -17.44 | 30.19 | -6.22 | 155.61 | 0.2514 | 704.0 | 468.2 | |
| 0.00 | 2.29 | 0.00 | 1.18 | -18.64 | 28.86 | -7.55 | 153.40 | 0.2792 | -1087.0 | -748.7 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -18.42 | 28.56 | -7.85 | 152.11 | 0.2783 | -812.0 | -600.1 | |
| 33.31 | 49.71 | 17.17 | 25.61 | -18.14 | 28.10 | -8.31 | 150.25 | 0.2780 | -1080.3 | -713.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
