SDO HMI 2014-01-13 05:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 89.70 | 501.97 | 47.10 | 263.70 | -16.49 | 13.18 | -15.53 | 129.76 | 0.3352 | 1222.2 | 386.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-13 05:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.28 | 0.00 | 0.65 | -14.41 | 17.22 | -11.49 | 132.35 | 0.2623 | 1175.0 | 807.8 | |
| 1.11 | 493.20 | 0.58 | 258.88 | -17.00 | 13.93 | -14.78 | 132.19 | 0.3308 | 963.3 | 404.5 | |
| 51.61 | -2.00 | 27.03 | -2.00 | -16.58 | 13.90 | -14.81 | 131.13 | 0.3267 | 1421.0 | 999999 | |
| 8.16 | -2.00 | 4.30 | -2.00 | -16.73 | 12.77 | -15.94 | 129.52 | 0.3425 | 1199.6 | 999999 | |
| 28.82 | -2.00 | 15.19 | -2.00 | -16.30 | 12.42 | -16.29 | 127.93 | 0.3428 | 1293.8 | 999999 | |
| 0.00 | 2.89 | 0.00 | 1.62 | -19.01 | 4.53 | -24.17 | 123.79 | 0.4678 | -808.0 | -692.3 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -18.54 | 3.37 | -25.34 | 121.83 | 0.4795 | -854.0 | -648.2 | |
| 0.00 | 3.49 | 0.00 | 1.93 | -12.43 | 3.34 | -25.37 | 109.40 | 0.4455 | -842.0 | -548.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
