SDO HMI 2014-01-14 06:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.83 | 65.49 | 11.36 | 35.62 | 16.44 | 27.32 | 12.32 | 330.23 | 0.4135 | -17.5 | 6.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-14 06:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.19 | 20.32 | 0.65 | 11.12 | 16.08 | 30.09 | 15.10 | 324.31 | 0.4308 | -843.6 | -624.4 | |
| 7.14 | -1.00 | 3.91 | -1.00 | 15.88 | 29.79 | 14.80 | 324.57 | 0.4256 | -1071.0 | 999999 | |
| 1.11 | 2.30 | 0.60 | 1.25 | 15.96 | 29.17 | 14.17 | 325.84 | 0.4210 | -823.3 | -621.5 | |
| 2.38 | 3.91 | 1.30 | 2.13 | 16.11 | 28.42 | 13.42 | 327.45 | 0.4163 | -985.6 | -738.9 | |
| 0.00 | 1.53 | 0.00 | 0.84 | 17.31 | 28.51 | 13.51 | 328.85 | 0.4330 | -761.0 | -573.0 | |
| 1.36 | 9.01 | 0.74 | 4.92 | 16.39 | 28.31 | 13.32 | 328.03 | 0.4192 | -1020.6 | -643.4 | |
| 3.57 | -6.00 | 1.95 | -6.00 | 16.58 | 28.20 | 13.20 | 328.50 | 0.4207 | -797.6 | 999999 | |
| 0.00 | 1.28 | 0.00 | 0.69 | 15.18 | 27.63 | 12.64 | 327.74 | 0.3973 | -766.0 | -584.6 | |
| 1.36 | 10.97 | 0.74 | 5.94 | 16.54 | 26.12 | 11.12 | 332.63 | 0.4040 | 979.2 | 510.1 | |
| 0.00 | 1.11 | 0.00 | 0.62 | 20.42 | 26.38 | 11.39 | 336.20 | 0.4605 | 569.0 | 501.5 | |
| 2.72 | -9.00 | 1.47 | -9.00 | 16.79 | 26.04 | 11.04 | 333.09 | 0.4070 | 743.1 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.57 | 20.26 | 26.18 | 11.18 | 336.43 | 0.4569 | 848.0 | 638.5 | |
| 0.00 | 1.87 | 0.00 | 1.01 | 16.75 | 25.28 | 10.29 | 334.64 | 0.4011 | 785.0 | 568.8 | |
| 0.00 | 1.70 | 0.00 | 0.92 | 17.13 | 24.96 | 9.97 | 335.74 | 0.4043 | 796.0 | 613.7 | |
| 0.00 | 2.64 | 0.00 | 1.42 | 16.33 | 24.48 | 9.49 | 335.93 | 0.3896 | 923.0 | 745.5 | |
| 0.00 | 1.53 | 0.00 | 0.82 | 15.94 | 23.28 | 8.29 | 338.28 | 0.3762 | 881.0 | 646.1 | |
| 0.00 | 1.02 | 0.00 | 0.55 | 16.28 | 22.83 | 7.84 | 339.69 | 0.3788 | 913.0 | 751.6 | |
| 0.00 | 1.28 | 0.00 | 0.68 | 15.84 | 22.60 | 7.60 | 339.83 | 0.3707 | 977.0 | 843.8 | |
| 0.00 | 2.64 | 0.00 | 1.41 | 16.09 | 22.24 | 7.24 | 340.94 | 0.3725 | 784.0 | 655.2 | |
| 0.00 | 1.36 | 0.00 | 0.73 | 18.07 | 20.16 | 5.17 | 347.40 | 0.3942 | 648.0 | 539.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
