SDO HMI 2014-01-14 07:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 79.86 | 449.70 | 40.45 | 227.84 | -16.46 | 12.96 | -1.49 | 173.18 | 0.2109 | 1205.4 | 439.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-14 07:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 46.18 | 277.82 | 23.40 | 140.75 | -16.60 | 13.71 | -0.74 | 176.64 | 0.2114 | 1471.6 | 484.1 | |
| 5.02 | -1.00 | 2.54 | -1.00 | -16.69 | 13.00 | -1.45 | 173.49 | 0.2140 | 1120.9 | 999999 | |
| 0.00 | 2.47 | 0.00 | 1.25 | -16.81 | 12.66 | -1.79 | 172.05 | 0.2168 | 729.0 | 623.2 | |
| 0.00 | 2.81 | 0.00 | 1.42 | -15.82 | 12.58 | -1.87 | 170.94 | 0.2001 | 1049.0 | 832.2 | |
| 3.66 | 156.56 | 1.85 | 79.31 | -16.51 | 12.21 | -2.24 | 169.79 | 0.2129 | 1170.7 | 406.5 | |
| 0.00 | 2.98 | 0.00 | 1.50 | -15.10 | 12.22 | -2.23 | 168.50 | 0.1890 | -483.0 | -303.4 | |
| 25.00 | -5.00 | 12.66 | -5.00 | -16.18 | 12.00 | -2.45 | 168.54 | 0.2080 | 1414.7 | 999999 | |
| 0.00 | 2.04 | 0.00 | 1.03 | -14.82 | 12.01 | -2.44 | 167.12 | 0.1852 | 982.0 | 709.9 | |
| 0.00 | 1.53 | 0.00 | 0.78 | -16.84 | 7.41 | -7.04 | 151.34 | 0.2457 | -910.0 | -869.7 | |
| 0.00 | 1.19 | 0.00 | 0.61 | -15.56 | 6.50 | -7.95 | 145.38 | 0.2356 | -812.0 | -604.4 | |
| 0.00 | 2.30 | 0.00 | 1.19 | -17.67 | 4.12 | -10.33 | 143.34 | 0.2874 | -720.0 | -690.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
