SDO HMI 2014-01-16 06:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.01 | 83.70 | 15.73 | 77.34 | 6.22 | 45.19 | 56.53 | 280.47 | 0.8454 | -594.7 | -300.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-16 06:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.68 | 54.78 | 0.64 | 51.20 | 5.95 | 45.87 | 57.22 | 279.99 | 0.8512 | -432.8 | -270.0 | |
| 6.97 | -1.00 | 6.49 | -1.00 | 5.85 | 45.64 | 56.98 | 279.91 | 0.8489 | -749.7 | 999999 | |
| 0.85 | 1.70 | 0.79 | 1.58 | 6.23 | 45.59 | 56.93 | 280.37 | 0.8490 | -426.1 | -346.0 | |
| 0.00 | 1.62 | 0.00 | 1.49 | 5.97 | 45.17 | 56.51 | 280.14 | 0.8447 | -553.0 | -497.2 | |
| 8.51 | 21.43 | 7.81 | 19.66 | 6.26 | 45.05 | 56.39 | 280.50 | 0.8441 | -792.1 | -475.7 | |
| 0.00 | 1.02 | 0.00 | 0.92 | 5.86 | 44.45 | 55.79 | 280.15 | 0.8379 | -678.0 | -595.8 | |
| 0.00 | 0.68 | 0.00 | 0.59 | 7.23 | 42.50 | 53.84 | 282.19 | 0.8217 | -392.0 | -351.6 | |
| 0.00 | 1.11 | 0.00 | 0.85 | 15.65 | 34.92 | 46.27 | 294.91 | 0.7694 | 469.0 | 380.4 | |
| 0.00 | 1.36 | 0.00 | 1.05 | 15.51 | 34.71 | 46.05 | 294.83 | 0.7667 | 491.0 | 429.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
