SDO HMI 2014-01-16 11:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.02 | 12.76 | 0.78 | 9.02 | 16.11 | 26.80 | 40.86 | 298.26 | 0.7145 | 229.4 | 182.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-16 11:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.51 | 2.55 | 0.39 | 1.94 | 15.79 | 31.39 | 45.46 | 295.43 | 0.7619 | -599.2 | -526.6 | |
| 0.51 | 2.04 | 0.39 | 1.54 | 15.82 | 30.97 | 45.03 | 295.67 | 0.7576 | -748.3 | -602.7 | |
| 0.00 | 1.19 | 0.00 | 0.81 | 15.78 | 24.51 | 38.58 | 298.98 | 0.6884 | 582.0 | 502.4 | |
| 0.00 | 0.94 | 0.00 | 0.64 | 16.20 | 24.26 | 38.33 | 299.69 | 0.6879 | 571.0 | 479.6 | |
| 0.00 | 2.30 | 0.00 | 1.55 | 15.87 | 23.87 | 37.94 | 299.49 | 0.6817 | 742.0 | 627.6 | |
| 0.00 | 1.53 | 0.00 | 1.04 | 16.35 | 23.98 | 38.05 | 300.05 | 0.6856 | 629.0 | 521.1 | |
| 0.00 | 1.53 | 0.00 | 1.05 | 17.56 | 24.19 | 38.26 | 301.50 | 0.6948 | 623.0 | 471.2 | |
| 0.00 | 0.68 | 0.00 | 0.45 | 15.92 | 23.11 | 37.17 | 300.04 | 0.6735 | 740.0 | 666.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
