SDO HMI 2014-01-17 22:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.21 | 39.36 | 15.84 | 44.71 | -17.71 | 30.99 | 64.29 | 252.62 | 0.9008 | 64.7 | 44.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-01-17 22:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.11 | 27.03 | 1.30 | 31.90 | -17.13 | 32.11 | 65.40 | 253.34 | 0.9088 | 376.8 | 174.2 | |
| 6.55 | -1.00 | 7.70 | -1.00 | -17.53 | 32.08 | 65.38 | 252.89 | 0.9088 | 503.2 | 999999 | |
| 0.43 | -1.00 | 0.50 | -1.00 | -17.85 | 32.31 | 65.61 | 252.55 | 0.9105 | 281.0 | 999999 | |
| 3.23 | 7.31 | 3.38 | 7.67 | -18.35 | 28.53 | 61.83 | 251.75 | 0.8830 | -496.2 | -376.3 | |
| 2.89 | 5.02 | 2.96 | 5.14 | -18.12 | 27.80 | 61.10 | 251.94 | 0.8772 | -609.1 | -458.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
