SDO HMI 2014-02-24 02:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 104.83 | 472.05 | 79.16 | 359.79 | -1.38 | 148.15 | -49.17 | 85.71 | 0.7593 | -263.3 | -110.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-02-24 02:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.92 | 239.93 | 11.27 | 170.52 | -2.51 | 151.74 | -45.57 | 86.52 | 0.7171 | -1291.7 | -429.5 | |
| 0.00 | 0.86 | 0.00 | 0.61 | -4.70 | 151.56 | -45.76 | 89.60 | 0.7164 | -690.0 | -447.4 | |
| 24.44 | -1.00 | 17.45 | -1.00 | -2.15 | 151.38 | -45.94 | 86.09 | 0.7222 | -887.3 | 999999 | |
| 2.32 | -1.00 | 1.66 | -1.00 | -2.90 | 151.34 | -45.98 | 87.12 | 0.7214 | -589.3 | 999999 | |
| 0.00 | 0.52 | 0.00 | 0.37 | -1.69 | 150.53 | -46.79 | 85.62 | 0.7330 | -404.0 | -349.5 | |
| 8.95 | 19.45 | 6.54 | 14.21 | -2.04 | 150.12 | -47.20 | 86.17 | 0.7372 | -808.0 | -505.7 | |
| 4.56 | -6.00 | 3.34 | -6.00 | -1.71 | 150.09 | -47.23 | 85.73 | 0.7381 | -624.9 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.76 | -1.02 | 150.07 | -47.25 | 84.81 | 0.7396 | -454.0 | -272.3 | |
| 2.07 | 9.90 | 1.52 | 7.31 | -1.55 | 149.70 | -47.62 | 85.59 | 0.7430 | -431.2 | -258.9 | |
| 11.02 | 15.06 | 8.13 | 11.12 | -2.25 | 149.49 | -47.82 | 86.56 | 0.7442 | -617.6 | -325.7 | |
| 1.72 | -9.00 | 1.27 | -9.00 | -1.74 | 149.47 | -47.85 | 85.89 | 0.7453 | -506.8 | 999999 | |
| 0.00 | 0.95 | 0.00 | 0.70 | -1.87 | 149.24 | -48.08 | 86.10 | 0.7477 | -264.0 | -212.8 | |
| 2.15 | 3.61 | 1.60 | 2.69 | -1.50 | 149.17 | -48.15 | 85.63 | 0.7492 | -383.2 | -186.6 | |
| 0.00 | 0.95 | 0.00 | 0.71 | -3.04 | 148.42 | -48.90 | 87.80 | 0.7554 | -285.0 | -327.1 | |
| 0.00 | 1.55 | 0.00 | 1.17 | -2.92 | 148.34 | -48.98 | 87.64 | 0.7565 | -626.0 | -455.9 | |
| 0.52 | 1.89 | 0.39 | 1.43 | -2.55 | 148.27 | -49.05 | 87.18 | 0.7578 | -440.0 | -360.7 | |
| 0.69 | 1.64 | 0.52 | 1.24 | -1.36 | 148.27 | -49.05 | 85.61 | 0.7596 | -536.5 | -481.0 | |
| 0.00 | 0.34 | 0.00 | 0.26 | -2.57 | 148.17 | -49.15 | 87.22 | 0.7588 | -473.0 | -411.2 | |
| 0.00 | 1.29 | 0.00 | 0.98 | -3.63 | 148.06 | -49.26 | 88.63 | 0.7587 | -466.0 | -413.9 | |
| 0.00 | 1.03 | 0.00 | 0.79 | -1.75 | 147.98 | -49.34 | 86.17 | 0.7622 | -264.0 | -255.9 | |
| 0.00 | 1.03 | 0.00 | 0.83 | -2.22 | 145.52 | -51.80 | 87.21 | 0.7885 | 416.0 | 308.2 | |
| 0.00 | 1.38 | 0.00 | 1.12 | -0.14 | 145.33 | -51.99 | 84.63 | 0.7936 | 734.0 | 574.8 | |
| 2.67 | 4.91 | 2.17 | 4.00 | -0.12 | 145.09 | -52.23 | 84.65 | 0.7962 | 530.7 | 467.1 | |
| 3.18 | 4.91 | 2.58 | 3.98 | -2.40 | 144.92 | -52.40 | 87.53 | 0.7946 | 650.4 | 463.3 | |
| 0.00 | 0.95 | 0.00 | 0.78 | -0.88 | 144.29 | -53.03 | 85.73 | 0.8033 | 550.0 | 496.2 | |
| 0.00 | 0.69 | 0.00 | 0.57 | -1.22 | 144.13 | -53.18 | 86.19 | 0.8044 | 640.0 | 573.1 | |
| 0.00 | 2.50 | 0.00 | 2.07 | -1.45 | 144.03 | -53.29 | 86.49 | 0.8052 | 622.0 | 549.6 | |
| 18.33 | 149.23 | 15.41 | 126.15 | -0.04 | 143.75 | -53.57 | 84.81 | 0.8101 | 976.9 | 282.8 | |
| 1.38 | 5.42 | 1.15 | 4.55 | -1.12 | 143.74 | -53.58 | 86.13 | 0.8086 | 718.9 | 547.0 | |
| 4.39 | -28.00 | 3.72 | -28.00 | 0.50 | 143.45 | -53.87 | 84.21 | 0.8140 | 637.6 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.87 | -0.72 | 143.39 | -53.93 | 85.71 | 0.8127 | 425.0 | 378.9 | |
| 0.52 | -28.00 | 0.44 | -28.00 | 1.04 | 142.88 | -54.44 | 83.67 | 0.8206 | 246.0 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
